Rotel - A10MKII 50W 2-Ch Integrated Stereo Amplifier - Silver
Color
SilverRelated Item
Specifications
- Continuous Watts x Channel @ Ohms50 Watts x 2 @ 8 OhmsNumber of Channels2Number of Audio Zones1Audio Only Inputs1 x Phono, Unbalanced RCANetwork Connector(s)No network connectorsPreamp OutputsNo
- Key Specs
- Continuous Watts x Channel @ Ohms: 50 Watts x 2 @ 8 Ohms
- Number of Channels: 2 (The number of discrete channels of sound output. This can be a single number or multiple numbers separated by decimal(s). The first number is the primary, horizontally directed audio channels. The number after the first decimal, if applicable, is the number of subwoofer outputs or channels. The number after the second decimal, if applicable, is the number of height or atmospheric channels designed to immerse the listener by producing overhead sound effects.)
- Number of Audio Zones: 1 (Audio zones, typically designated by rooms in a home, are areas in which all speakers are dependent on the same sound source. Whether a zone encompasses one or multiple rooms, the receiver or preamp/processor is used to control all aspects of its audio and is able to select which zones receive sound.)
- Audio Only Inputs: 1 x Phono, Unbalanced RCA
- Network Connector(s): No network connectors
- Preamp Outputs: false
- General
- Brand: Rotel
- Model Number: A10MKII Silver
- Product Name: A10MKII 50W 2-Ch Integrated Stereo Amplifier
- Color: Silver
- Audio
- Continuous Watts x Channel @ Ohms: 50 Watts x 2 @ 8 Ohms
- Maximum Watts x Channel @ Ohms: 60 Watts x 2 @ 4 Ohms (This is the maximum load the speaker, subwoofer or amp can drive.)
- Total Power Handling: 60 watts (How much amplifier (amplified) power (wattage) that can be handled before damaging the product.)
- Number of Channels: 2 (The number of discrete channels of sound output. This can be a single number or multiple numbers separated by decimal(s). The first number is the primary, horizontally directed audio channels. The number after the first decimal, if applicable, is the number of subwoofer outputs or channels. The number after the second decimal, if applicable, is the number of height or atmospheric channels designed to immerse the listener by producing overhead sound effects.)
- Number of Audio Zones: 1 (Audio zones, typically designated by rooms in a home, are areas in which all speakers are dependent on the same sound source. Whether a zone encompasses one or multiple rooms, the receiver or preamp/processor is used to control all aspects of its audio and is able to select which zones receive sound.)
- Minimum Frequency Response: 10 hertz (Describes the maximum range of frequencies or musical tones a product can reproduce, from very low tones to very high treble tones. The minimum frequency or musical tone the speaker can reproduce. High treble tones have higher frequencies while low tones and deep bass have lower frequencies.)
- Total Harmonic Distortion: 0.03 percent (Measurement of the harmonic sound distortion. The lower the percentage, the cleaner the sound.)
- Maximum Frequency Response: 100 kilohertz (Describes the maximum range of frequencies or musical tones a product can reproduce, from very low tones to very high treble tones. The maximum frequency or musical tone the speaker can reproduce. High treble tones have higher frequencies while low tones and deep bass have lower frequencies.)
- Amplifier Class: AB (An amplifier's mode of operation, specifically the conditions in which its electrical current flows for the duration of an audio signal, determines its class. Each class has its strengths and weaknesses when it comes to power efficiency, levels of crossover distortion, and overall sound quality.)
- Amplifier Type: Integrated amplifiers
- Signal-to-Noise Ratio (SNR): 90 decibels (The ratio of the desired signal's strength to the level of background noise. A ratio higher than 1:1, which equates to greater than 0 decibels, indicates more signal than noise.)
- Sensitivity: 1.5 decibels
- Bass Boost: Variable (Circuitry that boosts the bass response of the amplifier, improving audio reproduction enhancing the sound of low frequencies. Fixed boost means the level of bass response is preset, whereas variable boost allows the user to make adjustments.)
- Audio
- Impedance: 8 (Describes the resistance of an electric signal throughout the system. Devices with low impedance require less power to deliver optimal signals but are more at risk for damage from overloading. Higher impedance requires more power but is more protected from overload damage.)
- Inputs
- Audio Only Inputs: 1 x Phono, Unbalanced RCA
- Video Only Inputs: No video only inputs (The number and type of video signal only inputs the product has.)
- Network Connector(s): No network connectors
- Speaker-Level Inputs: false (Also referred to as high-level inputs. Enables the amplifier to receive a sound signal from another device that does not have RCA, or low-level, inputs.)
- Line-Level Inputs: true (Also referred to as low-level inputs. Enables the amplifier to receive a sound signal from another device via RCA cables.)
- Outputs
- Preamp Outputs: false
- Speaker Connection Type: RCA
- Video Only Outputs: No video only outputs (The number and type of video signal only outputs the product has.)
- Features
- App Compatible: false (The product can be connected to a program or software application on a mobile device, which then receives collected data from the product.)
- Fan Cooled: false
- Connectivity
- Wireless Multi-Room Audio: false (Technology that allows multiple speakers and/or soundbars to be connected wirelessly and play audio in separate rooms.)
- Dimensions
- Product Height: 3 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 17 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 14 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Product Weight: 15 pounds (The out of box weight of the item.)
- Warranty
- Warranty - Parts: 5 years
- Warranty - Labor: 5 Years
- Other
- UPC: 672563760112
Discover the A10MKII Integrated Amplifier, where power meets style in perfect harmony. Delivering 50W per channel of Class A/B power into 8 ohms and featuring a Rotel-built toroidal transformer, it offers three RCA inputs and a Moving Magnet Phono stage, making it a must-have for vinyl enthusiasts and anyone seeking a powerful yet stylish audio solution.
- Class AB Amplification: Achieve powerful sound with Class AB amplification: 62W per channel at 4Ω and 50W per channel at 8Ω.
- Phono Input: Connect your turntable effortlessly with the Moving Magnet Phono input.
- Intuitive Operation and Setup: Simplified operation for all skill levels using the intuitive front panel controls and included IR remote control.
- Convenient IR Remote Control Included: Experience effortless control and seamless operation with the included IR remote control. This feature-packed remote provides source selection, volume control and power on/off and conveniently includes transport controls for Rotel CD Players.
- Class AB Amplification: Achieve powerful sound with Class AB amplification: 62W per channel at 4Ω and 50W per channel at 8Ω.
- Phono Input: Connect your turntable effortlessly with the Moving Magnet Phono input.
- Intuitive Operation and Setup: Simplified operation for all skill levels using the intuitive front panel controls and included IR remote control.
- Convenient IR Remote Control Included: Experience effortless control and seamless operation with the included IR remote control. This feature-packed remote provides source selection, volume control and power on/off and conveniently includes transport controls for Rotel CD Players.
Whats Included
- Rotel A10MKII Amplifier
- Power Cord
- Manual
- Remote
- Rotel A10MKII Amplifier
- Power Cord
- Manual
- Remote
Q: What is the amplifier's warranty period?
A: The amplifier's parts and labor warranty period is 5 years.
Q: Does the amplifier have a built-in phono stage?
A: This amplifier features a Moving Magnet Phono stage.
Q: What type of inputs does the amplifier have?
A: The A10 MKII amplifier features three RCA inputs and a Moving Magnet Phono stage.
Q: What is the amplifier's weight?
A: The amplifier's weight is 14.5 pounds.
Q: What are the amplifier's dimensions?
A: The amplifier has a depth of 13.64 inches, a height of 3 inches, and a width of 16.9 inches.
Q: What is the amplifier's power output per channel?
A: The amplifier delivers 50 watts per channel of Class A/B power into 8 ohms.
Q: What is the amplifier's total harmonic distortion?
A: The total harmonic distortion of the amplifier is 0.03 percent.
Q: I have a pair of OHM RS-9's that are 4 ohm. Will this work?
A: Hi Denny. I’ve been an audiophile hobbyist for almost 40 years and I can definitely help you with this question. Your Ohm RS-9 speakers that are rated at 4 ohms can definitely be powered by the Rotel A10mkii integrated amplifier. . The A10 is rated to put out 50 watts per channel into 8 ohms and 60 watts per channel into 4 ohms. The important consideration is the rated sensitivity of the RS-9 speakers are 89db. That will be the most useful specification to how they match up. I have a different set of speakers, Paradigm reference studio 20 speakers with the same 89db rating as your speakers. I hooked them up to the a10mkii and found that they worked fine for low to medium listening levels. My mom came in the room and with a song she liked asked me to turn up the volume slightly. Think of the loudest that you would want the TV turned up but can still talk over. The volume was turned up to 11 o clock position. As you go up in sensitivity rating by 3 decibels you double the volume. If you want more volume than medium level you should get a amplifier with at least 100 watts per channel. Even if you don’t play louder the increased power will power your speakers better at lower volumes with a cleaner, clearer, more transparent and open presentation instead of sounding more distant and subdued which is what mine sounded like trying both amplifiers. If you like a more subdued and layed back presentation and your only going to listen at moderate listening levels than the Rotel a10mkii is a good choice. I know this was a long answer but I hope it helps.
