Tesla - Wall Connector Level 2 Hardwired Electric Vehicle (EV Charger) - up to 48A - 24' - White
More Buying Options
Related Item
- General
- Brand: Tesla
- Model Number: 1517085-42-F/1517085-02-E
- Product Name: Wall Connector Level 2 Hardwired Electric Vehicle (EV Charger) - up to 48A - 24'
- Color: White
- Power
- Electric Vehicle Charging Level: Level 2 (Level 1 chargers connect to a standard 120V outlet but may take nearly a day to charge a vehicle. Level 2 chargers connect to a dedicated 240V outlet and charge most vehicles within a few hours. Level 3 chargers require a specialized charger and are typically found in public, fast charging stations. Charging requirements vary by vehicle.)
- Input Wiring Type: Hardwired
- Power Requirements: Nominal 200-240V AC single-phase
- Circuit Breaker Needed: Yes. Requires 60A, 50A, 40A, 30A, 20A, or 15A breaker. Includes integrated GFCI protection.
- Charging Rate: Up to 11.5kW (on 60A breaker)
- Charging Cable Length: 24 feet
- Surge Protection: N/A
- Connectivity
- Connector Type(s): Tesla (Type of interface connection found on the device.)
- Wireless Connectivity: Wi-Fi (The manner in which a device sends data to another device over a short distance without the use of wires or cables.)
- Compatibility
- App Compatible: true (The product can be connected to a program or software application on a mobile device, which then receives collected data from the product.)
- Features
- Overload Protection: true (Features intended to protect the product from damage and overheating caused by overload.)
- Number of Vehicles Charged Simultaneously: 1
- Mount Type: Wall, Stand
- Certifications Listings & Approvals
- ENERGY STAR Certified: true (Devices carrying the ENERGY STAR service mark, such as computer products and peripherals, kitchen appliances, and other products, generally use 20% to 30% less energy than required by federal standards.)
- Certifications and Standards: cULus - E351002
- Product Safety Certifications and Standard(s): cULus, UL Listed (Lists the applicable certifications and/or standards, as stated by the manufacturer, in which the product has met the requirements for the assurance of quality and safety.)
- Environmental
- Indoor or Outdoor Use: Outdoor
- Minimum Operating Temperature: -22.0 degrees fahrenheit (The lowest recommended ambient (surrounding) temperature in which the product can ideally operate stated by the manufacturer. Generally long-term exposure of the product to temperatures less than the minimum can result in ineffective operation.)
- Maximum Operating Temperature: 122 degrees fahrenheit (The highest recommended ambient (surrounding) temperature in which the product can ideally operate stated by the manufacturer. Generally long-term exposure of the product to temperatures more than the maximum can result in ineffective operation.)
- NEMA Enclosure Rating: Type 3R
- Dimensions
- Product Height: 13.6 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 6.1 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 4.3 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Product Weight: 11.4 pounds (The out of box weight of the item.)
- Warranty
- Warranty - Parts: 4 year for Residential use and 1 year for Commercial use.
- Warranty - Labor: Not applicable
- Other
- UPC: 860009564008
The Tesla Wall Connector is our most convenient charging solution for Tesla vehicles and is ideal for houses, apartments, hospitality properties and workplaces. A faster and Wi-Fi enabled option for your Tesla vehicle, Wall Connector receives over-the-air updates so the charger becomes better over time. Wall Connector adds up to 44 miles of range per hour (or 11.5 kW). Must be installed by a qualified electrician.
- Vehicle compatibility: Compatible with Tesla vehicles.
- Charging speed: Up to 44 mi of range added per hour at 11.5 kW / 48 amp output
- App experience: Monitor and manage your charging schedule and usage from the Tesla app.
- Ease: Over-the-air firmware updates for continual product improvements and access control. Auto-sensing handle to open a Tesla charge port
- Variable amperage: Allows max output to be customized to an existing power supply and supports any output up to 48A. Possible max output configurations include: 48A, 40A, 32A, 24A, 16A, 12A.
- Vehicle compatibility: Compatible with Tesla vehicles.
- Charging speed: Up to 44 mi of range added per hour at 11.5 kW / 48 amp output
- App experience: Monitor and manage your charging schedule and usage from the Tesla app.
- Ease: Over-the-air firmware updates for continual product improvements and access control. Auto-sensing handle to open a Tesla charge port
- Variable amperage: Allows max output to be customized to an existing power supply and supports any output up to 48A. Possible max output configurations include: 48A, 40A, 32A, 24A, 16A, 12A.
Whats Included
- EV charger and user manual
- EV charger and user manual
Product Manuals
Q: Can the maximum output amperage be adjusted on this charger?
A: Yes, the Tesla Wall Connector allows for variable amperage, with a maximum output customizable up to 48A.
Q: Does this charger have WiFi connectivity?
A: Yes, the Tesla Wall Connector has WiFi connectivity for over-the-air firmware updates and access control.
Q: What is the length of the charging cable included with the Tesla Wall Connector?
A: The Tesla Wall Connector comes with a convenient 24ft charging cable.
Q: What is the warranty period for this Tesla Wall Connector?
A: The Tesla Wall Connector has a four-year warranty for residential use and a one-year warranty for commercial use.
Q: How many Tesla Wall Connectors can I link together for power sharing?
A: You can link up to six Wall Connectors for efficient power management.
Q: What is the maximum charging speed of this Tesla Wall Connector?
A: The Tesla Wall Connector can provide up to 44 miles of range per hour of charging, or 11.5kW on a 60A breaker.
A: A single Wall Connector can only charge one car at a time. Tesla does have a “load sharing” feature that allows multiple Wall Connectors to split the available power on a circuit between them and charge two cars at once but you would have to buy a second Wall Connector.
Q: About how much does it cost to install this wall connector?
A: Varies greatly as it depends on the following and other items: location of your home main electrical panel to your desired Tesla charger. This will probably require a subpanel, suitable breakers, disconnect, conduit, fittings, supports, 3 conductor wiring with ground (4 cables), wall penetrations, labor, equipment, electrical permits, and other items. The cost could vary anywhere from less than a thousand to a much larger amount. I was able to have my Tesla wall charger installed 4 years ago for less than 500 as it was connected to a spare 250vac 30 amp circuit in my garage. With this set up I was able to charge my Tesla up to 24 amps (80% of 30 amps) which provided about 16 miles per hour. The wall charger has internal pin switches which are set to match the supply voltage and amperage. Finally, get several bids from reliable and bonded electricians as this work has to be done correctly!
