Questions & Answers
Page Showing 1-5 of 5 questions
Q: Questiondoes this have wireless LAN? and what is speed of WIRED network? and does this have extra slot for SSD SATA 2.5 inch drive? and can this be set on desk VERTICALLY instead of horizontally?
Asked by nick.
- A:Answer Thank you for the question. The EliteDesk 800 G6 (683J5UT) has Wi-Fi 6 AX201. The RJ45 port is Intel I219-LM Gigabit Network Connection LOM. Expansion Slots:1 M.2 2230; 2 M.2 2242/2280 (Note - 1 M.2 slot for WLAN and 2 M.2 2242/2280 slot for storage). You can position it vertically provided it's slightly raised to avoid blocking the vents. Scroll through the images to see vertical mounting ideas.
Answered by HP Team

Q: Questioncontinuing with the 2.5 SSD drive bay, see spec's, attached, i was on CHAT with HP, and this sheet, and your comments, indicate it is available, which is why i bought it. HOW TO GET TWO OF THOSE bays, since i got two machines ???
Asked by nick.
- A:Answer It looks like Best Buy doesn't carry the drive bay kit, but it should be available directly from HP or other places that sell computer parts. It's HP part number 13L70AA.
Answered by HP Team

Q: Questionthanks for clear answers. i just ordered TWO of these. do you have link to download PDF manuals, confiturations (circuit board layout, etc), any archivable documents for this machine? thanks
Asked by nick.
- A:Answer Thank you for asking. Yes, the user guide is here: http://h10032.www1.hp.com/ctg/Manual/c06713182.pdf and the maintenance and service manual is here: http://h10032.www1.hp.com/ctg/Manual/c06713660.pdf.
Answered by HP Team

Q: Questiondo you MEAN that the WLAN and STORAGE occupy the indicated slots, AND that there are ADDITIONALLY a M.2 2230 and M.2 2242/2280 are EXTRA available slots? thanks
Asked by nick.
- A:Answer Thank you for the question. The EliteDesk 683J5UT has one vacant M.2 2242/280 slot (the other slots are occupied by the WLAN and the 512GB SSD). There is also a bay for a 2.5" HDD should you want to add one.
Answered by HP Team

Q: QuestionHELP - URGENT - your prior reply indicated this can take an SSD 2.5 inch drive. I opened the case, and there is NO CABLE and NO SUPPORT tray to conne3ct this !!!! HELP ! I NEED those connections, that is why i bought the machine ! (bought TWO of them)
Asked by nick.
- A:Answer replying to the hp reply - no problem, i will be filing a better business bureau complaint, as no one seems ablt to provide this missing part, as it is included in the spec's
Answered by Anonymous
Page 1, Showing 1-5 of 5 questions
