Lenovo - Legion Pro 5 16" 2.5K Gaming Laptop - AMD Ryzen 9 8945HX 2023 - NVIDIA GeForce RTX 5060 - 16GB Memory - 1TB SSD - Eclipse Black
Lenovo - Legion Pro 5 16" 2.5K Gaming Laptop - AMD Ryzen 9 8945HX 2023 - NVIDIA GeForce RTX 5060 - 16GB Memory - 1TB SSD - Eclipse Black
FREE shipping to
More Buying Options
Highlights
- Key Specs
- Screen Type: IPS
- Screen Size: 16 inches (Size of the screen, measured diagonally from corner to corner.)
- Screen Resolution: 2560 x 1600 (Screens come in a range of resolutions (measured in pixels, horizontal x vertical). The higher the resolution, the greater the picture quality.)
- Touch Screen: false (Touch-screen devices make navigating more intuitive. Using a touch-screen display, you can do things such as tap to select, hold and drag to move items, swipe to scroll, and pinch to zoom.)
- Refresh Rate: 240Hz (The number of frames per second the device can produce natively without enhancement. Higher rates help produce smooth, seamless pictures.)
- Brightness: 500 nits (A measure of the total light output.)
- Processor Model: AMD Ryzen 9 8000 Series (Your computer's processor is like its brain. Working in combination with system memory, the power of the processor determines the complexity of software you can run, how many programs you can have open at the same time, and how fast those programs will run. Most computers feature an AMD, Intel or Snapdragon processor.)
- CPU Base Clock Frequency: 2.5 gigahertz (Actual central processing unit (CPU) speed may vary by device configuration and design. The average rate at which the processor is able to execute tasks under normal operating conditions as asserted by the manufacturer.)
- Storage Type: SSD
- Total Storage Capacity: 1000 gigabytes
- System Memory (RAM): 16 gigabytes (Random-access memory (RAM) is a computing device's short-term data storage, which allows active information to be accessed quickly. The size and type of RAM determines how efficiently the device can handle large amounts of information at one time. For example, gaming or video editing requires more RAM for optimal performance.)
- Graphics: NVIDIA GeForce RTX 5060 (Often referred to as a "graphics processing unit" (GPU), this device is responsible for displaying image content and decoding/encoding video content in programs and games.)
- Display Connector(s): Display connection via USB port, 1 x HDMI 2.1 (The number and type of connectors used to connect to an external display.)
- Battery Life (up to): 6.3 hours (Battery life will vary depending on the product configuration, product model, applications loaded on the product, power management setting of the product and the product features used by the customer. As with all batteries, the maximum capacity of this battery will decrease with time and usage.)
- Battery Chemistry: Lithium-polymer
- 2-in-1 Design: false (A laptop and a tablet combined in one lightweight, portable device. Sometimes referred to as "convertible" or "hybrid" laptops, these devices deliver the processing power and keyboard of a laptop. When you're ready to play, either detach the screen or fold your 2-in-1 into tablet mode to comfortably watch movies, play games, read an e-book and more.)
- Backlit Keyboard: true (Integrated lights allow for visibility of the keys in low-light conditions.)
- General
- Brand: Lenovo
- Model Number: 83LT000EUS
- Product Name: Legion Pro 5 16" 2.5K Gaming Laptop - AMD Ryzen 9 8945HX 2023 - NVIDIA GeForce RTX 5060 - 16GB Memory - 1TB SSD
- Color: Eclipse Black
- Year of Release: 2025
- Display
- Display Type: LCD
- Screen Type: IPS
- Screen Size: 16 inches (Size of the screen, measured diagonally from corner to corner.)
- Screen Resolution: 2560 x 1600 (Screens come in a range of resolutions (measured in pixels, horizontal x vertical). The higher the resolution, the greater the picture quality.)
- Touch Screen: false (Touch-screen devices make navigating more intuitive. Using a touch-screen display, you can do things such as tap to select, hold and drag to move items, swipe to scroll, and pinch to zoom.)
- Refresh Rate: 240Hz (The number of frames per second the device can produce natively without enhancement. Higher rates help produce smooth, seamless pictures.)
- Display Surface: Anti-glare
- Brightness: 500 nits (A measure of the total light output.)
- Processor
- Processor Brand: AMD
- Processor Model: AMD Ryzen 9 8000 Series (Your computer's processor is like its brain. Working in combination with system memory, the power of the processor determines the complexity of software you can run, how many programs you can have open at the same time, and how fast those programs will run. Most computers feature an AMD, Intel or Snapdragon processor.)
- Processor Model Number: 8945HX
- Processor Model Year of Release: 2023 (The year the processor model was initially available for sale or built into a computer.)
- CPU Base Clock Frequency: 2.5 gigahertz (Actual central processing unit (CPU) speed may vary by device configuration and design. The average rate at which the processor is able to execute tasks under normal operating conditions as asserted by the manufacturer.)
- CPU Boost Clock Frequency: 5.4 gigahertz (Actual central processing unit (CPU) speed may vary by device configuration and design. The maximum rate at which the processor is able to execute tasks, typically only used for a short period of time as needed. This rate may temporarily boost the processor's performance, but may result in overheating, shutdown, or damage to equipment if sustained.)
- Number of CPU Cores: 16-core (A core, or "brain" of a CPU, allows it to receive and execute instructions. Each core can work independently or together to perform parallel operations.)
- Number of CPU Threads: 32 (Generally, the more threads, the faster and more responsive the operating system.)
- Unlocked Processor: false
- CPU Cache Memory Level: L2, L3
- L2 Cache: 8 megabytes (Cache memory, also called CPU memory, is random-access memory (RAM) that a computer microprocessor can access more quickly than it can access regular RAM. This memory is typically integrated directly with the CPU chip or placed on a separate chip that has a separate bus interconnect with the CPU.)
- L3 Cache: 16 megabytes (Cache memory, also called CPU memory, is random-access memory (RAM) that a computer microprocessor can access more quickly than it can access regular RAM. This memory is typically integrated directly with the CPU chip or placed on a separate chip that has a separate bus interconnect with the CPU.)
- Storage
- Storage Type: SSD
- Total Storage Capacity: 1000 gigabytes
- Solid State Drive Capacity: 1000 gigabytes (The amount of data that can be stored on the device's solid state drive (SSD). SSD is a flash-based storage with faster speeds than a hard disk drive (HDD).)
- Memory
- System Memory (RAM): 16 gigabytes (Random-access memory (RAM) is a computing device's short-term data storage, which allows active information to be accessed quickly. The size and type of RAM determines how efficiently the device can handle large amounts of information at one time. For example, gaming or video editing requires more RAM for optimal performance.)
- Type of Memory (RAM): DDR5 (Each type of RAM delivers a different level of speed, bandwidth, energy efficiency and performance.)
- System Memory RAM Speed: 5200 megahertz (How fast the information-storing hardware operates. The faster the RAM, the faster memory can be transferred to other system components. Ultimately, faster RAM improves operational efficiency.)
- Number Of Memory Slots: 2
- System Memory RAM Expandable To: 32 gigabytes (Adding more random-access memory (RAM) to a computer speeds up performance and improves efficiency. Upgrades to memory are limited by the number of expansion slots for additional RAM and existing RAM installed on the device.)
- Graphics
- Graphics Type: Dedicated (Dedicated graphics uses a separate graphics card for processing video images. Because it does not use memory from the system's RAM, there is no extra burden on the CPU and graphics are processed more efficiently. Integrated graphics shares system RAM to process video images.)
- GPU Brand: NVIDIA
- Graphics: NVIDIA GeForce RTX 5060 (Often referred to as a "graphics processing unit" (GPU), this device is responsible for displaying image content and decoding/encoding video content in programs and games.)
- Advanced Graphics Rendering Technique(s): DLSS 4 (Deep Learning Super Sampling) (Imaging technology designed to improve graphics rendering.)
- GPU Base Clock Frequency: 2.28 gigahertz (The minimum rate at which the graphics controller is guaranteed to operate.)
- GPU Boost Clock Frequency: 2.5 gigahertz (The maximum ideal rate at which the graphics controller is able to operate, typically only for a short period of time.)
- GPU Video Memory (RAM): 8 gigabytes (Random-access memory (RAM) is a GPU’s, or graphics cards, short-term data storage, which allows active information to be accessed quickly. The size and type of RAM determines how efficiently the GPU can handle large amounts of information at one time. For example, larger amounts of RAM for gaming or video editing increases performance.)
- GPU Video Memory Type (RAM): GDDR7 (Each type of RAM delivers a different level of speed, bandwidth, energy efficiency and performance.)
- Compatibility
- Operating System: Windows 11 Home (The operating system manages all software and hardware, including files, memory and connected devices. Most importantly, it lets you interact with your device and your programs in a visual way; otherwise, you'd be typing computer code to get anything done.)
- Connectivity
- Display Connector(s): Display connection via USB port, 1 x HDMI 2.1 (The number and type of connectors used to connect to an external display.)
- Number of HDMI Outputs (Total): 1
- DisplayPort Over USB-C: DisplayPort 2.1 (The version of DisplayPort that leverages the Alternate Mode Functional Extension of the USB-C interface. This connector allows for higher resolution, broader color space, multichannel audio support, and greater backwards compatibility with display adapters. Also known as DisplayPort Alt Mode.)
- USB Ports: 3 x USB-A 3.2, 2 x USB-C 3.2 (The number and type of USB ports the product has.)
- Number of USB Ports (Total): 5
- Headphone Jack: true (The device features an interface that allows for the connection of headphones.)
- Microphone Input: true (The device features an input for connecting an external microphone.)
- Wireless Connectivity: Bluetooth, Wi-Fi (The manner in which a device sends data to another device over a short distance without the use of wires or cables.)
- Wireless Standard: BE (The wireless networking protocol used by the device. Each iteration of the protocol is based on the 802.11 standard developed by the Institute of Electrical and Electronics Engineers (IEEE) Standards Association. Denoted by letters following 802.11 (802.11a, 802.11ac, etc.), each version, published in alphabetical order, encompasses all previous versions.)
- Wireless Networking Standard: Wi-Fi 7 (The wireless networking standard used by the device. Each iteration of the standard developed by the Wi-Fi Alliance corresponds to an existing IEEE 802.11 protocol; for example, standard 802.11ac (or AC) is termed Wi-Fi 5. Refers specifically to the standard the device is designed to use, but ultimately determines product interoperability and backward compatibility including previous versions.)
- Number Of Ethernet Ports: 1
- Power
- Power Supply Maximum Wattage: 245 watts
- Battery Life (up to): 6.3 hours (Battery life will vary depending on the product configuration, product model, applications loaded on the product, power management setting of the product and the product features used by the customer. As with all batteries, the maximum capacity of this battery will decrease with time and usage.)
- Battery Cells: 4-cell
- Battery Chemistry: Lithium-polymer
- Camera
- Front-Facing Camera: true
- Front Facing Camera Megapixels: 5 megapixels (The more megapixels, the more detail that the camera facing the user can capture.)
- Built-In Microphone: true
- Features
- 2-in-1 Design: false (A laptop and a tablet combined in one lightweight, portable device. Sometimes referred to as "convertible" or "hybrid" laptops, these devices deliver the processing power and keyboard of a laptop. When you're ready to play, either detach the screen or fold your 2-in-1 into tablet mode to comfortably watch movies, play games, read an e-book and more.)
- Backlit Keyboard: true (Integrated lights allow for visibility of the keys in low-light conditions.)
- Customizable Keyboard Lighting: No
- GPS Enabled: true
- Touchpad Type: Multi-touch, Precision
- Media Card Reader: false (A hardware device that allows for access to data on a memory card and enables the transfer of its files to a computer. These devices may have one or multiple slots for various types of memory cards, and may be integrated into the computer or available as an external device.)
- Customizable Case Lighting: false
- Audio Technology: Nahimic Audio Solution
- Speaker Type: 2 x 2W Harman
- Windows AI: Copilot
- Security Features: Privacy camera
- Cable Lock Slot: None
- Casing Material: Aluminum, Plastic
- Dimensions
- Product Height: 1.02 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 10.55 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 14.35 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Product Weight: 5.33 pounds (The out of box weight of the item.)
- Certifications Listings & Approvals
- ENERGY STAR Certified: false (Devices carrying the ENERGY STAR service mark, such as computer products and peripherals, kitchen appliances, and other products, generally use 20% to 30% less energy than required by federal standards.)
- EPEAT Qualified: false (The Electronic Product Environmental Assessment Tool (EPEAT) was designed to provide an environmental assessment tool for purchasers. In order to qualify for EPEAT, a product must meet all 23 required criteria.)
- Included
- Optical Drive Type: None (An optical disk drive (ODD) uses a laser light to read data from or write data to an optical disc. These discs include CDs, DVDs, and Blu-ray Discs. This allows you to play music or watch movies using prerecorded discs.)
- Numeric Keypad: true
- Warranty
- Warranty - Parts: 1 year limited
- Warranty - Labor: 1 year limited
- Other
- UPC: 198157030091
For aspiring esports gamers, the Legion Pro 5i features AMD processors and 50 Series NVIDIA GeForce RTX graphics for elite performance. The Lenovo PureSight OLED Gaming display delivers ultra-clear visuals and lightning-fast response for high FPS play. Legion Coldfront: Hyper’s advanced cooling keeps your system quiet and efficient, while Lenovo AI Engine+ optimizes performance in real time. Enjoy AI-synced RGB lighting, Legion Truestrike’s 1.6mm key travel, and soft-landing switches. Legion Space enables custom overclocking and AI-driven coaching.
- Windows 11 operating system: Windows 11 brings back the Start Menu from Windows 7 and introduces new features, like the Edge Web browser that lets you markup Web pages on your screen.
- AMD Ryzen 9000 HX Series: The AMD Ryzen 9000 HX Series processor lineup was born to game, with some of the most incredible gaming performance a laptop has ever seen. No need to waste time on the competition, this is the technology every gamer has been waiting for.
- NVIVIDA GeForce RTX 50 Series: Powered by NVIDIA Blackwell, GeForce RTX 50 Series Laptop GPUs bring game-changing AI capabilities to gamers and creators. Multiply performance with NVIDIA DLSS 4, generate images at unprecedented speed, and unleash your creativity with NVIDIA Studio.
- 16" WQXGA 245Hz Display: The 245Hz ultra bright 500 nits display features a 16:10 2560 x 1600 resolution that gives you more space for toolbars and tabs.
- Boost Your FPS with Lenovo AI Engine+: Lenovo AI Engine+ powered by the Lenovo AI Core dynamically tunes your system for peak competitive performance, boosting FPS in any game. Using Scenario Detection in Performance and Balance Modes, it adapts to your gameplay for maximum FPS when you need it most. Smart FPS technology detects on-screen frame rates and adjusts settings in real-time, ensuring smooth, high-FPS gameplay in every match.
- Legion ColdFront Hyper: Stay Cool, Quiet, and in Control for Peak Performance: Legion Coldfront: Hyper keeps your system cool with turbo fans, 3D heatpipes, and AI tuning. Switch modes with Fn+Q, while Acoustic AI Sound Sync adjusts performance for seamless, uninterrupted gaming, ideal for esports and AAA titles.
- Intelligent Esports Design for Peak Performance, Comfort, and Focus: The Legion Pro 5 is built for esports, offering top-tier performance in a sleek, customizable design. An intelligent eco-friendly build ensures portability and sustainability. The high-quality webcam, customizable setup, and gaming accessories elevate your experience for peak competitive focus.
- Nahimic by SteelSeries Audio for Games: Nahimic by SteelSeries leverages AI technology to deliver immersive 3D audio and tailored sound profiles, transforming your gaming experience. Nahimic’s AI Smart Profile adjusts audio settings automatically, ensuring you’re always in the game’s sweet spot.
Whats Included
- Lenovo Legion Pro 5
- User Guide
- Charger
Product Manuals
A: Hey Armani, Yes, this Legion Pro 5 is equipped with DDR5-5200 memory, and it features an open memory slot for quick memory expansion. Please feel free to reach out to us with any other questions!
A: Hey Terrence, This Legion Pro 5 does not feature an OLED display, but the display still dazzles with 500nits brightness, 2560x1600 resolution, and a 240Hz refresh rate, supporting Dolby Vision and DisplayHDR 400. We hope that you enjoy your Legion Pro 5! Please feel free to reach out to us with any other questions!
Q: What is the Total draw Power of the GPU in this laptop?
A: Hey Polilla, This Legion Pro 5's primary draw comes from the Ryzen 9 8945HX CPU with a 55W default TDP, configurable up to 75W, and its RTX 5060 with a TGP of 115. Please feel free to reach out to us with any other questions!
A: Hey Griffith, Officially, the Legion Pro 5 is tested to support up to 1TB in each storage slot. The storage capacity supported is based on the test results with current Lenovo storage offerings. With that being said, theoretically, the system's open M.2 2280 PCIe 4.0 x4 slot should accommodate whatever M.2 storage option you prefer given that it fits within the boundaries of the slot (i.e., an SSD with larger heatsinks may be too large for the slot). Please feel free to reach out to us with any other questions!
A: Hi there, The memory is not soldered, and the system storage can be expanded. This Legion Pro 5 comes with 1x 16GB SO-DIMM DDR5-5200 memory module and it supports up to 32GB DDR5-5200 (max memory is based on the test results with current Lenovo memory offerings), but the chipset may support up to 64GB DDR5. Also, the Legion Pro 5 features two M.2 2280 PCIe 4.0 x4 storage slots to expand storage, which leaves you one open storage slot right out of the box since this system comes with a 1TB SSD preinstalled. Please feel free to reach out to us with any other questions!
Q: Can it run marvel rivals good?
A: Yes, pretty smooth
Q: Would this be a good computer to run adobe creative suit?
A: Hey Jmiller, This Legion Pro 5 will run most, if not all of the Adobe Creative Cloud suite of apps based on the programs' system requirements. Please feel free to reach out to us with any other questions!
Compare similar products
For aspiring esports gamers, the Legion Pro 5i features AMD processors and 50 Series NVIDIA GeForce RTX graphics for elite performance. The Lenovo PureSight OLED Gaming display delivers ultra-clear visuals and lightning-fast response for high FPS play. Legion Coldfront: Hyper’s advanced cooling keeps your system quiet and efficient, while Lenovo AI Engine+ optimizes performance in real time. Enjoy AI-synced RGB lighting, Legion Truestrike’s 1.6mm key travel, and soft-landing switches. Legion Space enables custom overclocking and AI-driven coaching.
For aspiring esports gamers, the Legion Pro 5i features AMD processors and 50 Series NVIDIA GeForce RTX graphics for elite performance. The Lenovo PureSight OLED Gaming display delivers ultra-clear visuals and lightning-fast response for high FPS play. Legion Coldfront: Hyper’s advanced cooling keeps your system quiet and efficient, while Lenovo AI Engine+ optimizes performance in real time. Enjoy AI-synced RGB lighting, Legion Truestrike’s 1.6mm key travel, and soft-landing switches. Legion Space enables custom overclocking and AI-driven coaching.
Skip the burnout and enjoy true uninterrupted gaming enabled by high-efficiency fans and increased noise reduction so you can actually focus on the exceptional performance delivered by the Intel Core Ultra processor and NVIDIA GeForce RTX GPU. OMEN's latest technologies like OMEN AI adapt to your unique setup to boost your game with customized power.
Skip the burnout and enjoy true uninterrupted gaming enabled by high-efficiency fans and increased noise reduction so you can actually focus on the exceptional performance delivered by the AMD Ryzen processor and NVIDIA GeForce RTX GPU. OMEN's latest technologies like OMEN AI adapt to your unique setup to boost your game with customized power.
| Pros for Lenovo - Legion Pro 5 16" 2.5K Gaming Laptop - AMD Ryzen 9 8945HX 2023 - NVIDIA GeForce RTX 5060 - 16GB Memory - 1TB SSD - Eclipse Black | |||
|---|---|---|---|
| There were no pros for this product— | Overall Performance, Processor Speed, OLED Quality, Keyboard Lighting | Overall Performance, Processor Speed, Screen Quality, Design, Keyboard Feel | There were no pros for this product— |
| Cons for Lenovo - Legion Pro 5 16" 2.5K Gaming Laptop - AMD Ryzen 9 8945HX 2023 - NVIDIA GeForce RTX 5060 - 16GB Memory - 1TB SSD - Eclipse Black | |||
| There were no cons for this product— | Battery Life, Heat Dissipation, Noise Level, Portability | Battery Life, Noise Level, Heat Dissipation, Portability, Weight | There were no cons for this product— |
Specs
Reviews
Customer Images
The vast majority of our reviews come from verified purchases. Reviews from customers may include My Best Buy members, employees, and Tech Insider Network members (as tagged). Select reviewers may receive discounted products, promotional considerations or entries into drawings for honest, helpful reviews.
- Rated 5 out of 5 stars
Great machine, well built, nice screen.
Very happy with this machine. I added an additional 16GB of DDR5 (before prices went crazy) and a 2nd NVME SSD for gaming. So far for all the games I play this does a great job. Well built, bright screen, nice keyboard with numpad. Fast CPU and the NVIDIA 5060 really helps gaming performance. I've never had a screen with this high of a refresh before, but it sure seems smooth. Be sure to enable it in Windows 11, by default its stuck at 60hz instead of 240hz. The battery life isn't that great, but this isn't really a productivity machine. It's not bad, but if you really want crazy battery life buy a mac I guess.
This review is from Lenovo - Legion Pro 5 16" 2.5K Gaming Laptop - AMD Ryzen 9 8945HX 2023 - NVIDIA GeForce RTX 5060 - 16GB Memory - 1TB SSD - Eclipse Black
Trackster986 Posted
- Rated 5 out of 5 stars
Great for everything Laptop
This laptop i got during cyber monday at $1100 it was an amazing purchase. It runs most games flawlessly and i can do all my schoolwork on it. Its batterly life is poor but thats to be expected with a gaming laptop. My only complaint would be its weight as it can get uncomfortable on your lap after a while. It has good screen quality although i wish colors popped just a little bit more. This is probably as good as it gets for a mid-range gaming laptop for the price i bought it at. It is a solid 9/10 gaming laptop
This review is from Lenovo - Legion Pro 5 16" 2.5K Gaming Laptop - AMD Ryzen 9 8945HX 2023 - NVIDIA GeForce RTX 5060 - 16GB Memory - 1TB SSD - Eclipse Black
Carson Posted
- Rated 5 out of 5 stars
Good choice
Great performance for everyday work and gaming. The laptop is fast, responsive, and handles multitasking without any issues. Build quality feels solid, the screen looks good, and overall it offers excellent value for the price. Very satisfied with the purchase and would definitely recommend it.
This review is from Lenovo - Legion Pro 5 16" 2.5K Gaming Laptop - AMD Ryzen 9 8945HX 2023 - NVIDIA GeForce RTX 5060 - 16GB Memory - 1TB SSD - Eclipse Black
AleksandrR Posted
