Memphis Car Audio - Memphis Audio MJP800.4 4-Channel 800 Watt Amplifier - 200 Watts RMS x 4 at 2-Ohm - Black/Gray
Reviews coming soon
About this product
Memphis Audio MJP800.4 4-Channel 800 Watt Amplifier - 200 Watts RMS x 4 at 2-Ohm — Features: Extruded aluminum Heatsink; 12dB/octave butterworth crossovers; Variable crossovers; 3 EQ boost settings - 0, 6, 12dB; Strap-able mono block amps. Specifications: RMS Power/CH @ 4: 125x4; RMS Power/CH @ 2: 200x4; RMS Power/CH @ 1: na; RMS Power/Bridge 4 Ohms: 400x2; THD: 80dB; Frequency Response ± 0.5dB: 10Hz – 25kHz; Crossover Frequency (HPF): 50-250kHz; Crossover Frequency (LPF): 50-250Hz; Subsonic: na; Dimensions (in): 7.5 x 2 x 8.7"; Input Range: 400mV - 7.5V LOW LEVEL, 3V-20V HIGH LEVEL; Crossover slope: 12db crossovers.
Features
Key Feature
4-channel full-range amplifier rated at 125W RMS x 4 @ 4Ω, 200W RMS x 4 @ 2Ω, or 400W RMS x 2 bridged @ 4Ω, giving you flexible power options for front/rear speakers, components, or a combination of speakers and small subs.
Key Feature
Built on an extruded aluminum heatsink chassis measuring approximately 7.5" x 2" x 8.7", designed to help manage heat while keeping the amplifier compact enough for under-seat, trunk, or side-panel installations.
Key Feature
Features 12dB/octave Butterworth crossovers with variable high-pass and low-pass filters (HPF: 50–250Hz, LPF: 50–250Hz), allowing you to tailor the frequency range going to each channel for component sets, coaxials, or bridged midbass/sub setups.
Key Feature
Includes 3-position EQ boost (0, +6, +12dB) so you can add controlled emphasis where needed, along with a frequency response of 10Hz–25kHz, THD under 1%, and a signal-to-noise ratio greater than 80dB for clean, wideband audio performance.
Key Feature
Offers a broad input sensitivity range of 400mV–7.5V (low level) and 3V–20V (high level), making integration straightforward with aftermarket head units and many factory systems that provide either preamp or speaker-level outputs.
Specifications
- Amplifier ClassDNumber Of Channels4Bass BoostVariable
