Thermador - Star Sapphire 24" Top Control Smart Built-In Stainless Steel Tub Dishwasher with 3rd Rack and Interior Light, 42 dBA - Custom Panel Ready
Need-haul away?
- We’ll haul away your old item and make sure it’s properly and safely recycled.
- We can also move it to another location in your home if the path is clear of obstructions.
- We can’t remove doors from your home (or a product) to make an item fit through a doorway
- Relocated appliances will not be connected to utilities
Related Item
Specifications
- Color FinishCustomProduct Height33 7/8 inchesProduct Width23 9/16 inchesProduct Depth23 3/4 inchesOperating Sound Level42 decibels adjustedNumber Of Racks3
- Key Specs
- Color Finish: Custom
- Product Height: 33 7/8 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 23 9/16 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 23 3/4 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Operating Sound Level: 42 decibels adjusted (Today's appliances are pretty quiet. To get a sense for how quiet you'll need, think about having a conversation in the same room. Choose from Not as Quiet (56 dBA or higher. You'll likely need to raise your voice); Quiet (50-55 dBA. Need to raise your voice slightly); Very Quiet (43-49 dBA. Easily have a conversation right next the appliance); and Nearly Silent (42 dBA or lower. You'll hardly know the appliance is on).)
- Number Of Racks: 3
- Tub Finish: Stainless steel (Certain coatings or materials on the inside of the dishwasher, such as stainless steel, are more durable, retain heat better, and can withstand higher temperatures than materials such as plastic. These higher quality materials may increase the appliance’s efficiency, but there may be also be extra initial cost. Some models marketed as Hybrid will use both materials in the tub, often using stainless steel on the interior door to increase durability on the part of the appliance with the most common wear and tear.)
- Place Setting Capacity: 16 (A basic place setting typically consists of a dinner plate, side plate, drinking glass, cutlery, and optional soup bowl and coffee cup. Full-size dishwashers typically hold 12-16 place settings. This does not include pots, pans, or other cookware.)
- App Compatible: false (The product can be connected to a program or software application on a mobile device, which then receives collected data from the product.)
- Works With: Amazon Alexa, Google Home, SmartThings (Compatible with or able to be connected to other smart devices or applications.)
- General
- Brand: Thermador
- Model Number: DWHD661EPR
- Product Name: Star Sapphire 24" Top Control Smart Built-In Stainless Steel Tub Dishwasher with 3rd Rack and Interior Light, 42 dBA
- Color: Custom Panel Ready
- Color Finish: Custom
- Dimensions
- Product Height: 33 7/8 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 23 9/16 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 23 3/4 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Depth Without Handle: 22 9/16 inches (Measurement from the back of the product to its front (with door closed), not including handle.)
- Depth With Handle: 23 3/4 inches (Measurement from the back of the product to its front (with door closed), including the handle.)
- Depth With Door Open: 47 inches (Measurement from the back of the product to its front, with door fully open.)
- Product Weight: 103 pounds (The out of box weight of the item.)
- Cut-Out Dimensions
- Cut-Out Height: 33 7/8 inches (Minimum required height of the installation location for a standard installation of the product. This measurement will help you determine if the appliance will fit into the desired space and have the clearance necessary for proper operational use. Please refer to the manufacturer’s installation documentation for detailed measurement requirements.)
- Cut-Out Width: 24 inches (Minimum required width of the installation location for a standard installation of the product. This measurement will help you determine if the appliance will fit into the desired space and have the clearance necessary for proper operational use. Please refer to the manufacturer’s installation documentation for detailed measurement requirements.)
- Cut-Out Depth: 24 inches (Minimum required depth of the installation location for a standard installation of the product. This measurement will help you determine if the appliance will fit into the desired space and have the clearance necessary for proper operational use. Please refer to the manufacturer’s installation documentation for detailed measurement requirements.)
- Features
- Hard Food Disposer: false (This feature has blades to chop and disintegrate hard food particles, making them small enough to easily drain away. This prevents them from being recirculated back onto dishware and allows for easy maintenance.)
- Drying Method: Heated drying (Appliances that use heat to dry the dishes will include a heating element or minerals which transform moisture into heat. A fan or vent then circulates the hot dry air throughout the tub during the drying cycle. This may reduce drying time and the risk of water spots. Appliances that use minerals to produce heat are considered more energy efficient than those that include a heating element. Appliances that use condensation drying are considered more energy efficient than those that use heated drying. Instead, high temperature water is produced during the final rinse cycle which warms the interior and eventually condensates and drains out of the machine.)
- Operating Sound Level: 42 decibels adjusted (Today's appliances are pretty quiet. To get a sense for how quiet you'll need, think about having a conversation in the same room. Choose from Not as Quiet (56 dBA or higher. You'll likely need to raise your voice); Quiet (50-55 dBA. Need to raise your voice slightly); Very Quiet (43-49 dBA. Easily have a conversation right next the appliance); and Nearly Silent (42 dBA or lower. You'll hardly know the appliance is on).)
- Delay Start: true (Allows you to program the appliance to automatically run at a later time. This feature helps you coordinate with your household’s water needs, noise preferences, and more. Additionally, operating your appliance during off-peak hours may reduce energy costs.)
- End-Of-Cycle Signal: true (An audible alert and/or visual indicator that notifies you when a pre-selected cycle is complete.)
- Cycle Status Lights: true (Lights on the control panel that indicate which cycle is in use and/or its current status. Know when to unload with a simple glance.)
- Child Lock: false (Setting that allows appliance to be temporarily locked to prevent use.)
- Filtered Water: true (Internal water filter(s) remove minerals and chemicals from hard water before the wash cycle. Filtered water is less likely to leave mineral deposits or stains, meaning your dishware will look cleaner for longer.)
- Water Soil Sensor: true (Feature that measures how dirty the water is throughout the wash cycle and adjusts the energy and water usage as needed. This can increase washing efficiency and may reduce energy costs.)
- Wireless Connectivity: Wi-Fi (The manner in which a device sends data to another device over a short distance without the use of wires or cables.)
- Cycle
- Number of Cycles: 8 (Standard dishwashers have at least 3 cycles, each with different water pressure, speed, and temperature settings designed for particular loads.)
- Dishwasher Cycles: 8
- Options and Programs: Heavy, Auto, Normal, Speed60 (1hr Wash), Favorite, Delicate, Rinse, MachineCare
- Sensor Wash: true (Feature that automatically senses the load's soil levels and adjusts the wash cycle as needed. This often results in reduced water usage, which in turn may reduce energy costs.)
- Steam Cleaning: false (Wash cycle that primarily uses steam to loosen food debris and clean fragile dishware without force.)
- Steam Pre-Wash: false (Loosens food debris by creating steam inside the washer before the primary wash cycle, allowing for an easier, gentler clean of dishware.)
- NSF-Certified Sanitization Cycle: true (Meets the National Sanitation Foundation (NSF) standards for performance and cleaning effectiveness. When operated on the sanitizing cycle, an NSF-Certified dishwasher reaches a final rinse temperature of 150⁰ Fahrenheit and achieves a minimum 99.999% percent reduction of bacteria.)
- Water Consumption Per Cycle: 3.2 gallons (Estimated amount of water used during a standard wash cycle. Most standard-size dishwashers today use an average of 3-6 gallons.)
- Rack Features
- Number Of Racks: 3
- Third Rack Features: Removable, Utensil separator (Aspects of third rack designed for better dishware organization, cleaning, and usability, such as adjustable height and tines, utensils separator, and utility basket.)
- Upper Rack Features: Adjustable height, Adjustable tines (Aspects of upper rack designed for better dishware organization, cleaning, and usability, such as adjustable height and tines, cup clips, and stemware holders.)
- Lower Rack Features: Silverware basket, Removable silverware basket (Aspects of lower rack designed for better dishware organization, cleaning, and usability, such as adjustable height and tines, utensils separator, and utility basket.)
- Rack Material: Nylon
- Design
- Panel Ready: true (Product is ready to be fit with a customized front panel that integrates with existing cabinetry and décor.)
- Panel(s) Included: false
- Dishwasher Type: Built-in dishwashers
- Tub Finish: Stainless steel (Certain coatings or materials on the inside of the dishwasher, such as stainless steel, are more durable, retain heat better, and can withstand higher temperatures than materials such as plastic. These higher quality materials may increase the appliance’s efficiency, but there may be also be extra initial cost. Some models marketed as Hybrid will use both materials in the tub, often using stainless steel on the interior door to increase durability on the part of the appliance with the most common wear and tear.)
- Control Type: Touchpad
- Control Location: Top control
- Display Type: LCD
- Handle Type: No handle - push to open
- Fingerprint Resistant: false
- Place Setting Capacity: 16 (A basic place setting typically consists of a dinner plate, side plate, drinking glass, cutlery, and optional soup bowl and coffee cup. Full-size dishwashers typically hold 12-16 place settings. This does not include pots, pans, or other cookware.)
- Included
- Power Cord Included: false (Connects your product to an electrical outlet, allowing for immediate use (provided that other installation requirements are met).)
- Integrated Water-Softener: false (A built-in water softener that automatically filters minerals from hard water to clean your dishes, reducing clouding, streaks, hard-water stains, or mineral deposit build-up.)
- Electrical
- Estimated Annual Electricity Use: 240 kilowatt hours (Predicted amount of electricity needed to operate the product under average conditions for one year.)
- Estimated Annual Operating Cost: 34 United States dollars (Predicted cost of operating the product under average conditions for one year.)
- Amperage: 12 amperes (Strength of electrical current.)
- Voltage: 240 volts (Amount of power needed to support an electrical current.)
- Wattage: 1440 watts (Measurement of electrical power.)
- Certifications Listings & Approvals
- ENERGY STAR Certified: true (Devices carrying the ENERGY STAR service mark, such as computer products and peripherals, kitchen appliances, and other products, generally use 20% to 30% less energy than required by federal standards.)
- ADA Compliant: true (Meets standards set by the Disabilities Act (ADA) Standards for Accessible Design)
- Consortium for Energy Efficiency (CEE) Rating: CEE Tier 1
- Warranty
- Warranty - Parts: 1 year limited
- Warranty - Labor: 1 year limited
- Compatibility
- Works With: Amazon Alexa, Google Home, SmartThings (Compatible with or able to be connected to other smart devices or applications.)
- Other
- UPC: 825225971498
Elevate your style to radiant with the Star Sapphire dishwasher that delivers an impressively quiet performance at 42 dBA, with an absolutely unparalleled flexibility featuring an adjustable chef’s tool drawer, and folding glass care rack that can accommodate to 18 wine glasses at once. Customize your cleaning power with the Zone Control Spray Arm to deep clean the most challenging dishes, no matter where you place them. With exclusive features like StarDry and Multi-color Star Glow for an effortless cleanup. Push-to-Open opens the door with either a push or pull for easy loading and unloading. Easily fit up to 16 place settings in the dishwasher and select from up to 9 wash cycles to achieve the perfect clean. Refine your cleanup routine with remote start and timely notifications that keep track of every dish tab when paired with the Home Connect App. Energy Star Certified to help you save water and energy.
- Custom Panel Ready: Matches your kitchen’s custom cabinetry to our dishwasher for complete integration.
- Customize Your Cleaning Power with Zone Control: Design the ideal clean with Zone Control. Specify up to 4 customized lower rack cleaning zones in the Home Connect app, ensuring the most challenging pieces emerge immaculate and the most delicate are protected.
- StarDry with Zeolite: Introducing StarDry with Zeolite, an exclusive Thermador drying solution. Zeolite is a natural substance that dries without the use of chemicals. This unique feature helps dry hard to reach crevices, and does not need to be replenished over time.
- Powerfully Quiet 42 dBA: Powerfully Quiet: enjoy a signature cleaning cycle at 42 dBA, perfect for after-dinner conversation.
- Spacious Adjustable Chef’s Tool Drawer: Adjustable Chef’s Tool Drawer delivers added loading capacity as well as flexibility to accommodate larger or smaller items in this additional third rack.
- Folding Glass Care Rack: Allowing you to wash up to 18 wine glasses at once. Securely wash your most delicate stems while accommodating every entertaining occasion.
- Multi-color Star Glow Light: Multi-color Star Glow Light illuminates dishes and glassware with an internal colorful light.
- Time Remaining PowerBeam countdown on floor: Time Remaining PowerBeam: shines a countdown of the remaining time of the cycle on the floor.
- Monitor and control your appliance with Home Connect: Wi-Fi-Enabled Dishwasher allows you to monitor and control your appliance remotely, via the Home Connect app, works with smart home devices and services like Amazon Alexa.
- Flexible Folding Tines accommodate larger items: Flexible Folding Tines fold down to accommodate larger pots, pans, and dishes.
- Crystal Protection System is perfect for fine crystal: The Crystal Protect Water Softener System utilizes a built-in water softener to neutralize water hardness, making it safe to wash crystal with sparkling results.
- 6+3 Cycles Available in Home Connect: Dishwasher Cycles: Auto, Normal, Quick, Hand Wash, Pots & Pans and Favorite . Available in the Home Connect App: Machine Care, Rinse, Glass
- 6+1 Options Available in Home Connect: Dishwasher Cycle Options: StarDry, Sanitize, Remote Start . Available in the Home Connect App: Save Time
- Smart Cycle: Customized dishwasher cycle suggestions to meet your needs in the Home Connect app.
- Push to Open for easy loading and unloading: Push to Open opens the door with either a push or pull, so loading is easier, even when your hands are full. Allows for a handle-less sleek custom panel design.
- Accommodates up to 16 place settings: Generous interior space means more clean dishes, fewer loads.
- 3-level adjustable upper rack: Adjust the height of the upper rack for flexibility to accommodate various sized items.
- Powerful cleaning and sanitizing performance for everyday dish care: Includes NSF Sanitization.
- Stainless Steel Tub: Premium design for a sleek kitchen.
- LED Display with Touch Controls: LED Display for easy controls.
- Ball Bearing Wheels provide an ultra-smooth glide: Racks glide in and out of the appliance with ease.
- Energy Star: Energy Star Certified
- Custom Panel Ready: Matches your kitchen’s custom cabinetry to our dishwasher for complete integration.
- Customize Your Cleaning Power with Zone Control: Design the ideal clean with Zone Control. Specify up to 4 customized lower rack cleaning zones in the Home Connect app, ensuring the most challenging pieces emerge immaculate and the most delicate are protected.
- StarDry with Zeolite: Introducing StarDry with Zeolite, an exclusive Thermador drying solution. Zeolite is a natural substance that dries without the use of chemicals. This unique feature helps dry hard to reach crevices, and does not need to be replenished over time.
- Powerfully Quiet 42 dBA: Powerfully Quiet: enjoy a signature cleaning cycle at 42 dBA, perfect for after-dinner conversation.
- Spacious Adjustable Chef’s Tool Drawer: Adjustable Chef’s Tool Drawer delivers added loading capacity as well as flexibility to accommodate larger or smaller items in this additional third rack.
- Folding Glass Care Rack: Allowing you to wash up to 18 wine glasses at once. Securely wash your most delicate stems while accommodating every entertaining occasion.
- Multi-color Star Glow Light: Multi-color Star Glow Light illuminates dishes and glassware with an internal colorful light.
- Time Remaining PowerBeam countdown on floor: Time Remaining PowerBeam: shines a countdown of the remaining time of the cycle on the floor.
- Monitor and control your appliance with Home Connect: Wi-Fi-Enabled Dishwasher allows you to monitor and control your appliance remotely, via the Home Connect app, works with smart home devices and services like Amazon Alexa.
- Flexible Folding Tines accommodate larger items: Flexible Folding Tines fold down to accommodate larger pots, pans, and dishes.
- Crystal Protection System is perfect for fine crystal: The Crystal Protect Water Softener System utilizes a built-in water softener to neutralize water hardness, making it safe to wash crystal with sparkling results.
- 6+3 Cycles Available in Home Connect: Dishwasher Cycles: Auto, Normal, Quick, Hand Wash, Pots & Pans and Favorite . Available in the Home Connect App: Machine Care, Rinse, Glass
- 6+1 Options Available in Home Connect: Dishwasher Cycle Options: StarDry, Sanitize, Remote Start . Available in the Home Connect App: Save Time
- Smart Cycle: Customized dishwasher cycle suggestions to meet your needs in the Home Connect app.
- Push to Open for easy loading and unloading: Push to Open opens the door with either a push or pull, so loading is easier, even when your hands are full. Allows for a handle-less sleek custom panel design.
- Accommodates up to 16 place settings: Generous interior space means more clean dishes, fewer loads.
- 3-level adjustable upper rack: Adjust the height of the upper rack for flexibility to accommodate various sized items.
- Powerful cleaning and sanitizing performance for everyday dish care: Includes NSF Sanitization.
- Stainless Steel Tub: Premium design for a sleek kitchen.
- LED Display with Touch Controls: LED Display for easy controls.
- Ball Bearing Wheels provide an ultra-smooth glide: Racks glide in and out of the appliance with ease.
- Energy Star: Energy Star Certified
Whats Included
- Sapphire 24" Top Control Dishwasher
- Owner's Manual
- Sapphire 24" Top Control Dishwasher
- Owner's Manual
Product Manuals
Documents
- Energy_Guide_PDF
- Energy_Guide_PDF
Q: What type of drying method does the dishwasher use?
A: The drying method for this dishwasher is heated drying.
Q: Does the dishwasher have a third rack?
A: This dishwasher has three racks.
Q: What is the capacity of the dishwasher?
A: This dishwasher has a capacity of 16 place settings.
Q: What is the noise level of the dishwasher?
A: This dishwasher boasts an impressively quiet performance at only 42 decibels.
Q: Can the dishwasher be controlled remotely?
A: This dishwasher can be controlled remotely when paired with the Home Connect App.
