Zephyr - 48 inches - Externally Vented & Externally Vented - Range Hood Insert - Stainless Steel
Need-haul away?
- We can also move it to another location in your home if the path is clear of obstructions.
- We can’t remove doors from your home (or a product) to make an item fit through a doorway
- Relocated appliances will not be connected to utilities
Related Item
Specifications
- Product Height12 inchesProduct Width46.375 inchesProduct Depth22.5 inchesExhaust Vent LocationTop/RearVent TypeDuctedVent StyleExternal, External
- Key Specs
- Product Height: 12 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 46.375 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 22.5 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Exhaust Vent Location: Top/Rear
- Vent Type: Ducted
- Vent Style: External, External (External vents pull air from the room and move it directly outside through a dedicated duct system. Recirculating vents pull the air through a filter so that it can be cleaned before being recycled back into the room. Convertible vents can be reconfigured from external ventilation to recirculating via installation of certain parts.)
- General
- Brand: Zephyr
- Model Number: AK9346CS
- Product Name: Monsoon II 48 in. 650 CFM Insert Mount Range Hood with LED Light
- Color: Stainless Steel
- Dimensions
- Product Height: 12 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Minimum Installation Height Above Cooktop: 26 inches
- Maximum Installation Height Above Cooktop: 36 inches
- Product Width: 46.375 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 22.5 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Standardized Width: 48 inches (An approximated measurement (exact width may differ slightly) determined by the manufacturer in accordance with industry standards. Standardized sizes are intended to assist consumers when purchasing appliances and planning for installation.)
- Product Weight: 54.5 pounds (The out of box weight of the item.)
- Duct Shape: Round
- Cut-Out Dimensions
- Cut-Out Width: 46.625 inches (Minimum required width of the installation location for a standard installation of the product. This measurement will help you determine if the appliance will fit into the desired space and have the clearance necessary for proper operational use. Please refer to the manufacturer’s installation documentation for detailed measurement requirements.)
- Cut-Out Depth: 22.75 inches (Minimum required depth of the installation location for a standard installation of the product. This measurement will help you determine if the appliance will fit into the desired space and have the clearance necessary for proper operational use. Please refer to the manufacturer’s installation documentation for detailed measurement requirements.)
- Features
- Exhaust Vent Location: Top/Rear
- Vent Type: Ducted
- Vent Style: External, External (External vents pull air from the room and move it directly outside through a dedicated duct system. Recirculating vents pull the air through a filter so that it can be cleaned before being recycled back into the room. Convertible vents can be reconfigured from external ventilation to recirculating via installation of certain parts.)
- Range Hood Type: Insert
- Number of Fan Speeds: 5
- Temperature Sensor: true (Integrated sensor adjusts ventilation power as needed to accommodate high temperatures.)
- Control Type: Button
- Display Type: LCD
- Delay Shut-Off: true (Use this feature after cooking to continue ventilating any fumes or odors. When time's up, the operation automatically shuts off.)
- Auto Fan Shut-Off: true
- Remote Control: true
- Damper Included: false
- Integrated Light(s): true
- Number of Lights: 4
- Number of Light Levels: 2
- Bulb Type Required: LED
- Bulb(s) Included: true
- Maximum Bulb Wattage: 6 watts
- Performance
- Maximum Air Flow Capacity: 650 cubic feet per minute (Maximum amount of air that the appliance can ventilate at its highest setting.)
- Minimum Air Flow Capacity: 200 cubic feet per minute (Minimum amount of air that the appliance will ventilate at its lowest setting.)
- Maximum Operating Sound Level: 8 sones (The perceived intensity of the operating sound produced by the product at its highest setting. The higher the sone rating, the louder the noise level.)
- Minimum Operating Sound Level: 1 sones (The perceived intensity of the operating sound produced by the product at its lowest setting. The higher the sone rating, the louder the noise level.)
- Filter Info
- Dishwasher-Safe Filter: true
- Removable Grease Filter: true
- Number of Filters: 3
- Electrical
- Amperage: 5 amperes (Strength of electrical current.)
- Voltage: 120 volts (Amount of power needed to support an electrical current.)
- Warranty
- Warranty - Parts: 3 years
- Warranty - Labor: 1 year
- Other
- UPC: 646328013591
Now available with LumiLight LED lighting with TruHue™ that lets you customize the ambiance from warm to cool (2700K to 5000K) with just a touch, Monsoon II delivers even more. Designed using universally-recognized, conventional installation dimensions, Monsoon II is a great option for custom cabinetry or an enclosure. Its stainless steel baffle filters with removable grease tray make it easy to maintain its pro-style look, while the new 5-speed electronic LCD controls, optional wireless remote control, and exclusive ACT™ technology give the homeowner more than they expected.
- Airflow Control Technology (ACT): Airflow Control Technology or ACT is an exclusive technology that gives installers the ability to set the maximum CFM levels to meet local code requirements.
- LumiLight LED Lighting with TruHue: A bright idea: customize your hoods light to harmonize with the rest of your kitchens lighting at the touch of a button with TruHue anywhere from 2700K to 5000K.
- Optional Dual Internal Blower Kit Available: Optional dual internal blower kit available to fit your application. (PBD-1200B)
- Electronic Touch Controls: Electronic touch controls adjust the range hood blower and LED light levels, and enable the auto delay-off function.
- Professional Baffle Filters: High-airflow baffle filters that are dishwasher safe and ensure a lifetime of exceptional performance.
- Optional Wireless Remote Control (RC-0002): ADA-compliant, wireless RF remote control with battery and holder. Equipped with a magnet on the back for easy storage on any magnetic surface. Maximum remote control communication distance is 15 feet from the hood. Please check your Zephyr range hoods specification sheet to ensure compatibility.
- Dual-Level Lighting: The dual-level dimmable LEDs require less energy than traditional halogen lights, are cool to the touch, and provide uniform light distribution.
- TempGuard: TempGuard is a built-in safety feature that turns on the fan if excessive heat is detected.
Whats Included
- Monsoon II 48 in. 650 CFM Insert Mount Range Hood with LED Light in Stainless Steel
Q: Does this range hood have a light?
A: Yes, this range hood has integrated LED lights.
Q: Does this range hood have a remote control?
A: Yes, this range hood comes with a wireless remote control.
Q: Is there a safety feature to turn on the fan if excessive heat is detected?
A: Yes, TempGuard is a built-in safety feature that turns on the fan if excessive heat is detected.
Q: What is the maximum airflow capacity of this range hood?
A: The maximum airflow capacity is 650 cubic feet per minute.
Q: How many fan speeds does this range hood have?
A: This range hood has five different fan speeds.
Q: Can the fan automatically turn off?
A: Yes, this range hood has an auto fan shut-off feature.
Q: Are the filters on this range hood easy to clean?
A: Yes, the baffle filters are dishwasher safe for easy cleaning.
Compare similar products
Now available with LumiLight LED lighting with TruHue™ that lets you customize the ambiance from warm to cool (2700K to 5000K) with just a touch, Monsoon II delivers even more. Designed using universally-recognized, conventional installation dimensions, Monsoon II is a great option for custom cabinetry or an enclosure. Its stainless steel baffle filters with removable grease tray make it easy to maintain its pro-style look, while the new 5-speed electronic LCD controls, optional wireless remote control, and exclusive ACT™ technology give the homeowner more than they expected.
Monsoon Connect is unique in the marketplace. Optional dual 1300-CFM PowerWave blowers and stainless steel baffle filters make for a powerful, performance-driven range hood insert that is easy to clean. With a wireless remote-control option and Zephyr Connect, our most advanced operation system makes the Monsoon Connect the most quiet and energy efficient, one-piece liner available today. Dual blowers available on the 36, 42 and 48 models.
Monsoon I has taken the one-piece liner to the next level. Featuring dual-level LumiLight LED lighting with TruHue™ that lets you customize the ambiance from warm to cool (2700K to 5000K) with just a touch. An optional ADA-compliant wireless remote allows you to easily control Monsoon I without ever reaching over a dangerous cooking surface. Equipped with new 5-speed electronic LCD controls, pro baffle filters, our exclusive ACT™ technology and either a powerful 600-CFM blower (30” and 36” models) or a 1,200-CFM blower (42” and 48” models).
Now available with LumiLight LED lighting with TruHue™ that lets you customize the ambiance from warm to cool (2700K to 5000K) with just a touch, Monsoon II delivers even more. Designed using universally-recognized, conventional installation dimensions, Monsoon II is a great option for custom cabinetry or an enclosure. Its stainless steel baffle filters with removable grease tray make it easy to maintain its pro-style look, while the new 5-speed electronic LCD controls, optional wireless remote control, and exclusive ACT™ technology give the homeowner more than they expected.
