NVX - XLCA2X X-Series PRO 2-Channel Line Out Converter Digital Bass Enhancer xBOOST, Impedance Matching, Remote Level Control
Reviews coming soon
About this product
Product Details: Active 2-channel line output converter and line driver. Designed to work with factory and aftermarket audio systems. Speaker-level inputs handle up to 30V (225 watts RMS). Low-level RCA inputs handle 150 mV - 2 Volts. RCA outputs Provides up to 9. 5 Volts of output. Adjustable xBOOST corrects for bass roll-off. Auto turn-on via DC offset or Audio detection. Load selection switch (20, 60, or 20K ohm) to prevent factory stereo shut-down. 12 Volt turn-on output for aftermarket amplifiers. Selectable Ground Isolation switch to eliminate ground and alternator noise. Molex terminals for speaker signal and power. Wired remote bass level control included. LED Clip indicator. Total Harmonic Distortion: 0. 001%. Signal to Noise: >105 dB. Frequency Response: 10-25, 000 Hz. Authorized Internet Dealer. 1-year Manufacturer's Warranty.
Features
2-Channel Line Out Converter w/ Digital Bass Enhancer xBOOST
X-Series PRO 2-channel line out converter enhances car audio with adjustable xBOOST to correct bass roll-off for deeper sound. Handles up to 30V (225W RMS) and delivers up to 9.5V output for strong audio performance. Features auto turn-on via DC offset or signal detection and a load switch (20, 60, or 20K ohms) to prevent factory radio shutdown. Includes wired remote for easy bass level adjustment.
Specifications
- BrandNVXModel Numberxlca2xProduct NameXLCA2X X-Series PRO 2-Channel Line Out Converter Digital Bass Enhancer xBOOST, Impedance Matching, Remote Level ControlProduct CompatibilityAudio/VideoProduct TypeLine output converterUPC810021844589
Reviews
This product doesn't have any reviews yet.
Compare similar products
Product Details: Active 2-channel line output converter and line driver. Designed to work with factory and aftermarket audio systems. Speaker-level inputs handle up to 30V (225 watts RMS). Low-level RCA inputs handle 150 mV - 2 Volts. RCA outputs Provides up to 9. 5 Volts of output. Adjustable xBOOST corrects for bass roll-off. Auto turn-on via DC offset or Audio detection. Load selection switch (20, 60, or 20K ohm) to prevent factory stereo shut-down. 12 Volt turn-on output for aftermarket amplifiers. Selectable Ground Isolation switch to eliminate ground and alternator noise. Molex terminals for speaker signal and power. Wired remote bass level control included. LED Clip indicator. Total Harmonic Distortion: 0. 001%. Signal to Noise: >105 dB. Frequency Response: 10-25, 000 Hz. Authorized Internet Dealer. 1-year Manufacturer's Warranty.
Product Details: 2-channel line out converter. Speaker Level Input Accepts Up To 400 Watts RMS. Bass Enhancer And Bass Compensation. xBOOST Technology. Selectable Auto On optimizes efficiency by only utilizing XLCA2 when the vehicle is in use. 9. 5 Volt Pre-Out. 12 Volt Trigger Out. Dual Amplifier Outputs. Level Matching Controls. Dash Remote Level Control Included. Dimensions: 5-1/2" W x 3-3/4" L x 1-1/4" H. Authorized Internet Dealer. 3 Year Manufacturer's Warranty. Check out the NVX XLCA2 Owner's Manual
