OWC - Thunderbolt 5 Dual 10GbE Network Dock
More Buying Options
About This Item
- Key Specs
- Maximum Number of Displays Supported: 3
- Maximum Supported Resolution: 8K (4320p)
- Number of DisplayPort Outputs (Total): 0
- Number of Thunderbolt Ports (Total): 4
- Passthrough Power: true (Indicates whether the device allows power to passthrough, possibly with some loss, to another device, typically to charge that other device.)
- General
- Brand: OWC
- Model Number: TB5DK11PD210G
- Product Name: OWC Thunderbolt 5 Dual 10GbE Network Dock
- Display
- Maximum Number of Displays Supported: 3
- Maximum Supported Resolution: 8K (4320p)
- Maximum Supported Refresh Rate: 144Hz (The number of frames per second the device can support, expressed as a frequency. Higher rates help produce smooth, seamless pictures.)
- Ports
- Display Connector(s): Display connection via USB port (The number and type of connectors used to connect to an external display.)
- Number of DisplayPort Outputs (Total): 0
- Number of HDMI Ports (Total): 0
- DisplayPort Over USB-C: DisplayPort 2.1 (The version of DisplayPort that leverages the Alternate Mode Functional Extension of the USB-C interface. This connector allows for higher resolution, broader color space, multichannel audio support, and greater backwards compatibility with display adapters. Also known as DisplayPort Alt Mode.)
- Number of Thunderbolt Ports (Total): 4
- Number of VGA Ports: 0 (VGA (Video Graphics Adapter or Video Graphics Array) is a display standard that transmits via analog signals. This type of interface is typically used to connect a computer to a display device such as a monitor, projector, or TV.)
- Number Of Ethernet Ports: 3
- Number of USB Ports (Total): 4
- USB Ports: 1 x USB-C 3.2, 3 x USB-A 3.2 (The number and type of USB ports the product has.)
- Headphone Jack: false (The device features an interface that allows for the connection of headphones.)
- Microphone Input: false (The device features an input for connecting an external microphone.)
- Memory Card Slot: false
- Power
- Powered: true
- Power Supply Included: true
- Cable Length: 2.3 feet
- Passthrough Power: true (Indicates whether the device allows power to passthrough, possibly with some loss, to another device, typically to charge that other device.)
- Power Supply Output: USB-C (The connector type(s) used by the device to send electrical power to another device.)
- Maximum Output Power: 15 watts (The maximum amount of power produced or allowed to flow through the device.)
- Compatibility
- Brand Compatibility: Mac|PC
- Model Compatibility: Mac|PC
- Features
- Cable Lock Slot: None
- Dimensions
- Product Height: 1.4 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Length: 8.3 inches (The out of box length of the item. Length is measured as the longest dimension of the item.)
- Product Width: 4.3 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Weight: 32 ounces (The out of box weight of the item.)
- Warranty
- Warranty - Parts: 2 Year OWC Limited Warranty
- Other
- UPC: 810179170776
One cable. One dock. Complex networking simplified. You can tell it’s special with just one glance. Three fully independent high speed Ethernet ports. Four Thunderbolt 5 and four USB ports. The Thunderbolt 5 Dual 10GbE Network Dock is the first all-in-one solution that simplifies complex multi-network workflows and unlocks high- bandwidth network storage connectivity while offering everyday docking convenience. Whether handling audio production with Dante, routing 4K NDI video streams for broadcast, outputting large high-res files to NAS storage, or administering a cluster of virtual machines in the cloud, it can all be done through this one dock via a single cable connection to a Thunderbolt equipped Mac or PC.
- WHAT YOU NEED TO KNOW: Host Interface Requirements: Thunderbolt 5 , Thunderbolt 4, USB4 or Thunderbolt 3 (Mac Only); Other Requirements: Thunderbolt 5 Mac systems require macOS 15.3.x or later; Thunderbolt 5, Thunderbolt 4, and USB4 PC systems require Windows 11 or later; Thunderbolt 4 and USB4 Apple silicon Macs require macOS version 14.x or later; Thunderbolt 3 support is Mac only and requires macOS 15.x or later; Linux - Latest version of Ubuntu
- WHAT YOU NEED TO KNOW: Host Interface Requirements: Thunderbolt 5 , Thunderbolt 4, USB4 or Thunderbolt 3 (Mac Only); Other Requirements: Thunderbolt 5 Mac systems require macOS 15.3.x or later; Thunderbolt 5, Thunderbolt 4, and USB4 PC systems require Windows 11 or later; Thunderbolt 4 and USB4 Apple silicon Macs require macOS version 14.x or later; Thunderbolt 3 support is Mac only and requires macOS 15.x or later; Linux - Latest version of Ubuntu
Reviews
This product doesn't have any reviews yet.
Compare similar products
One cable. One dock. Complex networking simplified. You can tell it’s special with just one glance. Three fully independent high speed Ethernet ports. Four Thunderbolt 5 and four USB ports. The Thunderbolt 5 Dual 10GbE Network Dock is the first all-in-one solution that simplifies complex multi-network workflows and unlocks high- bandwidth network storage connectivity while offering everyday docking convenience. Whether handling audio production with Dante, routing 4K NDI video streams for broadcast, outputting large high-res files to NAS storage, or administering a cluster of virtual machines in the cloud, it can all be done through this one dock via a single cable connection to a Thunderbolt equipped Mac or PC.
