Zephyr - 30 inches - Convertible - Island Range Hood - Stainless Steel/Glass
Delivery to
Need-haul away?
- We’ll haul away your old item and make sure it’s properly and safely recycled.
- We can also move it to another location in your home if the path is clear of obstructions.
- We can’t remove doors from your home (or a product) to make an item fit through a doorway
- Relocated appliances will not be connected to utilities
Related Item
Specifications
- Color FinishStainless steelProduct Height28 inchesProduct Width29.875 inchesProduct Depth25 inchesExhaust Vent LocationTopVent TypeDucted, Ductless
- Key Specs
- Color Finish: Stainless steel
- Product Height: 28 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 29.875 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 25 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Exhaust Vent Location: Top
- Vent Type: Ducted, Ductless
- Vent Style: Convertible (External vents pull air from the room and move it directly outside through a dedicated duct system. Recirculating vents pull the air through a filter so that it can be cleaned before being recycled back into the room. Convertible vents can be reconfigured from external ventilation to recirculating via installation of certain parts.)
- General
- Brand: Zephyr
- Model Number: BML-E30CG
- Product Name: Brisas 30 in. 600 CFM Curved Glass Island Range Hood with LED Lights
- Color: Stainless Steel/Glass
- Color Finish: Stainless steel
- Dimensions
- Product Height: 28 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Minimum Installation Height Above Cooktop: 24 inches
- Product Width: 29.875 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 25 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Standardized Width: 30 inches (An approximated measurement (exact width may differ slightly) determined by the manufacturer in accordance with industry standards. Standardized sizes are intended to assist consumers when purchasing appliances and planning for installation.)
- Product Weight: 71 pounds (The out of box weight of the item.)
- Features
- Exhaust Vent Location: Top
- Vent Type: Ducted, Ductless
- Vent Style: Convertible (External vents pull air from the room and move it directly outside through a dedicated duct system. Recirculating vents pull the air through a filter so that it can be cleaned before being recycled back into the room. Convertible vents can be reconfigured from external ventilation to recirculating via installation of certain parts.)
- Range Hood Type: Island
- Number of Fan Speeds: 3
- Temperature Sensor: false (Integrated sensor adjusts ventilation power as needed to accommodate high temperatures.)
- Delay Shut-Off: true (Use this feature after cooking to continue ventilating any fumes or odors. When time's up, the operation automatically shuts off.)
- Auto Fan Shut-Off: true
- Remote Control: false
- Damper Included: false
- Performance
- Maximum Air Flow Capacity: 600 cubic feet per minute (Maximum amount of air that the appliance can ventilate at its highest setting.)
- Minimum Air Flow Capacity: 290 cubic feet per minute (Minimum amount of air that the appliance will ventilate at its lowest setting.)
- Maximum Operating Sound Level: 6 sones (The perceived intensity of the operating sound produced by the product at its highest setting. The higher the sone rating, the louder the noise level.)
- Filter Info
- Filter Material: Mesh
- Dishwasher-Safe Filter: true
- Electrical Specification
- Amperage: 2.7 amperes (Strength of electrical current.)
- Voltage: 120 volts (Amount of power needed to support an electrical current.)
- Warranty
- Warranty - Parts: 1 year
- Warranty - Labor: 1 year
- Other
- UPC: 646328012570
Brisas BML can be installed in as little as 20 minutes. Designed with our unique 3-step installation system, Brisas BML breaks the arduous task of installing the entire range hood into a few easy steps. Weve even added an installation template to help you align your ceiling marks without the guesswork and upgraded the unit with LumiLight LED lighting and electronic touch controls. One look at the classic European design and gentle clear-glass curved canopy will have you sold. Love at first site? Yes. Its possible.
- Electronic Touch Controls: Electronic touch controls adjust the range hood blower and LED light levels, and enable the auto delay-off function.
- Airflow Control Technology (ACT): Airflow Control Technology or ACT is an exclusive technology that gives installers the ability to set the maximum CFM levels to meet local code requirements.
- LumiLight LED Lighting: LumiLight LED lights are eco-friendly and built to last with a lifetime of more than 25,000 hours.
- Dishwasher Safe Aluminum Mesh Filters: High-quality, dishwasher-safe aluminum mesh filters for improved capture and performance.
- Quick-Lock Installation System: Zephyrs Quick-Lock Installation System is an innovative, hassle-free method for installing island range hoods. A quick-lock motion lets the user assemble the frame, lift the hood and lock it into place on the frame and then assemble the 4-piece duct covers. This easy three-step process ensures the island hood is securely installed without additional build-out required.
- Optional Ductless Recirculating Kit: Ductless recirculating kit used when venting air outside your home is not possible. Smoke and odors pass through charcoal filters allowing purified air to be reintroduced into the kitchen.
- Optional Extension Duct Cover Kit: Extension duct cover kit to accommodate ceiling heights up to 12 ft see spec sheets for more details.
- Electronic Touch Controls: Electronic touch controls adjust the range hood blower and LED light levels, and enable the auto delay-off function.
- Airflow Control Technology (ACT): Airflow Control Technology or ACT is an exclusive technology that gives installers the ability to set the maximum CFM levels to meet local code requirements.
- LumiLight LED Lighting: LumiLight LED lights are eco-friendly and built to last with a lifetime of more than 25,000 hours.
- Dishwasher Safe Aluminum Mesh Filters: High-quality, dishwasher-safe aluminum mesh filters for improved capture and performance.
- Quick-Lock Installation System: Zephyrs Quick-Lock Installation System is an innovative, hassle-free method for installing island range hoods. A quick-lock motion lets the user assemble the frame, lift the hood and lock it into place on the frame and then assemble the 4-piece duct covers. This easy three-step process ensures the island hood is securely installed without additional build-out required.
- Optional Ductless Recirculating Kit: Ductless recirculating kit used when venting air outside your home is not possible. Smoke and odors pass through charcoal filters allowing purified air to be reintroduced into the kitchen.
- Optional Extension Duct Cover Kit: Extension duct cover kit to accommodate ceiling heights up to 12 ft see spec sheets for more details.
Whats Included
- Brisas 30 in. 600 CFM Curved Glass Island Range Hood with LED Lights in Stainless Steel
- Brisas 30 in. 600 CFM Curved Glass Island Range Hood with LED Lights in Stainless Steel
Q: What is the minimum installation height above the cooktop?
A: The minimum installation height above the cooktop is 24 inches.
Q: How many fan speeds does the range hood have?
A: This range hood has three fan speeds.
Q: Is the filter dishwasher-safe?
A: The range hood has a dishwasher-safe filter.
Q: How long is the manufacturer's warranty on parts?
A: The manufacturer's warranty on parts for the Brisas range hood is 1 year.
Q: What is the maximum air flow capacity of the range hood?
A: The maximum air flow capacity of this range hood is 600 cubic feet per minute.
Compare similar products
Brisas BML can be installed in as little as 20 minutes. Designed with our unique 3-step installation system, Brisas BML breaks the arduous task of installing the entire range hood into a few easy steps. Weve even added an installation template to help you align your ceiling marks without the guesswork and upgraded the unit with LumiLight LED lighting and electronic touch controls. One look at the classic European design and gentle clear-glass curved canopy will have you sold. Love at first site? Yes. Its possible.
Brisas BML can be installed in as little as 20 minutes. Designed with our unique 3-step installation system, Brisas BML breaks the arduous task of installing the entire range hood into a few easy steps. Weve even added an installation template to help you align your ceiling marks without the guesswork and upgraded the unit with LumiLight LED lighting and electronic touch controls. One look at the classic European design and gentle clear-glass curved canopy will have you sold. Love at first site? Yes. Its possible.
Experience ZLINE Attainable Luxury with industry-leading kitchen and bath products that provide an elevated luxury experience, all designed in Lake Tahoe, USA. The ZLINE GL19i-30 is a 30 in. professional island mount stainless steel range hood with a modern design and built-to-last quality, making it a great addition to any kitchen. This hood's high-performance, 400 CFM 4-speed motor will provide all the power you need to quietly and efficiently ventilate your stove while cooking. With its classic 430 grade stainless steel, this range hood contains rust, temperature, and corrosion-resistant properties to ensure a durable vent hood that will last for years to come. Enjoy modern features, including built-in LED lighting for an illuminated culinary experience and dishwasher-safe stainless steel baffle filters for easy clean-up. This island mount range hood has a convertible vent, so you can have a luxury range hood whether you need a ducted or ductless option. Enjoy easy installation and an easy recirculating conversion process.
Get a modern look and quiet, effective ventilation for all of your cooking with this 3-speed, 400 CFM motor class glass island kitchen hood. Noise reduction technology provides sound insulation and a special chimney design to deliver sound levels as low as 49 dBA at low speed. Perimetric Venting technology helps remove smoke and odors by concentrating hood suction to targeted zones on your cooktop. You'll be able to easily see what you're cooking with efficient LED task lighting, and the range hood's glass edge LED lighting senses when your kitchen lights dim and automatically turns on to act as a night-light.
| Pros for Zephyr - 30 inches - Convertible - Island Range Hood - Stainless Steel/Glass | |||
|---|---|---|---|
| There were no pros for this product— | There were no pros for this product— | Appearance | There were no pros for this product— |
Specs
Reviews
This product doesn't have any reviews yet.
