Orei - 4K@60hz 8x8 HDMI™ Matrix Audio Extract UHD-808 - Black

The UHD88-EXB230R-K is a 4K HDMI Matrix extender that distributes media signals from 8 inputs to 8 distant displays. It supports video resolutions up to 4K@60Hz and 2K@60Hz and is compliant with HDMI 2.0b and HDCP 2.2 standards. This matrix extender can extend HDMI signals up to 400 feet at 4K@60Hz 4:4:4. With a video bandwidth of 18Gbps, it also allows for seamless pass-through of HDR, HDR10, HDR10+, Dolby Vision, and HLG. For displays that don't support 4K resolution, this matrix extender can downscale the resolution to 1080p for any HDBaseT output ports. This matrix extender supports a wide range of audio formats up to 7.1 channels, including LPCM, Dolby TrueHD, and DTS-HD Master Audio, with audio de-embedding (audio extraction) through analog and coaxial outputs simultaneously. It is equipped with bi-directional IR control allowing the control of the source device from the receiver's location and vice versa. Its Power over cable technology enables powering up the setup through only one power adapter connected to the transmitter. The unit can be controlled via the front panel buttons, remote control, RS-232, LAN, or the WebGUI interface. With its rack-mounted design, integration into both residential and commercial setups becomes easy.

The BK-808 is an 8 In 8 Out HDMI Matrix designed for switching or splitting between various sources and displays. It supports video resolutions up to 8K@60Hz 4:2:0 12bit and 4K@120Hz 4:4:4 12bit, with a video bandwidth of up to 48Gbps. The device includes Optical and Analog audio outputs for audio extraction and can be controlled via an included remote, front panel buttons, RS-232, or TCP/IP commands. It offers downscaling options, allowing you to downscale 8K to 4K or 8K/4K to 1080p on each output port. Additionally, the BK-808 supports HDMI 2.1 features like VRR, ALLM, QFT, QMS, and SBTM, ensuring advanced compatibility with modern displays. Robust build and easy plug-and-play installation. Perfect for both commercial and personal setups.

The UHD816-EX230-K Matrix can connect up to 8 HDMI sources and output to 16 displays. It features eight HDMI outputs, and each HDMI output is mirrored to provide a CAT-Cable output which runs simultaneously. It supports transmission of video with resolutions up to 4K@60Hz and 2K@60Hz and supports HD digital audio formats such as LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio. The Matrix can be used for multi-room connectivity, and the HDMI signals can be extended up to 230ft/70m via CAT-Cable outputs by connecting the included CAT Receivers. The Matrix supports one-way IR matrix function. It can be controlled via front panel buttons, IR remote, RS-232, LAN, and Web GUI.
