Leviton - 5359-VY 20 Amp 125V Straight Blade Industrial Grounding Connector, Nylon Housing - Yellow
Leviton - 5359-VY 20 Amp 125V Straight Blade Industrial Grounding Connector, Nylon Housing - Yellow
About This Item
- Key Specs
- App Compatible: false (The product can be connected to a program or software application on a mobile device, which then receives collected data from the product.)
- General
- Brand: Leviton
- Model Number: 3713899
- Product Name: 5359-VY 20 Amp 125V Straight Blade Industrial Grounding Connector, Nylon Housing
- Color: Yellow
- Power
- Amperage: 20.0 amperes (Strength of electrical current.)
- Voltage: 125.0 volts (Amount of power needed to support an electrical current.)
- Features
- Grounded Receptacle: Grounding
- Material: Nylon
- Certifications Listings & Approvals
- NEMA Configuration: Type B
- Compatibility
- App Compatible: false (The product can be connected to a program or software application on a mobile device, which then receives collected data from the product.)
- Connectivity
- Plug Style: Straight connector
- Dimensions
- Product Height: 1.6 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 3.5 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Length: 5 inches (The out of box length of the item. Length is measured as the longest dimension of the item.)
- Product Weight: 0.15 pounds (The out of box weight of the item.)
- Warranty
- Warranty - Parts: Manufacture
- Other
- UPC: 078477055106
Heavy-duty straight-blade grounding connector engineered for industrial power cords. Rated 20 Amp, 125 Volt with NEMA Type B configuration, model 5359-VY features a high-impact nylon housing and clear back terminal cover for durability and easy inspection. One-piece hinge, triple-drive screws, and curved crimp-lock terminal clamps speed assembly and secure electrical connections without cutting wire strands. Wide cord clamp range (0.245 in to 0.700 in) with removable inserts fits 18-3 SVT to 10-3 ST cords; UL listed and made in China.
- Industrial grounding connector with 1-piece hinge: One-piece hinge construction combined with triple-drive screws enables quick, secure assembly and maintenance-free operation.
- High-impact nylon housing and clear back terminal cover: High-impact nylon housing resists abuse while the clear thermoplastic back terminal cover allows visual inspection of wiring.
- Curved crimp-lock terminal clamps, no wire strand cutting: Curved and crimp-lock terminal clamps create reliable connections without needing to cut wire strands, preserving conductor strength.
- Wide cord clamp range with removable inserts: Wide cord clamp range (0.245 in to 0.700 in) with removable inserts supports a variety of cord sizes from 18-3 SVT to 10-3 ST for flexible use.
- Durable front module lock and UL listed: Durable front module lock withstands heavy use; UL listed for safety and reliability. Made in China.
- Industrial grounding connector with 1-piece hinge: One-piece hinge construction combined with triple-drive screws enables quick, secure assembly and maintenance-free operation.
- High-impact nylon housing and clear back terminal cover: High-impact nylon housing resists abuse while the clear thermoplastic back terminal cover allows visual inspection of wiring.
- Curved crimp-lock terminal clamps, no wire strand cutting: Curved and crimp-lock terminal clamps create reliable connections without needing to cut wire strands, preserving conductor strength.
- Wide cord clamp range with removable inserts: Wide cord clamp range (0.245 in to 0.700 in) with removable inserts supports a variety of cord sizes from 18-3 SVT to 10-3 ST for flexible use.
- Durable front module lock and UL listed: Durable front module lock withstands heavy use; UL listed for safety and reliability. Made in China.
- Industrial grounding connector with 1-piece hinge: One-piece hinge construction combined with triple-drive screws enables quick, secure assembly and maintenance-free operation.
- High-impact nylon housing and clear back terminal cover: High-impact nylon housing resists abuse while the clear thermoplastic back terminal cover allows visual inspection of wiring.
- Curved crimp-lock terminal clamps, no wire strand cutting: Curved and crimp-lock terminal clamps create reliable connections without needing to cut wire strands, preserving conductor strength.
- Wide cord clamp range with removable inserts: Wide cord clamp range (0.245 in to 0.700 in) with removable inserts supports a variety of cord sizes from 18-3 SVT to 10-3 ST for flexible use.
- Durable front module lock and UL listed: Durable front module lock withstands heavy use; UL listed for safety and reliability. Made in China.
