Onkyo - TX-RZ30 9.2 Channel AV Receiver - Black
AudioQuest - X2 - 30' - Gray with Red Stripes$104.95
More Buying Options
Related Item
Specifications
- Continuous Watts x Channel @ Ohms100W x 2 @ 8 ohmsMaximum Watts x Channel @ Ohms170W x 1 @ 4 ohmsNumber of Channels9.2Number of Audio Zones3Audio Only Inputs5 x Analog audio, 1 x Coaxial digital audio, 1 x Optical digital audio, 1 x Analog audio, 1 x USB-AAudio/Video Inputs6 x HDMI 2.1
- Key Specs
- Continuous Watts x Channel @ Ohms: 100W x 2 @ 8 ohms
- Maximum Watts x Channel @ Ohms: 170W x 1 @ 4 ohms (This is the maximum load the speaker, subwoofer or amp can drive.)
- Number of Channels: 9.2 (The number of discrete channels of sound output. This can be a single number or multiple numbers separated by decimal(s). The first number is the primary, horizontally directed audio channels. The number after the first decimal, if applicable, is the number of subwoofer outputs or channels. The number after the second decimal, if applicable, is the number of height or atmospheric channels designed to immerse the listener by producing overhead sound effects.)
- Number of Audio Zones: 3 (Audio zones, typically designated by rooms in a home, are areas in which all speakers are dependent on the same sound source. Whether a zone encompasses one or multiple rooms, the receiver or preamp/processor is used to control all aspects of its audio and is able to select which zones receive sound.)
- Audio Only Inputs: 5 x Analog audio, 1 x Coaxial digital audio, 1 x Optical digital audio, 1 x Analog audio, 1 x USB-A
- Audio/Video Inputs: 6 x HDMI 2.1 (The number and type of HDMI inputs the product has.)
- Network Connector(s): 1 x LAN, 1 x RS-232, 1 x IR in and out
- Video Pass-through: 2160 (4K), 1080, HDR, 3D (Devices with this feature allow video signals to travel from their source to a target device without alteration. For example, a receiver with 4K pass-through would allow 4K video signal from a Blu-ray player to pass to a target TV with surround sound; without the pass-through ability, the receiver would not allow both 4K video and surround sound to be transmitted simultaneously.)
- Maximum Supported Resolution (Video Passthrough): 4320p (8K) @ 60 Hz (The highest video resolution supported by the device for passing through video to another device.)
- Audio/Video Outputs: 2 x HDMI 2.1 (The number and type of HDMI outputs the product has.)
- Wireless Connectivity: Bluetooth, Wi-Fi (The manner in which a device sends data to another device over a short distance without the use of wires or cables.)
- Works With: Google Home (Compatible with or able to be connected to other smart devices or applications.)
- General
- Brand: Onkyo
- Model Number: TX-RZ30BMDC
- Product Name: TX-RZ30 9.2 Channel AV Receiver (Black)
- Color: Black
- Audio
- Continuous Watts x Channel @ Ohms: 100W x 2 @ 8 ohms
- Maximum Watts x Channel @ Ohms: 170W x 1 @ 4 ohms (This is the maximum load the speaker, subwoofer or amp can drive.)
- Number of Channels: 9.2 (The number of discrete channels of sound output. This can be a single number or multiple numbers separated by decimal(s). The first number is the primary, horizontally directed audio channels. The number after the first decimal, if applicable, is the number of subwoofer outputs or channels. The number after the second decimal, if applicable, is the number of height or atmospheric channels designed to immerse the listener by producing overhead sound effects.)
- High Resolution Audio: true (Hear music the way musicians and sound technicians intended it to be heard. Products that support hi-res audio deliver audio signals with a dynamic range and bandwidth far greater than that of a standard CD so you'll be able to enjoy pure music with outstanding sound quality. The device supports high-resolution audio signals, which more closely resemble the quality of music as it was originally recorded, with more texture and detail than can be heard via typical music streaming services or CDs.)
- Number of Audio Zones: 3 (Audio zones, typically designated by rooms in a home, are areas in which all speakers are dependent on the same sound source. Whether a zone encompasses one or multiple rooms, the receiver or preamp/processor is used to control all aspects of its audio and is able to select which zones receive sound.)
- Number of Audio Zone Source Outputs: 2 (Multiple source outputs from the receiver mean different speakers are able to receive different sound sources from the receiver or preamp/processor. For every output, a different sound source can be accessed simultaneously in different zones. For example, two source outputs could be a streaming media player in one room and a Blu-ray player in another.)
- Surround Sound Supported: Dolby Atmos, DTS:X, IMAX Enhanced, Dolby TrueHD, DTS-HD Master Audio (Surround sound systems use multiple audio channels and speakers to create an immersive sound experience for the listener. There are also various proprietary technologies that imitate this kind of sound via a device's built-in speakers or soundbar.)
- Maximum Sampling Rate Supported: 192kHz (Generally, the higher the sampling rate, the greater the quality of audio and/or video.)
- Speaker A/B Switching: false (Allows a user to select between one of two sets of primary speakers.)
- DSP Modes: Dirac Live (Available sound modes that alter how the audio is processed and played back. A common example is a mode that allows stereo audio to be played on all available surround sound speakers, creating a simulated surround sound effect.)
- Equalizer: true (Allows for the control of different frequencies within an audio signal, such as adjusting treble and bass levels.)
- Tuner Type(s): AM/FM, Internet
- Inputs
- Audio Only Inputs: 5 x Analog audio, 1 x Coaxial digital audio, 1 x Optical digital audio, 1 x Analog audio, 1 x USB-A
- Video Only Inputs: 1 x Component video, 2 x Composite video (The number and type of video signal only inputs the product has.)
- Audio/Video Inputs: 6 x HDMI 2.1 (The number and type of HDMI inputs the product has.)
- Network Connector(s): 1 x LAN, 1 x RS-232, 1 x IR in and out
- Front Facing Inputs: USB, Headphone, Setup Mic
- Number of HDMI Inputs (Total): 6
- Number of USB Inputs: 1
- Video
- Video Pass-through: 2160 (4K), 1080, HDR, 3D (Devices with this feature allow video signals to travel from their source to a target device without alteration. For example, a receiver with 4K pass-through would allow 4K video signal from a Blu-ray player to pass to a target TV with surround sound; without the pass-through ability, the receiver would not allow both 4K video and surround sound to be transmitted simultaneously.)
- Maximum Supported Resolution (Video Passthrough): 4320p (8K) @ 60 Hz (The highest video resolution supported by the device for passing through video to another device.)
- High Dynamic Range Format: HDR 10+, Dolby Vision, Hybrid Log-Gamma (HLG) (There are a few HDR formats that tell the TV or other HDR-compatible product how to best utilize its capabilities to display HDR content. HDR technology can support one or multiple formats, each with various benefits to picture quality.)
- Outputs
- Video Only Outputs: No video only outputs (The number and type of video signal only outputs the product has.)
- Audio/Video Outputs: 2 x HDMI 2.1 (The number and type of HDMI outputs the product has.)
- Speaker Connection Type: Banana Jack/Screw Terminals
- Number of HDMI Outputs (Total): 2
- Headphone Jack: true (The device features an interface that allows for the connection of headphones.)
- Features
- App Compatible: true (The product can be connected to a program or software application on a mobile device, which then receives collected data from the product.)
- Featured Streaming Services: TIDAL, Spotify, TuneIn (Streaming services and other programs are available on this device. Keep in mind, there may be more services supported than just those shown here.)
- Auto Calibration: true (Home theater systems and receivers with an autocalibration function can automatically determine basic settings like speaker volume, crossover point, equalization, and more.)
- Digital Content Protection: HDCP 2.3 (High-bandwidth Digital Content Protection (HDCP) is designed to prevent copying of digital audio and video content as it travels across connections. Newer versions of HDCP support more connection types, increase security, and resolve weaknesses of previous versions.)
- Remote Control Included: true
- Connectivity
- Wireless Multi-Room Audio: true (Technology that allows multiple speakers and/or soundbars to be connected wirelessly and play audio in separate rooms.)
- Wireless Multi-Room Technology: Sonos, Apple AirPlay 2, Google Cast (Proprietary technology that allows multiple speakers and/or soundbars to be connected wirelessly and play audio in separate rooms.)
- Wireless Connectivity: Bluetooth, Wi-Fi (The manner in which a device sends data to another device over a short distance without the use of wires or cables.)
- IP Control: true (Allows electronic devices to be controlled over a home network via a web-based interface. Typically refers to devices not traditionally controlled in this manner, such as A/V receivers.)
- Compatibility
- Works With: Google Home (Compatible with or able to be connected to other smart devices or applications.)
- Dimensions
- Product Height: 7 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 17.1 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 15.1 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Product Weight: 25.4 pounds (The out of box weight of the item.)
- Warranty
- Warranty - Parts: Three Years
- Warranty - Labor: Three Years
- Other
- UPC: 889951003953
For nearly 80 years, Onkyo has been providing audiophiles with sounds that no other company can match. Thanks to unique analogue circuitry and high-end amplifier technology, the 9.2-channel Onkyo TX-RZ30 delivers your favorite content with out-of-this-world sound – with soaring highs and deeper bass. Fan favorite features like Dirac Live, Dolby Atmos, and IMAX Enhanced come standard with the Onkyo RZ Series AVRs to make it the heartbeat of your entertainment system.
- Ultra-Wide Bandwidth Via Custom High-Current Circuitry: Thanks to custom low-noise power transformers and smoothing capacitors, the [PRODUCT] hits rumbling lows (5 Hz) and stunning highs (100 kHz) for an expansive audio experience our competitors just can’t match.
- Dirac Live: Dirac live room correction full bandwidth, is capable of calibrating the full frequency range of music and movie sound. with dirac live bass control, an optional upgrade, (single/multi), subwoofer output is calibrated with all your other speakers to provide additional bass refinement and fine details, while enhancing mid and high frequencies that were previously inaudible.
- Imax Enhanced For Vibrant, Lifelike Experience: Imax enhanced is a vital part of the premium home theater experience, delivering object-based audio for precisely placed sound and movement in 3D space. Meanwhile their exceptional video quality comes from a proprietary algorithm that optimizes color accuracy, contrast, and detail for a more vibrant and lifelike visual experience.
- Built-In Streaming Works With Sonos: The onkyo TX-RZ30 includes all your favorite streaming apps for seamless playback of digital content through all 9.2 channels. Plus, with the addition of a Sonos port, high quality sound can be distribution through your Sonos wireless network.
- Home Theater-Approved With 9.2-Channels: Onkyo’s 9.2-Channel TX-RZ30 allows you to create the home theater of your dreams with plenty of inputs for all your speakers.
- Ultra-Wide Bandwidth Via Custom High-Current Circuitry: Thanks to custom low-noise power transformers and smoothing capacitors, the [PRODUCT] hits rumbling lows (5 Hz) and stunning highs (100 kHz) for an expansive audio experience our competitors just can’t match.
- Dirac Live: Dirac live room correction full bandwidth, is capable of calibrating the full frequency range of music and movie sound. with dirac live bass control, an optional upgrade, (single/multi), subwoofer output is calibrated with all your other speakers to provide additional bass refinement and fine details, while enhancing mid and high frequencies that were previously inaudible.
- Imax Enhanced For Vibrant, Lifelike Experience: Imax enhanced is a vital part of the premium home theater experience, delivering object-based audio for precisely placed sound and movement in 3D space. Meanwhile their exceptional video quality comes from a proprietary algorithm that optimizes color accuracy, contrast, and detail for a more vibrant and lifelike visual experience.
- Built-In Streaming Works With Sonos: The onkyo TX-RZ30 includes all your favorite streaming apps for seamless playback of digital content through all 9.2 channels. Plus, with the addition of a Sonos port, high quality sound can be distribution through your Sonos wireless network.
- Home Theater-Approved With 9.2-Channels: Onkyo’s 9.2-Channel TX-RZ30 allows you to create the home theater of your dreams with plenty of inputs for all your speakers.
Whats Included
- TX-RZ30 9.2 Channel AV Receiver (Black)
- 6' AC power cord
- Remote Control
- Setup Microphone
- Dirac Live QR Code Card
- TX-RZ30 9.2 Channel AV Receiver (Black)
- 6' AC power cord
- Remote Control
- Setup Microphone
- Dirac Live QR Code Card
Product Manuals
Q: What is the weight of the receiver?
A: The Onkyo TX-RZ30 9.2 Channel AV Receiver weighs 25.4 pounds.
Q: What are the dimensions of the receiver?
A: The Onkyo TX-RZ30 receiver has a width of 17.1 inches, a depth of 15.1 inches, and a height of 7 inches.
Q: Can the receiver be used for a 9.2 channel surround sound system?
A: This receiver would be suitable for a 9.2 channel surround sound system. The Onkyo TX-RZ30 is a 9.2 channel AV receiver.
Q: Does the receiver support Dolby Atmos?
A: This receiver supports Dolby Atmos surround sound.
Q: Is a remote control included with the receiver?
A: The Onkyo TX-RZ30 9.2 Channel AV Receiver does include a remote control.
Q: How many HDMI inputs does the receiver have?
A: This receiver has six HDMI inputs.
Q: Can a phonographic turntable be connected to this receiver?
A: Hello Rick, The TXRZ30 does support the phono input connection along with the ground screw. However, if your turntable is already pre amplified, then you can go into any input on the receiver. Thank you Onkyo
Q: How many watts per channel does it have
A: Hello Chad The TXRZ30 with 8 ohm speakers is 100 watts per channel channel at 20hz- 20kHz with a 0.08 THD. Thank you Onkyo
Compare similar products
For nearly 80 years, Onkyo has been providing audiophiles with sounds that no other company can match. Thanks to unique analogue circuitry and high-end amplifier technology, the 9.2-channel Onkyo TX-RZ30 delivers your favorite content with out-of-this-world sound – with soaring highs and deeper bass. Fan favorite features like Dirac Live, Dolby Atmos, and IMAX Enhanced come standard with the Onkyo RZ Series AVRs to make it the heartbeat of your entertainment system.
Experience breathtaking 8K video and immersive 3D audio with our new 7.2-channel 8K receiver. Enjoy space-filling sound from your 7.2 or 5.2.2 setup with Dolby Atmos and DTS:X. It’s easy to enjoy all your content with Works with SONOS, Chromecast Built-in, Apple AirPlay, and Spotify Connect—all via Wi-Fi or Bluetooth.
Start your new entertainment life in the media room, where the RZ50 passes 8K HDR video to your display via HDMIR—optimized for lag-free gameplay and feeds Dolby AtmosR or DTS:XR sound to your 5.2.4-ch speaker system with high-current power behind it. Move to another space and music follows with three-zone powered audio and the SMART AV Receiver suite controlled by voice with easy access to streaming services. The AVR fits into your Sonos system and plays to headphones over bidirectional BluetoothR wireless technology. With 75 years of hi-fi knowhow elevating our THXR Certified Select and IMAXR Enhanced certified RZ Series custom amp design, music, film scores, and game soundtracks thrill with emotion, sound perfected by Dirac LiveR Room Correction. This AVR has features others don’t, such as front-to-height stereo switching for background listening, DSP vocal/dialog enhancement, My Volume presets, and an OSD function that compares source data to output settings so playback can be optimized before entertainment kicks off.
Building key noise-reduction refinements into 100 W/Ch THX Certified Select high-current amplification, the Onkyo TX-NR6100 sets the bar for reference sound while bringing 8K/60p and HDR10+ video to your compatible display over HDMI. Enjoy Dolby Atmos and DTS:X soundtracks through your height-enabled surround system or use upmixing and virtualization solutions from DTS and Dolby to create a 3D sound-field from any layout. Cue and control music around your home with voice assistants Hey Google or Alexa, and connect a second display via HDMI Sub/Zone 2 output. Chromecast built-in, AirPlay 2, DTS Play-Fi, and Works with Sonos cover every multi-room situation, and if you connect passive loudspeakers, you can switch between a 7.2/5.2.2-ch and 5.2-ch + Zone 2 layout at the touch of a button thanks to dedicated Zone 2 speaker terminals. Features such as a quality MM phono equalizer and bi-directional Bluetooth wireless technology make this value proposition even more persuasive.
| Pros for Onkyo - TX-RZ30 9.2 Channel AV Receiver - Black | |||
|---|---|---|---|
| Sound Quality | Sound Quality, Ease of use, Setup, Power, Dolby Atmos | Sound Quality, Power, Ease of use, Setup, Dirac | Sound Quality, Ease of use, Power, Setup, HDMI |
| Cons for Onkyo - TX-RZ30 9.2 Channel AV Receiver - Black | |||
| There were no cons for this product— | Remote | Input Switching, HDMI | Input Switching, Display |
Specs
Reviews
Customers are saying
Customers admire the TX-RZ30 9.2 Channel AV Receiver for its excellent sound quality. Users report that the sound quality is on point. There were no cons mentioned for this product.
Customer Images
The vast majority of our reviews come from verified purchases. Reviews from customers may include My Best Buy members, employees, and Tech Insider Network members (as tagged). Select reviewers may receive discounted products, promotional considerations or entries into drawings for honest, helpful reviews.
- Rated 4 out of 5 stars
RZ30 super affordable for its class...
This is my first sound receiver...i was hesitant between all of the different options available in the market today....however, I went for this receiver rz30 particularly for its sound quality, Dirac Live room correction, and robust feature set, including Dolby Atmos, DTS:X, and 8K/60Hz support. I realky like and appreciate its ability to handle various speaker configurations and its user-friendly setup process....i would say that the remote control feels old...and the app is meh....and for a novice such as me...it was complicated to set up and comprehend the multiple options...overall i super content with the purchase....
Posted by SuperNiceMacBookAir
- Rated 5 out of 5 stars
Onkyo TX-RZ30
This is my first Onkyo receiver. So far, its been great! I have no complaints. Would buy again.
Posted by mhstennis
- Rated 4 out of 5 stars
Checks all the boxes and looks promising
The new Onkyo TX-RZ30 checks all the boxes for a solid AVR. Of particular importance are full set of pre outputs, independent dual subwoofer outputs, and DIRAC room correction software. The price is competitive with other AVR’s in its class. Time will tell if Onkyo has ironed out the issues they’ve had with their AVR’s in the past.
Posted by DanielPlainview
