PAC - Radio Replacement and Steering Wheel Control Interface with OnStar Retention for Select GM Vehicles - Blue
More Buying Options
About This Item
- General
- Brand: PAC
- Model Number: RP5-GM31
- Product Name: Radio Replacement and Steering Wheel Control Interface with OnStar Retention for Select GM Vehicles
- Color: Blue
- Compatibility
- Vehicle Compatibility: Select General Motors vehicles equipped with 29-bit LAN radios
- Product Compatibility: Camera
- Product Type: Interface
- Dimensions
- Product Height: 0.5 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Length: 2 inches (The out of box length of the item. Length is measured as the longest dimension of the item.)
- Product Width: 5 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Weight: 0.3 pounds (The out of box weight of the item.)
- Warranty
- Warranty - Parts: 1 year
- Warranty - Labor: None
- Other
- UPC: 606523109246
Easily replace the factory radio in your GM vehicle with this all-in-one Radio Replacement and Steering Wheel Control Interface with OnStar Retention by PAC. The RadioPRO5 RP5-GM31 interface comes pre-loaded with amplifier and OnStar retention, steering wheel control software, navigation-based output signals and more to help simplify aftermarket radio installation while retaining your vehicle’s factory features. Antenna adapter not included.
- Compatible with select General Motors vehicles: Including 2008-2017 Buick Enclave, 2006-2011 Buick Lucerne, 2006-2010 Cadillac DTS, 2007-2014 Cadillac Escalade, 2007-2014 Cadillac Escalade ESV, 2007-2014 Cadillac Escalade EXT, 2007-2009 Cadillac SRX and 2007-2013 Chevrolet Avalanche models.
- Designed for use with 29-bit LAN radios: Retains pre-programmed steering wheel controls, rear seat audio controls, dual zone function, factory satellite radio, and factory Bluetooth (in 2009+ models).
- Keeps OnStar: And OnStar functions when replacing the factory radio.
- Retains factory safety features: Including back-up sensors, park assist and back-up camera signal. Also includes a chime module with volume adjustment to retain all warning chimes.
- Provides data-controlled accessory and navigation outputs: Including retained accessory power (RAP), vehicle speed sensor (VSS), illumination, reverse trigger and parking brake to help ensure efficient operation.
- Preserve your vehicle’s factory amplified audio system: For quality sound in vehicles equipped with BOSE and premium BOSE audio systems. Also works with non-amplified audio systems.
- Compatible with select General Motors vehicles: Including 2008-2017 Buick Enclave, 2006-2011 Buick Lucerne, 2006-2010 Cadillac DTS, 2007-2014 Cadillac Escalade, 2007-2014 Cadillac Escalade ESV, 2007-2014 Cadillac Escalade EXT, 2007-2009 Cadillac SRX and 2007-2013 Chevrolet Avalanche models.
- Designed for use with 29-bit LAN radios: Retains pre-programmed steering wheel controls, rear seat audio controls, dual zone function, factory satellite radio, and factory Bluetooth (in 2009+ models).
- Keeps OnStar: And OnStar functions when replacing the factory radio.
- Retains factory safety features: Including back-up sensors, park assist and back-up camera signal. Also includes a chime module with volume adjustment to retain all warning chimes.
- Provides data-controlled accessory and navigation outputs: Including retained accessory power (RAP), vehicle speed sensor (VSS), illumination, reverse trigger and parking brake to help ensure efficient operation.
- Preserve your vehicle’s factory amplified audio system: For quality sound in vehicles equipped with BOSE and premium BOSE audio systems. Also works with non-amplified audio systems.
Q: How does this interface help with installation in vehicles with OnStar?
A: This radio replacement interface is designed to keep OnStar and its functions operational even after replacing the factory radio.
Q: What additional outputs does this interface provide?
A: This interface provides data-controlled accessory and navigation outputs including retained accessory power (RAP), vehicle speed sensor (VSS), illumination, reverse trigger and parking brake.
Q: What safety features are retained when using this interface?
A: This interface retains factory safety features including back-up sensors, park assist and back-up camera signal.
Q: Why is this radio replacement interface useful?
A: This all-in-one interface simplifies aftermarket radio installation while retaining your vehicle's factory features.
Q: Does this radio replacement interface work with vehicles that have amplified audio systems?
A: Yes, it preserves your vehicle's factory amplified audio system, including those with BOSE and premium BOSE audio systems. It also works with non-amplified audio systems.
Q: What type of radios is this interface designed for?
A: This interface is designed for use with 29-bit LAN radios.
Q: Do i need a parking brake bypass ?
A: If you want to avoid having to be in Park to access the settings, just crimp the parking brake wire (color codes included) to your 12V switched from your ignition. The receiver will think you're always in park, and all settings will be accessible.
Q: Does this retain Bose system speakers to work on install with nothing else needed?
A: Yes you can use the original Bose system with this. Please read the instructions when installing it. The part has two options where to plug harness into. 1) amplified 2) non amplified. The sound between the two is a big difference.
