Cisco - MA-ANT-20 Dual-Band Omnidirectional Wi-Fi Access Point Antenna Set, 4 dBi 2.4 GHz & 7 dBi 5 GHz, N-Type, MR74 MR76 MR86 - White
Related Item
About This Item
- Key Specs
- Antenna Type: Multi-Directional Antenna
- Indoor or Outdoor Use: Indoor Antenna, Outdoor Antenna (Indicates the appropriate environment product was designed to be used in.)
- Amplified Reception: false (A powered antenna is able to pull signals from a greater distance, enabling better reception.)
- General
- Brand: Cisco
- Model Number: MA-ANT-20
- Product Name: MA-ANT-20 Dual-Band Omnidirectional Wi-Fi Access Point Antenna Set, 4 dBi 2.4 GHz & 7 dBi 5 GHz, N-Type, MR74 MR76 MR86
- Color: White
- Design
- Antenna Type: Multi-Directional Antenna
- Indoor or Outdoor Use: Indoor Antenna, Outdoor Antenna (Indicates the appropriate environment product was designed to be used in.)
- Form Factor: Dipole (The size, arrangement, and physical configuration of the product.)
- Material: Acrylonitrile Butadiene Styrene (ABS)
- Performance
- Frequency: 2.4GHz Digital (A measurement of the electromagnetic radio waves a device emits.)
- Gain: 7 decibels relative to isotropic (The higher the gain, the farther the range and higher the efficiency of the antenna.)
- Impedance: 50 ohms (Describes the resistance of an electric signal throughout the system. Devices with low impedance require less power to deliver optimal signals but are more at risk for damage from overloading. Higher impedance requires more power but is more protected from overload damage.)
- Signal Strength Meter: false
- Features
- Amplified Reception: false (A powered antenna is able to pull signals from a greater distance, enabling better reception.)
- Removable Amplifier: false
- Rotational Design: 0 degrees
- Parental Controls: false (Allows user to block unwanted content, signals, channels, networks, etc. from being received or accessed.)
- Product Type: Network antenna
- Connectivity
- Connection Type: Wired
- Compatibility: Cisco Meraki MR62, MR66, MR72, MR74, MR76, MR84, MR86 Access Points
- Dimensions
- Product Height: 7 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 1 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 1 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Product Weight: 0.5 pounds (The out of box weight of the item.)
- Included
- Coaxial Cable Included: false
- Warranty
- Warranty - Parts: 1 year
- Warranty - Labor: None
- Other
- UPC: 810979012115
The Cisco Meraki MA-ANT-20 is a dual-band omnidirectional Wi-Fi antenna set designed for Meraki MR series access points with external N-type connectors. Sold as a pack of two, each antenna delivers 4 dBi of gain on the 2.400 to 2.500 GHz band and 7 dBi of gain on the 5.150 to 5.875 GHz band, providing 360-degree horizontal coverage and vertical linear polarization for extended wireless reach in large open environments, warehouses, retail floors, and sheltered outdoor deployments. The MA-ANT-20 screws directly onto the access point with no coaxial cable required, keeping the installation clean and minimizing insertion loss. Certified for use with the Cisco Meraki MR62, MR66, MR72, MR74, MR76, MR84, and MR86 access points, it gives network administrators a sanctioned external antenna upgrade path for improved client coverage, stronger uplink and downlink signal levels, and better throughput at the edge of the wireless cell. Each antenna measures 1.0 by 7.1 inches, weighs 0.17 pounds, is constructed from ABS plastic, and is rated for operation from minus 40 to 158 degrees Fahrenheit, making it suitable for conditioned indoor spaces and sheltered outdoor installations alike. An ideal upgrade for IT administrators deploying Meraki wireless networks in spaces that demand wide-area omnidirectional Wi-Fi coverage.
- Dual-Band 2.4 GHz and 5 GHz Omnidirectional Coverage: Delivers 360-degree horizontal coverage on both 2.4 GHz and 5 GHz Wi-Fi bands in a single antenna set, extending signal reach for Meraki MR access points in warehouses, open offices, retail floors, and other large indoor or sheltered environments where omnidirectional propagation is required.
- High-Gain 4 dBi 2.4 GHz and 7 dBi 5 GHz Performance: Provides 4 dBi gain on the 2.400 to 2.500 GHz band and 7 dBi gain on the 5.150 to 5.875 GHz band for stronger uplink and downlink signal levels, improved client connection rates, and better throughput at the edge of the wireless cell compared to stock dipole antennas.
- N-Type Connector for Direct Meraki AP Mounting: Screw-on N-type connector mounts the antenna directly to the access point body with no coaxial cable required, keeping installs clean and minimizing signal loss. Vertical linear polarization matches standard Meraki MR deployment practice.
- Certified for Meraki MR62 MR72 MR74 MR76 MR84 MR86 APs: Officially certified by Cisco Meraki for use with the MR62, MR66, MR72, MR74, MR76, MR84, and MR86 indoor and outdoor access points, giving network administrators a sanctioned upgrade path for external antenna deployments without voiding AP compatibility.
- Rugged ABS Housing with Wide Operating Temperature Range: Constructed from ABS plastic and rated for operation from minus 40 to 158 degrees Fahrenheit (minus 40 to 70 degrees Celsius), making the antenna set suitable for conditioned indoor spaces and sheltered outdoor installations. Sold as a set of two antennas, 1.0 x 7.1 inches each.
Whats Included
- Two Cisco Meraki MA-ANT-20 antennas
