Wavtech - link500.4mini - 500 Watt 4-Channel Amplifier - Black/Gray
Specifications
- Amplifier ClassDNumber Of Channels4Bass BoostVariable
- Key Specs
- Amplifier Class: D (An amplifier's mode of operation, specifically the conditions in which its electrical current flows for the duration of an audio signal, determines its class. Each class has its strengths and weaknesses when it comes to power efficiency, levels of crossover distortion, and overall sound quality.)
- Number Of Channels: 4
- Bass Boost: Variable (Circuitry that boosts the bass response of the amplifier, improving audio reproduction enhancing the sound of low frequencies. Fixed boost means the level of bass response is preset, whereas variable boost allows the user to make adjustments.)
- General
- Brand: Wavtech
- Model Number: link500.4mini
- Product Name: Wavtech link500.4mini - 500 Watt 4-Channel Amplifier
- Color: Black/Gray
- Audio Power
- Total Power Handling RMS: 500 watts
- Total Power Handling Maximum: 1000 watts
- Amplifier Class: D (An amplifier's mode of operation, specifically the conditions in which its electrical current flows for the duration of an audio signal, determines its class. Each class has its strengths and weaknesses when it comes to power efficiency, levels of crossover distortion, and overall sound quality.)
- Audio
- Number Of Channels: 4
- Bass Boost: Variable (Circuitry that boosts the bass response of the amplifier, improving audio reproduction enhancing the sound of low frequencies. Fixed boost means the level of bass response is preset, whereas variable boost allows the user to make adjustments.)
- Features
- Bluetooth Enabled: false (The device is capable of communicating with another device via Bluetooth, provided they are within the required range of each other. A Bluetooth-enabled device must also be the same Bluetooth version or higher than the accessory it is intended to pair with.)
- Marine: false
- Dimensions
- Product Height: 9.000 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 1.650 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 4.500 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Product Weight: 1.0 pounds (The out of box weight of the item.)
- Warranty
- Warranty - Parts: 1-Year Manufacturer Warranty
- Warranty - Labor: None
- Other
- UPC: 700987201475
A pair of new front speakers and a subwoofer is one of the most common aftermarket audio upgrades. The link500.4mini is the perfect amplifier for this application. When used in 3-channel mode, the amplifier can produce 125 watts x 2 for the main speakers and 250 watts x 1 for the subwoofer, so it won’t lack for power. Speaking of the subwoofer, channels 3/4 have a 1-band PEQ, a subsonic filter and the ability to add an RLC to fine tune the subwoofers performance. The link500.4mini has our new adaptive loading technology plus the ability to handle up to 40V of hi-level input. It also has fully adjustable high and low pass crossovers. For factory audio systems where no full-range signal is present, the link500.4mini has built-in summing, so it can handle that internally, without the need for an outboard processor. Like all Wāvtech amplifiers, the link500.4mini is start/stop system compatible. link500.4mini Features 500 Watt 4-Channel Amplifier 75 watts x 4 @ 4 ohms 125 watts x 4 @ 2 ohms 250 watts x 2 @ 4 ohms BTL Small Footprint Only 9”x4.5”x1.65” Adjustable Paragraphic EQ (Channels 3/4) Variable Subsonic Filter (Channels 3/4) Variable Hi/Low Pass Crossover (-12dB/oct) Remote Level Control (RLC) w/Optional linkRC (CH 3/4) Built-In Summing w/Level Trim Adjsutment Start/Stop Sytem Compatiable Differential Balanced Inputs Variable Gain Adjustment w/Clip LED Auto Turn-On via DC-Offset or Audio Signal Detect Adaptive OEM Load Technology Locking Detachable Hi-Level Speaker Terminals Professional Grade Panel Mount RCA’s Compact Aluminum Chassis w/Detachable Mounting tabs link500.4mini Specifications Input Sensitivity SPK: 1-20Vrms, 2-40Vrms RCA: 0.2V-5Vrms, 0.4V-10Vrms Max Input Voltage (SPK): 40Vrms Frequency Response: 43kHz (+0/-3dB) THD+N: <1% at rated power S/N: >78dBA (1W, 4Ω)
- Key Feature: Amplifier can produce 125 watts x 2 for the main speakers and 250 watts x 1 for the subwoofer
- Key Feature: Channels 3/4 have a 1-band PEQ, a subsonic filter and the ability to add an RLC to fine tune the subwoofers performance
- Key Feature: New adaptive loading technology plus the ability to handle up to 40V of hi-level input
- Key Feature: Auto Turn-On via DC-Offset or Audio Signal Detect
- Key Feature: Locking Detachable Hi-Level Speaker Terminals
- Key Feature: Amplifier can produce 125 watts x 2 for the main speakers and 250 watts x 1 for the subwoofer
- Key Feature: Channels 3/4 have a 1-band PEQ, a subsonic filter and the ability to add an RLC to fine tune the subwoofers performance
- Key Feature: New adaptive loading technology plus the ability to handle up to 40V of hi-level input
- Key Feature: Auto Turn-On via DC-Offset or Audio Signal Detect
- Key Feature: Locking Detachable Hi-Level Speaker Terminals
Whats Included
- Wavtech link500.4mini - 500 Watt 4-Channel Amplifier
- Wavtech link500.4mini - 500 Watt 4-Channel Amplifier
