Name: EVGA - 650W ATX12V / EPS12V Modular Power Supply - Black
Brand: EVGA
SKU: 5753408
Rating: 5 (3 reviews)

Key Specs
- Wattage: 650 watts (Measurement of electrical power.)
- Modular: Fully modular
- Energy Efficiency: 80 PLUS Gold (Computer and server power supplies with the 80 PLUS certification are tested for operating efficiency at 10, 20, 50, and 100% of rated load. If a product tests at least 80% efficient, it qualifies for the base level 80 PLUS certification. Bronze, Silver, Gold, Platinum, and Titanium level certifications are given to products with even higher efficiency ratings.)
- ATX Connector: 24 Pin (The configuration of the connector as it connects a computer power supply unit to an ATX motherboard.)
- PCIe Connector: 3x 8pin (6+2) (The configuration of the connector as it connects a computer power supply unit to a PCIe (Peripheral Component Interconnect Express) motherboard interface.)
- Peripheral Connector: 4 (The configuration of the connector as it connects a computer power supply unit to a peripheral component such as a motherboard, video card, lighting, etc.)
- SATA Connector: 6x (The configuration of the connector as it connects a computer power supply unit to a SATA-based drive.)
- Product Length: 149.86 millimeters (The out of box length of the item. Length is measured as the longest dimension of the item.)
General
- Brand: EVGA
- Model Number: 220-G3-0650-Y1
- Product Name: 650W ATX12V / EPS12V Modular Power Supply
- Color: Black
Power
- Wattage: 650 watts (Measurement of electrical power.)
- Modular: Fully modular
- Energy Efficiency: 80 PLUS Gold (Computer and server power supplies with the 80 PLUS certification are tested for operating efficiency at 10, 20, 50, and 100% of rated load. If a product tests at least 80% efficient, it qualifies for the base level 80 PLUS certification. Bronze, Silver, Gold, Platinum, and Titanium level certifications are given to products with even higher efficiency ratings.)
- Specification Compliance: ATX12V / EPS12V
- Overload Protection: true (Features intended to protect the product from damage and overheating caused by overload.)
- Power Cord Included: true (Connects your product to an electrical outlet, allowing for immediate use (provided that other installation requirements are met).)
- Cord Length: 4.9212 feet
Connectivity
- ATX Connector: 24 Pin (The configuration of the connector as it connects a computer power supply unit to an ATX motherboard.)
- Floppy Connector: true (The configuration of the connector as it connects a computer power supply unit to a floppy disk drive.)
- PCIe Connector: 3x 8pin (6+2) (The configuration of the connector as it connects a computer power supply unit to a PCIe (Peripheral Component Interconnect Express) motherboard interface.)
- Peripheral Connector: 4 (The configuration of the connector as it connects a computer power supply unit to a peripheral component such as a motherboard, video card, lighting, etc.)
- SATA Connector: 6x (The configuration of the connector as it connects a computer power supply unit to a SATA-based drive.)
Dimensions
- Product Height: 83.82 millimeters (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 149.86 millimeters (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Length: 149.86 millimeters (The out of box length of the item. Length is measured as the longest dimension of the item.)
- Product Weight: 112.2 ounces (The out of box weight of the item.)
Cooling
- Cooling Fan Type: Other
Other
- UPC: 843368042585

Secure your gaming rig and components with this EVGA SuperNova G3 power supply. It's 80 Plus Gold-certified for optimal operating efficiency, and its fully modular design provides flexible cabling setup for enhanced airflow. This 650W EVGA SuperNova G3 power supply operates quietly and has improved longevity thanks to the hydraulic dynamic bearing fan.

650W power supply: Delivers the power needed to run your PC.
AC 100-240V input: With input 50 - 60Hz frequency for wide-ranging use.
ATX12V and EPS12V compliance: Meets industry standards.
130mm fluid dynamic bearing cooling fan: Dissipates heat to help the power supply remain working at optimal temperature levels.
Maximum safety to your critical system components: Provides overheat, overcurrent, overvoltage, overpower, undervoltage and short-circuit protection.
80 PLUS Gold Certification: Delivers 90% (115VAC) / 92% (220-240VAC) energy efficiency at real world load conditions.
Modular cable management: Allows you to use only the cables you need.
