Zephyr - 54 inches - Externally Vented - Wall Range Hood - Stainless Steel
Need-haul away?
Related Item
Specifications
- Product Height18 inchesProduct Width53 7/8 inchesProduct Depth32 inchesExhaust Vent LocationTop/RearVent TypeDuctedVent StyleExternal
- Key Specs
- Product Height: 18 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 53 7/8 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 32 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Exhaust Vent Location: Top/Rear
- Vent Type: Ducted
- Vent Style: External (External vents pull air from the room and move it directly outside through a dedicated duct system. Recirculating vents pull the air through a filter so that it can be cleaned before being recycled back into the room. Convertible vents can be reconfigured from external ventilation to recirculating via installation of certain parts.)
- General
- Brand: Zephyr
- Model Number: AK7854CS
- Product Name: Cypress 54 in. 1200 CFM Wall Mount Range Hood with LED Light
- Color: Stainless Steel
- Dimensions
- Product Height: 18 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Minimum Installation Height Above Cooktop: 32 inches
- Maximum Installation Height Above Cooktop: 42 inches
- Product Width: 53 7/8 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 32 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Standardized Width: 54 inches (An approximated measurement (exact width may differ slightly) determined by the manufacturer in accordance with industry standards. Standardized sizes are intended to assist consumers when purchasing appliances and planning for installation.)
- Product Weight: 105.9 pounds (The out of box weight of the item.)
- Duct Shape: Round
- Round Duct Diameter: 10 inches
- Features
- Exhaust Vent Location: Top/Rear
- Vent Type: Ducted
- Vent Style: External (External vents pull air from the room and move it directly outside through a dedicated duct system. Recirculating vents pull the air through a filter so that it can be cleaned before being recycled back into the room. Convertible vents can be reconfigured from external ventilation to recirculating via installation of certain parts.)
- Range Hood Type: Wall
- Number of Fan Speeds: 3
- Temperature Sensor: false (Integrated sensor adjusts ventilation power as needed to accommodate high temperatures.)
- Control Type: Switch
- Delay Shut-Off: true (Use this feature after cooking to continue ventilating any fumes or odors. When time's up, the operation automatically shuts off.)
- Auto Fan Shut-Off: true
- Remote Control: false
- Damper Included: false
- Integrated Light(s): true
- Number of Lights: 4
- Number of Light Levels: 2
- Bulb Type Required: LED
- Bulb(s) Included: true
- Maximum Bulb Wattage: 6 watts
- Performance
- Maximum Air Flow Capacity: 1200 cubic feet per minute (Maximum amount of air that the appliance can ventilate at its highest setting.)
- Minimum Air Flow Capacity: 450 cubic feet per minute (Minimum amount of air that the appliance will ventilate at its lowest setting.)
- Filter Info
- Filter Material: Stainless Steel
- Dishwasher-Safe Filter: true
- Removable Grease Filter: true
- Number of Filters: 4
- Electrical
- Amperage: 9 amperes (Strength of electrical current.)
- Voltage: 120 volts (Amount of power needed to support an electrical current.)
- Certifications Listings & Approvals
- Product Safety Certifications and Standard(s): UL Listed (Lists the applicable certifications and/or standards, as stated by the manufacturer, in which the product has met the requirements for the assurance of quality and safety.)
- Other
- UPC: 646328010613
Cypress features a seamlessly contoured, fully welded and polished exterior, along with a corrosion resistant, 304–grade stainless steel canopy that houses high-performance professional stainless steel baffle filters that enhance airflow and are dishwasher safe. Three-speed metallic knob controls withstand extreme heat and moisture. Available with dual-level LumiLight LED lighting and an extended 32” depth for even more capture. An optional 12” duct cover and telescopic duct cover for 10’ to 12’ ceilings available.
- Professional Baffle Filters: High-airflow baffle filters that are dishwasher safe and ensure a lifetime of exceptional performance. (Part # 50210031)
- Welded and Polished Body: A welded and polished body ensures a high quality, seamless appearance.
- Vertical or Horizontal Ducting: This hood has the ability to vent either out the top or out the back.
- Optional Extension Duct Cover Kit: Extension duct cover kit to accommodate ceiling heights up to 12 ft. (see spec sheets for more details). (Part # Z1C-0178)
Product Manuals
Q: What is the maximum airflow capacity of this range hood?
A: The maximum airflow capacity of the Cypress 54 in. 1200 CFM Wall Mount Range Hood with LED Light by Zephyr is 1200 cubic feet per minute (CFM). This information can be found in the product specifications section of the provided context.
Q: What is the maximum and minimum operating sound level of this range hood?
A: The minimum operating sound level of this range hood is 3 sones, while the maximum operating sound level is 9 sones.
Q: What type of mount and control does this range hood have?
A: This range hood has a wall mount type and a switch control type.
Q: Does this range hood have a temperature sensor or a remote control?
A: This range hood does not have a temperature sensor, as specified in the product specifications. However, it does not have a remote control either. Therefore, the answer is: NO.
Q: What type of display does this range hood have?
A: The Cypress 54 in. 1200 CFM Wall Mount Range Hood with LED Light by Zephyr features an LCD display.
Q: How many fan speeds does this range hood have?
A: This Zephyr Cypress range hood has three fan speed settings. The metallic knob controls are designed to withstand extreme heat and moisture.
Q: What is the minimum and maximum installation height above the cooktop for this range hood?
A: The minimum installation height above the cooktop for this range hood is 30 inches, and the maximum installation height is 36 inches.
Q: What is the voltage requirement and amperage draw of this range hood?
A: The voltage requirement for this range hood is 120 volts, and the amperage draw is 9 amperes.
