“Mounting required dimensions? Horizontal or vertical? Same mounting procedure as the LTV series? Mount hole diameter?”
Answer This Question
1-1 of 1 Answer
Ideally, the sensor should be mounted on the tallest object in your area. Avoid positioning it parallel or below eaves, rooflines, trees, or other objects that may obstruct wind readings. The maximum wireless transmission range to the station is up to 400ft (121m) in open air. Though sensor is battery operated (requires 3 AA), the solar panel assists batteries during daylight hours, so it is helpful if solar panel faces direct sunlight. You will need to mount the wind sensor in vertical position, but mounting bracket may be adjusted 180° angle for optimal positioning. You are correct that LTV-W3 (Glide sensor) is very similar to LTV series wind sensors (brackets are similar size) If mounting wind sensor's bracket, it would need to have a diameter of 1 inch to 1.18 inch (3 cm) and use U-bolt to secure. Anchor base for wind sensor mounting bracket should be fastened to flat surface with 4 screws to be secured. You may view more content on our website page: https://www.lacrossetechnology.com/products/ltv-w3
