Onkyo - TX-NR7100 9.2 Channel THX Certified Network A/V Receiver - Black
Related Item
Specifications
- Continuous Watts x Channel @ Ohms100 watts x 9 channels @ 8 ohmsMaximum Watts x Channel @ Ohms100W/ch (8ohms, 20Hz~20kHz, 0.08% THD, 2ch driven, FTC)Number of Channels9.2Audio Only Inputs1 x Optical digital audio, 1 x Coaxial digital audio, 1 x PhonoAudio/Video Inputs7 x HDMINetwork Connector(s)1 x LAN
- Key Specs
- Continuous Watts x Channel @ Ohms: 100 watts x 9 channels @ 8 ohms
- Maximum Watts x Channel @ Ohms: 100W/ch (8ohms, 20Hz~20kHz, 0.08% THD, 2ch driven, FTC) (This is the maximum load the speaker, subwoofer or amp can drive.)
- Number of Channels: 9.2 (The number of discrete channels of sound output. This can be a single number or multiple numbers separated by decimal(s). The first number is the primary, horizontally directed audio channels. The number after the first decimal, if applicable, is the number of subwoofer outputs or channels. The number after the second decimal, if applicable, is the number of height or atmospheric channels designed to immerse the listener by producing overhead sound effects.)
- Audio Only Inputs: 1 x Optical digital audio, 1 x Coaxial digital audio, 1 x Phono
- Audio/Video Inputs: 7 x HDMI (The number and type of HDMI inputs the product has.)
- Network Connector(s): 1 x LAN
- Video Pass-through: HDR (Devices with this feature allow video signals to travel from their source to a target device without alteration. For example, a receiver with 4K pass-through would allow 4K video signal from a Blu-ray player to pass to a target TV with surround sound; without the pass-through ability, the receiver would not allow both 4K video and surround sound to be transmitted simultaneously.)
- Audio/Video Outputs: 2 x HDMI (The number and type of HDMI outputs the product has.)
- Wireless Connectivity: Bluetooth, Wi-Fi (The manner in which a device sends data to another device over a short distance without the use of wires or cables.)
- Works With: Amazon Alexa, Google Home (Compatible with or able to be connected to other smart devices or applications.)
- Voice Assistant Built-in: Amazon Alexa, Google Assistant (A digital assistant built into the device that uses voice commands to answer questions and control smart devices.)
- General
- Brand: Onkyo
- Model Number: TX-NR7100
- Product Name: TX-NR7100 9.2 Channel THX Certified Network A/V Receiver
- Color: Black
- Audio
- Continuous Watts x Channel @ Ohms: 100 watts x 9 channels @ 8 ohms
- Maximum Watts x Channel @ Ohms: 100W/ch (8ohms, 20Hz~20kHz, 0.08% THD, 2ch driven, FTC) (This is the maximum load the speaker, subwoofer or amp can drive.)
- Number of Channels: 9.2 (The number of discrete channels of sound output. This can be a single number or multiple numbers separated by decimal(s). The first number is the primary, horizontally directed audio channels. The number after the first decimal, if applicable, is the number of subwoofer outputs or channels. The number after the second decimal, if applicable, is the number of height or atmospheric channels designed to immerse the listener by producing overhead sound effects.)
- High Resolution Audio: true (Hear music the way musicians and sound technicians intended it to be heard. Products that support hi-res audio deliver audio signals with a dynamic range and bandwidth far greater than that of a standard CD so you'll be able to enjoy pure music with outstanding sound quality. The device supports high-resolution audio signals, which more closely resemble the quality of music as it was originally recorded, with more texture and detail than can be heard via typical music streaming services or CDs.)
- Surround Sound Supported: Dolby Atmos, DTS:X (Surround sound systems use multiple audio channels and speakers to create an immersive sound experience for the listener. There are also various proprietary technologies that imitate this kind of sound via a device's built-in speakers or soundbar.)
- Maximum Sampling Rate Supported: 24-bit/192kHz. (Generally, the higher the sampling rate, the greater the quality of audio and/or video.)
- Speaker A/B Switching: false (Allows a user to select between one of two sets of primary speakers.)
- Tuner Type(s): AM/FM, FM only, Internet
- Inputs
- Audio Only Inputs: 1 x Optical digital audio, 1 x Coaxial digital audio, 1 x Phono
- Video Only Inputs: 1 x Component video (The number and type of video signal only inputs the product has.)
- Audio/Video Inputs: 7 x HDMI (The number and type of HDMI inputs the product has.)
- Network Connector(s): 1 x LAN
- Number of HDMI Inputs (Total): 7
- Number of USB Inputs: 1
- Video
- Video Pass-through: HDR (Devices with this feature allow video signals to travel from their source to a target device without alteration. For example, a receiver with 4K pass-through would allow 4K video signal from a Blu-ray player to pass to a target TV with surround sound; without the pass-through ability, the receiver would not allow both 4K video and surround sound to be transmitted simultaneously.)
- Outputs
- Video Only Outputs: 1 x Component video (The number and type of video signal only outputs the product has.)
- Audio/Video Outputs: 2 x HDMI (The number and type of HDMI outputs the product has.)
- Speaker Connection Type: Banana Jack/Screw Terminals
- Number of HDMI Outputs (Total): 2
- Headphone Jack: true (The device features an interface that allows for the connection of headphones.)
- Features
- App Compatible: true (The product can be connected to a program or software application on a mobile device, which then receives collected data from the product.)
- Auto Calibration: true (Home theater systems and receivers with an autocalibration function can automatically determine basic settings like speaker volume, crossover point, equalization, and more.)
- Remote Control Included: true
- Connectivity
- Wireless Multi-Room Audio: true (Technology that allows multiple speakers and/or soundbars to be connected wirelessly and play audio in separate rooms.)
- Wireless Multi-Room Technology: Sonos, Google Cast, Apple AirPlay 2 (Proprietary technology that allows multiple speakers and/or soundbars to be connected wirelessly and play audio in separate rooms.)
- Wireless Connectivity: Bluetooth, Wi-Fi (The manner in which a device sends data to another device over a short distance without the use of wires or cables.)
- Compatibility
- Works With: Amazon Alexa, Google Home (Compatible with or able to be connected to other smart devices or applications.)
- Voice Assistant Built-in: Amazon Alexa, Google Assistant (A digital assistant built into the device that uses voice commands to answer questions and control smart devices.)
- Dimensions
- Product Height: 6.81 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 17.13 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 14.93 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Product Weight: 22.9 pounds (The out of box weight of the item.)
- Certifications Listings & Approvals
- ENERGY STAR Certified: false (Devices carrying the ENERGY STAR service mark, such as computer products and peripherals, kitchen appliances, and other products, generally use 20% to 30% less energy than required by federal standards.)
- Warranty
- Warranty - Parts: 2 years
- Warranty - Labor: 2 years
- Other
- UPC: 889951003496
Turn your home into a living media sanctuary with Onkyo TX-NR7100 9.2-channel Dynamic Audio Amplification (DAA) supporting 3D surround-sound and powered multi-zone audio together with the SMART AV Receiver suite for effortless voice-controllable entertainment via a Google Assistant or Amazon Alexa enabled device. HDMI supports 8K/60p and dynamic HDR (including HDR10+ and Dolby Vision) passthrough to compatible TVs, projectors, or gaming monitors connected via eARC-ready Main Out. Be overwhelmed by the hyper-realistic THX Certified Select reference experience, and explore the master-quality IMAX Enhanced film library. Unique functions such as Front-to-Height stereo switching for ambient background listening, DSP vocal/dialog enhancement, and practical GUI functions simplify everyday operation. Whether you’re gaming, watching a favorite TV series, or streaming Hi-Res Audio, a richer emotional life awaits inside the Onkyo signature sound.
- THX Certified Select theater-reference sound: THX Certified Select guarantees the same reference volume of a commercial theater in rooms where the screen-to-seat distance is about 12 ft. (3.5 m). Certified receivers must pass 2,000 bench-tests in 75 categories.
- Discover the IMAX experience: IMAX Enhanced uses DTS:X technology optimized for the
- Welcome to the 8K Ultra HD experience: Features defined in HDMI 2.1 specification enable 8K/60p video passthrough to your compatible display. As well as HDR10 and HLG, HDR10+ and Dolby Vision formats optimize brightness, contrast, and color scene-by-scene or frame-by-frame.
- New enhancements for gamers: Transform your playtime with 3D surround-sound and gain the winning edge with new gamer-friendly features defined in HDMI 2.1.
- SMART AV Receiver multi-room audio streaming: SMART AV Receiver shares audio around your home.
- Works with Sonos: Expand your Sonos Home Sound System by pairing this AVR with up to three Sonos Connect or Port* devices. The receiver ties into the Sonos ecosystem, waking, changing inputs, and playing at the desired volume on command from the Sonos app*.* Sonos Connect and Port sold separately.
- Chromecast built-in works with Hey Google: Stream music from your smartphone, lStream music from your smartphone, laptop, or PC to the receiver via Chromecast built-in.
- Works with Alexa: Alexa lets you use your voice to control the A/V receiver by speaking commands through an Alexa device.
- Dolby Atmos and DTS:X – celebrate a new world of sound: Dolby Atmos and DTS:X translate 3D soundtracks from the studio mixing desk to your room. Sounds are no longer tied to specific channels, and are free to move around and above your audience, placing them at the heart of the action.
- Dirac Live Room Correction: Onkyo TX-NR7100 Dirac Live analyzes your audio system and listening environment by examining acoustic data measured by microphone and detecting deficiencies.
- 5 GHz/2.4 GHz dual-band Wi-Fi supports the 802.11ac standard: A powerful quad-core SoC (System on a Chip) performs multiple processing tasks at once. It evolves network functions and supports the 802.11ac (2×2 MIMO) standard for stable multi-room audio streaming.
- Bi-directional Bluetooth wireless technology: This AVR can send and receive audio via Bluetooth wireless technology.
- Clearer dialog at the touch of a button: Vocal Enhancer solves the problem of inaudible dialog in movies and TV programs by using DSP algorithms to elevate vocal frequencies in the soundtrack. The effect level can be raised or lowered using keys on the remote control.
- Three-Zone Whole Home Audio: Manage playback in up to three rooms using the Onkyo Controller app.
- Multi-function Zone 2/Zone B line-out: Analog RCA line-out supports two Zone audio modes. Zone 2 supports active speaker or hi-fi system connection.
- Relax with Stereo Assign Mode: Onkyo TX-NR7100 Stereo Assign Mode switches playback from Front to Height 1, Height 2, Surround, or Surround Back speakers (depending on your layout). It’s ideal for ambient background listening.
- Connections for custom installations: A 12 V trigger output syncs operation with an external component, such as a power amp, while IR input connects an IR repeater.
- THX Certified Select theater-reference sound: THX Certified Select guarantees the same reference volume of a commercial theater in rooms where the screen-to-seat distance is about 12 ft. (3.5 m). Certified receivers must pass 2,000 bench-tests in 75 categories.
- Discover the IMAX experience: IMAX Enhanced uses DTS:X technology optimized for the
- Welcome to the 8K Ultra HD experience: Features defined in HDMI 2.1 specification enable 8K/60p video passthrough to your compatible display. As well as HDR10 and HLG, HDR10+ and Dolby Vision formats optimize brightness, contrast, and color scene-by-scene or frame-by-frame.
- New enhancements for gamers: Transform your playtime with 3D surround-sound and gain the winning edge with new gamer-friendly features defined in HDMI 2.1.
- SMART AV Receiver multi-room audio streaming: SMART AV Receiver shares audio around your home.
- Works with Sonos: Expand your Sonos Home Sound System by pairing this AVR with up to three Sonos Connect or Port* devices. The receiver ties into the Sonos ecosystem, waking, changing inputs, and playing at the desired volume on command from the Sonos app*.* Sonos Connect and Port sold separately.
- Chromecast built-in works with Hey Google: Stream music from your smartphone, lStream music from your smartphone, laptop, or PC to the receiver via Chromecast built-in.
- Works with Alexa: Alexa lets you use your voice to control the A/V receiver by speaking commands through an Alexa device.
- Dolby Atmos and DTS:X – celebrate a new world of sound: Dolby Atmos and DTS:X translate 3D soundtracks from the studio mixing desk to your room. Sounds are no longer tied to specific channels, and are free to move around and above your audience, placing them at the heart of the action.
- Dirac Live Room Correction: Onkyo TX-NR7100 Dirac Live analyzes your audio system and listening environment by examining acoustic data measured by microphone and detecting deficiencies.
- 5 GHz/2.4 GHz dual-band Wi-Fi supports the 802.11ac standard: A powerful quad-core SoC (System on a Chip) performs multiple processing tasks at once. It evolves network functions and supports the 802.11ac (2×2 MIMO) standard for stable multi-room audio streaming.
- Bi-directional Bluetooth wireless technology: This AVR can send and receive audio via Bluetooth wireless technology.
- Clearer dialog at the touch of a button: Vocal Enhancer solves the problem of inaudible dialog in movies and TV programs by using DSP algorithms to elevate vocal frequencies in the soundtrack. The effect level can be raised or lowered using keys on the remote control.
- Three-Zone Whole Home Audio: Manage playback in up to three rooms using the Onkyo Controller app.
- Multi-function Zone 2/Zone B line-out: Analog RCA line-out supports two Zone audio modes. Zone 2 supports active speaker or hi-fi system connection.
- Relax with Stereo Assign Mode: Onkyo TX-NR7100 Stereo Assign Mode switches playback from Front to Height 1, Height 2, Surround, or Surround Back speakers (depending on your layout). It’s ideal for ambient background listening.
- Connections for custom installations: A 12 V trigger output syncs operation with an external component, such as a power amp, while IR input connects an IR repeater.
Whats Included
- Remote Controller
- Speaker Set-Up Microphone
- Indoor FM Antenna
- AM Loop Antenna
- Power Cord
- Remote Controller
- Speaker Set-Up Microphone
- Indoor FM Antenna
- AM Loop Antenna
- Power Cord
Q: Does this receiver support Dolby Atmos?
A: Yes, this receiver supports Dolby Atmos and DTS:X for 3D sound.
Q: What is the wattage per channel for this receiver?
A: This receiver offers 100 watts per channel at 8 ohms.
Q: Can this receiver be used with a Sonos system?
A: Yes, you can expand your Sonos Home Sound System by pairing this AVR with up to three Sonos Connect or Port devices.
Q: Does this receiver have bluetooth?
A: Yes, this receiver has bluetooth connectivity.
Q: What is the maximum sampling rate supported by this receiver?
A: The maximum sampling rate supported is 24-bit/192kHz.
Q: How many channels does this Onkyo receiver have?
A: This Onkyo receiver has 9.2 channels.
Q: Does this passthrough 4k/120hz? I only see 8k/60hz on the specifications
A: Hello JoeB, The TXNR7100 does support 4K/120hz video passthrough. Thank you Onkyo
Q: Which Onkyo receiver, if any, currently supports HD Radio (RDS)?
A: Hello TechNerd4U, The TXNR7100 does not support HD Radio in the USA. RDS is available in European, Australian and Asian models. Thank you Onkyo
Compare similar products
Turn your home into a living media sanctuary with Onkyo TX-NR7100 9.2-channel Dynamic Audio Amplification (DAA) supporting 3D surround-sound and powered multi-zone audio together with the SMART AV Receiver suite for effortless voice-controllable entertainment via a Google Assistant or Amazon Alexa enabled device. HDMI supports 8K/60p and dynamic HDR (including HDR10+ and Dolby Vision) passthrough to compatible TVs, projectors, or gaming monitors connected via eARC-ready Main Out. Be overwhelmed by the hyper-realistic THX Certified Select reference experience, and explore the master-quality IMAX Enhanced film library. Unique functions such as Front-to-Height stereo switching for ambient background listening, DSP vocal/dialog enhancement, and practical GUI functions simplify everyday operation. Whether you’re gaming, watching a favorite TV series, or streaming Hi-Res Audio, a richer emotional life awaits inside the Onkyo signature sound.
Designed for optimum IMAX Enhanced and Dolby Atmos/DTS:X movie playback in a seamless 7.2.2ch/5.2.4ch surround sound calibrated by Advanced MCACC, along with support for next-generation video/gaming standards including HDMI 2.1 1 with 8K, VRR, ALLM, QFT pass-through, the VSX-LX305 brings multi-dimensional excitement to your home entertainment. Dolby Atmos Height Virtualizer provides virtual sound effects without using height or surround speakers. And it’s Roon Tested so music streaming from AV equipment is super easy. Enjoy multi-room audio streaming with Sonos system, Chromecast built-in, DTS Play-Fi, and Apple AirPlay 2. Finally, it works with Alexa or Hey Google for voice control.
Start your new entertainment life in the media room, where the RZ50 passes 8K HDR video to your display via HDMIR—optimized for lag-free gameplay and feeds Dolby AtmosR or DTS:XR sound to your 5.2.4-ch speaker system with high-current power behind it. Move to another space and music follows with three-zone powered audio and the SMART AV Receiver suite controlled by voice with easy access to streaming services. The AVR fits into your Sonos system and plays to headphones over bidirectional BluetoothR wireless technology. With 75 years of hi-fi knowhow elevating our THXR Certified Select and IMAXR Enhanced certified RZ Series custom amp design, music, film scores, and game soundtracks thrill with emotion, sound perfected by Dirac LiveR Room Correction. This AVR has features others don’t, such as front-to-height stereo switching for background listening, DSP vocal/dialog enhancement, My Volume presets, and an OSD function that compares source data to output settings so playback can be optimized before entertainment kicks off.
For nearly 80 years, Onkyo has been providing audiophiles with sounds that no other company can match. Thanks to unique analogue circuitry and high-end amplifier technology, the 9.2-channel Onkyo TX-RZ30 delivers your favorite content with out-of-this-world sound – with soaring highs and deeper bass. Fan favorite features like Dirac Live, Dolby Atmos, and IMAX Enhanced come standard with the Onkyo RZ Series AVRs to make it the heartbeat of your entertainment system.
| Pros for Onkyo - TX-NR7100 9.2 Channel THX Certified Network A/V Receiver - Black | |||
|---|---|---|---|
| Sound Quality, Setup, Atmos | Sound Quality, Ease of use, Power, Setup, Dirac Live | Sound Quality, Power, Ease of use, Setup, Dirac | Sound Quality |
| Cons for Onkyo - TX-NR7100 9.2 Channel THX Certified Network A/V Receiver - Black | |||
| HDMI | There were no cons for this product— | HDMI, Input Switching | There were no cons for this product— |
Specs
Reviews
Customers are saying
Customers frequently mention the excellent sound quality of the TX-NR7100 9.2 Channel THX Certified Network A/V Receiver, as well as the ease of setting it up. Many customers enjoy the Atmos feature. However, some customers have experienced issues with HDMI.
Customer Images
The vast majority of our reviews come from verified purchases. Reviews from customers may include My Best Buy members, employees, and Tech Insider Network members (as tagged). Select reviewers may receive discounted products, promotional considerations or entries into drawings for honest, helpful reviews.
- Rated 5 out of 5 stars
Onkyo 9.2 channel receiver
Best AVR I ever owned. Setup was a breeze. Sound is fantastic
Posted by GrandpaAndy
- Rated 3 out of 5 stars
Not quite ready for prime time.
My experience with the NR 7100 is not good. The unit has major HDMI switching issues that need to be addressed quickly. When changing from DVD back to cable TV, the video plays but the sound disappears. And I don't get the sound back unless I rurn the TV off and on - and even then there's an ubcomfortable delat. The fact is whenever I turn the NR7100 on I have no idea whether it will work or not. The bluetooth digital display remains fixed on the first song I play even when I change songs. The music changes, but the display stays fixed on the first song. Watching TV apps, like Netflix or Amazon is iffy. Video works, but sound gets lost or plays thru the TV speakers which can't find an external audio system AKA, the NR7100. HUH? Oh boy. And as for the calibration system, the famed Dirac Live, you can't download from Dirac, but must use the scaled down Onkyo licensed versions. And good luck trying to figure out the microphone placement for full, nine position calibration. Who drew that confusing diagram? I downloaded the full 191 page manual, which lacks commonsene explanations for setting up basic functions. I'm not an engineer and I doubt most buyers are either. One hundred and ninety-one pages? It's new and I still have a few days to decide if I want to keep this unit. I really do want to keep it, but for $1,100,00 I don't know if "hoping" for the best makes sense, when Marantz is right around the cirner. Fair warning. Problems, problems, problems. My assessment? This receiver is not quite ready for prime time. When it finds its way, the sound is good. The set up screens are pretty easy to navigate and the customer service is quite good. But in truth, having called rwice, even the reps seemed a little baffled that things weren't working as they shoukd. Look AV receivers should be intuitive and ready to identify and switch HDMI inputs, which the NR7100 isn't ready to do.
Posted by Skisan
- Rated 5 out of 5 stars
The Greatest Receiver I’ve Ever Owned!!!
I recently bought this Onkyo receiver And I got to tell you all this is the greatest receivers I’ve ever owned!!! My biggest recommendation is to mate this receiver with some Klipsch Dolby Atmos speakers and you’re really get some great sound!!! In fact you can choose in the settings menu that your brand of speakers is Klipsch. And if you get Jurassic World Dominion on 4K Blu-ray, that movie has DTS X Instead of Dolby Atmos with a Klipsch Subwoofer, oh my God now you will have a mini theater in your house!!! I have two Klipsch 12” powered subwoofers with this receiver.I really recommend this receiver to anybody who is a fan of theater surround sound. The only drawback that I could say is if you are coming off of a Onkyo TX-NR777 this receiver is not as loud as that one. Where the 777 is on volume at 30 on the 7100 you’ll need to put it to 40. But other than that this is a really great receiver!!!
Posted by JesseV
