Rotel - RAS-5000 220W 2-Ch Integrated Streaming Stereo Amplifier - Black
Specifications
- Continuous Watts x Channel @ Ohms140 Watts x 2 @ 8 OhmsNumber of Channels2Number of Audio Zones1Audio Only Inputs1 x USB-C, 1 x Phono, 1 x Optical digital audio, 1 x Coaxial digital audioPreamp OutputsYesWireless ConnectivityWi-Fi
- Key Specs
- Continuous Watts x Channel @ Ohms: 140 Watts x 2 @ 8 Ohms
- Number of Channels: 2 (The number of discrete channels of sound output. This can be a single number or multiple numbers separated by decimal(s). The first number is the primary, horizontally directed audio channels. The number after the first decimal, if applicable, is the number of subwoofer outputs or channels. The number after the second decimal, if applicable, is the number of height or atmospheric channels designed to immerse the listener by producing overhead sound effects.)
- Number of Audio Zones: 1 (Audio zones, typically designated by rooms in a home, are areas in which all speakers are dependent on the same sound source. Whether a zone encompasses one or multiple rooms, the receiver or preamp/processor is used to control all aspects of its audio and is able to select which zones receive sound.)
- Audio Only Inputs: 1 x USB-C, 1 x Phono, 1 x Optical digital audio, 1 x Coaxial digital audio
- Preamp Outputs: true
- Wireless Connectivity: Wi-Fi (The manner in which a device sends data to another device over a short distance without the use of wires or cables.)
- General
- Brand: Rotel
- Model Number: RAS-5000 - Black
- Product Name: RAS-5000 220W 2-Ch Integrated Streaming Stereo Amplifier
- Color: Black
- Audio
- Continuous Watts x Channel @ Ohms: 140 Watts x 2 @ 8 Ohms
- Maximum Watts x Channel @ Ohms: 220 Watts x 2 @ 4 Ohms (This is the maximum load the speaker, subwoofer or amp can drive.)
- Total Power Handling: 220 watts (How much amplifier (amplified) power (wattage) that can be handled before damaging the product.)
- Number of Channels: 2 (The number of discrete channels of sound output. This can be a single number or multiple numbers separated by decimal(s). The first number is the primary, horizontally directed audio channels. The number after the first decimal, if applicable, is the number of subwoofer outputs or channels. The number after the second decimal, if applicable, is the number of height or atmospheric channels designed to immerse the listener by producing overhead sound effects.)
- Number of Audio Zones: 1 (Audio zones, typically designated by rooms in a home, are areas in which all speakers are dependent on the same sound source. Whether a zone encompasses one or multiple rooms, the receiver or preamp/processor is used to control all aspects of its audio and is able to select which zones receive sound.)
- Minimum Frequency Response: 10 hertz (Describes the maximum range of frequencies or musical tones a product can reproduce, from very low tones to very high treble tones. The minimum frequency or musical tone the speaker can reproduce. High treble tones have higher frequencies while low tones and deep bass have lower frequencies.)
- Total Harmonic Distortion: 0.00030 percent (Measurement of the harmonic sound distortion. The lower the percentage, the cleaner the sound.)
- Maximum Frequency Response: 100 kilohertz (Describes the maximum range of frequencies or musical tones a product can reproduce, from very low tones to very high treble tones. The maximum frequency or musical tone the speaker can reproduce. High treble tones have higher frequencies while low tones and deep bass have lower frequencies.)
- Amplifier Class: AB (An amplifier's mode of operation, specifically the conditions in which its electrical current flows for the duration of an audio signal, determines its class. Each class has its strengths and weaknesses when it comes to power efficiency, levels of crossover distortion, and overall sound quality.)
- Amplifier Type: Integrated amplifiers
- Signal-to-Noise Ratio (SNR): 100 decibels (The ratio of the desired signal's strength to the level of background noise. A ratio higher than 1:1, which equates to greater than 0 decibels, indicates more signal than noise.)
- Bass Boost: None (Circuitry that boosts the bass response of the amplifier, improving audio reproduction enhancing the sound of low frequencies. Fixed boost means the level of bass response is preset, whereas variable boost allows the user to make adjustments.)
- Inputs
- Audio Only Inputs: 1 x USB-C, 1 x Phono, 1 x Optical digital audio, 1 x Coaxial digital audio
- Audio/Video Inputs: 1 x HDMI (The number and type of HDMI inputs the product has.)
- Speaker-Level Inputs: false (Also referred to as high-level inputs. Enables the amplifier to receive a sound signal from another device that does not have RCA, or low-level, inputs.)
- Line-Level Inputs: true (Also referred to as low-level inputs. Enables the amplifier to receive a sound signal from another device via RCA cables.)
- Outputs
- Preamp Outputs: true
- Speaker Connection Type: RCA
- Features
- App Compatible: true (The product can be connected to a program or software application on a mobile device, which then receives collected data from the product.)
- Fan Cooled: false
- Bridgeable: false (Bridging an amplifier increases the power it supplies to the speaker(s).)
- Connectivity
- Wireless Multi-Room Audio: true (Technology that allows multiple speakers and/or soundbars to be connected wirelessly and play audio in separate rooms.)
- Wireless Multi-Room Technology: Apple AirPlay 2, Google Cast (Proprietary technology that allows multiple speakers and/or soundbars to be connected wirelessly and play audio in separate rooms.)
- Wireless Connectivity: Wi-Fi (The manner in which a device sends data to another device over a short distance without the use of wires or cables.)
- Dimensions
- Product Height: 5.66 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 16.97 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 16.74 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Product Weight: 34.6 pounds (The out of box weight of the item.)
- Other
- UPC: 672563281112
Experience the perfect blend of simplicity and performance with the Rotel RAS-5000, designed to seamlessly fit into your lifestyle and elevate your entertainment journey. Immerse yourself in your favorite music from Spotify Connect, Tidal Connect, Internet Radio, or any service available on your computer, tablet, or mobile device via Airplay 2, Google Cast, Roon, or aptX HD Bluetooth. With HDMI ARC, enjoy breathtaking sound quality while watching live sports, TV shows, movies, or gaming, all powered by 220 watts of Class AB output into 4 ohms. It's the ultimate enhancement for your home entertainment, delivering uncompromised audio quality. Welcome the Rotel RAS-5000 into your world and let the sound immerse you in an unforgettable experience.
- Class AB Amplification: Harness the commanding force of Class AB Amplification, packing a punch with 220 watts of Class AB output into 4 ohms. Experience a new dimension of powerful sound that redefines your entertainment journey.
- Streaming Audio: Embrace the power to stream your favorite music from a plethora of options, including Spotify Connect, Tidal Connect, Airplay 2, Google Cast, Roon Ready, aptXTM HD Bluetooth, and more. It's your music, your way, all effortlessly accessible from the comfort of your device.
- Support HDMI eARC function: Indulge in breathtaking sound quality when watching live sports, TV shows, movies, or gaming with HDMI eARC support. Allow the Rotel RAS-5000 to provide the immersive audio you desire, reshaping your home entertainment.
Whats Included
- Rotel RAS-5000 Integrated Amplifier
- Remote
- Power Cord
- Manual
