Thermador - Masterpiece 30" Built-In Gas Cooktop with 5 Star Burners and ExtraLow Select - Stainless Steel
Shipping
Specifications
Key Specs
Voice Assistant Built-inNoProduct Height5 3/8 inchesProduct Width31 inchesProduct Depth21 1/4 inchesCooktop Surface TypeGrateNumber of Burners5Color FinishStainless steel
General
Product NameMasterpiece 30" Built-In Gas Cooktop with 5 Star Burners and ExtraLow SelectBrandThermadorModel NumberSGSX305TSVendor CollectionThermador MasterpieceColorStainless SteelColor FinishStainless steel
Compatibility
Voice Assistant Built-inNo
Dimensions
Product Height5 3/8 inchesProduct Width31 inchesProduct Depth21 1/4 inchesStandardized Width30 inchesProduct Weight37.92 pounds
Cut-Out Dimensions
Cut-Out Height3 13/16 inchesCut-Out Width28 15/16 inchesCut-Out Depth19 1/8 inches
Features
Downdraft VentilationfalseInstalls Over Built-In OventrueControl TypeAnalogControl LocationTopDigital DisplayfalseHot Surface Indicator(s)falseChild LockfalseForm FactorCooktopPortablefalseWireless ConnectivityNoneGas TypeNatural gas
Cooktop Features
Cooktop Surface TypeGrateCooktop Surface MaterialStainless steelNumber of Cooking Zones5Number of Burners5Sealed BurnersfalseSpecialty Burner(s)ExtraLow SelectGrate TypeContinuousGrate MaterialCast ironDishwasher-Safe Gratesfalse
Included
Power Cord IncludedtrueGriddle Includedfalse
Burner Rating
Burner 1 Rating8000 british thermal unitsBurner 2 Rating10000 british thermal unitsBurner 3 Rating16000 british thermal unitsBurner 4 Rating8000 british thermal unitsBurner 5 Rating10000 british thermal unitsTotal Maximum BTU Rating52000
Power
Cooktop Power SourceGasIgnition TypeElectricPropane (LP) ConvertibletruePropane Conversion Kit IncludedfalsePropane Kit Model CompatibilitySLPKITWGas Regulator Inlet Thread Size1/2 inch
Certifications Listings & Approvals
ADA ComplianttrueChemical DisclosuresFree of PFAS, PFOA, lead, and cadmium. Libre de PFAS, PFOA, plomo, y cadmio.
Warranty
Warranty - Parts2 yearsWarranty - Labor2 years
Other
UPC825225933052
Features
Thermador offers an impressive 30-inch gas cooktop with 5 patented Star Burners, including a center-mounted power burner, 2 ExtraLow Select simmer burners, and 52,000 BTUs of overall heat output. The patented Star Burner's unique five-point design offers more ports and more flame distribution than a round burner. ExtraLow Select burners have 5 precise settings that is perfect for simmering or holding foods and melting chocolate without scorching or burning and a powerful 16,000 BTU center burner allows for rapid boiling and high heat searing. The 30-inch 5 burner gas cooktop provides functionality of a 36-inch cooktop in a compact kitchen environment. Continuous grates allow pots and pans to move effortlessly across the cooktop.
Our Star Burner provides equal flame distribution
Star Burners are 56% longer than a round burner of the same size, which allows for more flame ports. The result is a burner that delivers a superior flame spread and reduced cold spots for faster and more even heating.
16,000 BTU Center Burner
Powerful 16,000 BTU center burner perfect for rapid boiling and high heat searing.
ExtraLow for slowly simmering delicate recipes
Our ExtraLow feature provides a wide range of temperature control. It cycles the burners on and off to maintain a very low temperature. Perfect for simmering delicate sauces or keeping food warm without scorching or stirring.
30-inch cooktop with functionality of a 36-inch cooktop
30-inch 5 burner gas cooktop provides functionality of a 36" cooktop in a compact kitchen environment.
Continuous Grates make it easy to move pans
The connected gridwork allows for moving pots and pans effortlessly across the cooktop.
Electronic Re-ignition keeps your flame ignited
Your burners will automatically re-ignite in case the flame goes out.
Contemporary Grates
Redesigned with stunning contemporary grates.
Stainles Steel
Stainless Steel Gas Cooktop for a modern look.
Flexibility & Function
Thermador Gas Cooktops are designed for flexibility and functionality.
Star-K Sabbath Compliant
This cooktop is Star-K certified and may be used as Sabbath Compliant appliances, making it possible to use it on the Sabbath or the holidays.
Downdraft Ventilation Pairing
The Stainless steel Gas Cooktop pairs beautifully with Downdraft Ventilation for a sleek and integrated look.
High-grade, quality die cast metal knobs
LP gas conversion kit not included; order seperately, Model# SLPKITW
What's Included
Thermador MASTERPIECE SERIES 30" Gas Cooktop
Cast iron pan support
Manuals & Guides
Specification Sheet
Use and Care Manual
Warranty Manual
Product Datasheet/Brochure
Questions & Answers (7)
Q: Does this cooktop have a continuous grate design? (1 answers)
A: Yes, this cooktop features continuous grates for easy movement of pots and pans.Q: How many burners does this Thermador gas cooktop have? (1 answers)
A: This Thermador gas cooktop is equipped with 5 burners.Q: What is the BTU rating of the center burner on this Thermador gas cooktop? (1 answers)
A: The center burner on this Thermador gas cooktop has a powerful 16,000 BTU rating.Q: Is this Thermador gas cooktop compatible with propane? (1 answers)
A: Yes, this cooktop can be converted to propane with the appropriate kit.Q: Does this gas cooktop have an electric ignition system? (1 answers)
A: Yes, this cooktop uses an electric ignition system to ignite the burners.Q: What is the advantage of the Star Burner design on this cooktop? (1 answers)
A: The Star Burner design offers more flame ports and better flame distribution compared to round burners, resulting in faster and more even heating.
