Bosch - 300 Series 4.0 Cu. Ft. 15-Cycle Compact Electric Dryer - White
- Key Specs
- Product Height: 33.15 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 23.55 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 23 23/39 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Depth With Door Open: 42 4/5 inches (Measurement from the back of the product to its front, with door fully open.)
- Capacity: 4 cubic feet
- Steam Function: false (In washers, this feature may be employed before, during, or after the main wash cycle. Steam aids in stain removal, activating detergent, sanitizing, and softening wrinkles. In dryers, this feature can be used to remove wrinkles or quickly freshen clothing items.)
- Dryer Heating Source: Electric
- Moisture Sensor: true (This feature automatically senses moisture levels of the items in the cycle to determine the proper drying time.)
- Pedestal Model Compatibility: WMZ20500
- Matching Washer Model Number: WAT28400UC
- Stackable: true (To stack with similar products, ensure that the necessary support and/or installation hardware is in place to reduce safety hazards.)
- Stacking Kit Model Compatibility: WTZ20410UC
- App Compatible: false (The product can be connected to a program or software application on a mobile device, which then receives collected data from the product.)
- Color Finish: White
- General
- Product Name: 300 Series 4.0 Cu. Ft. 15-Cycle Compact Electric Dryer
- Brand: Bosch
- Model Number: WTG86400UC
- Vendor Collection: Bosch 300 Series (Part of a line of different product types, like kitchen appliances.)
- Color: White
- Color Finish: White
- Dimensions
- Product Height: 33.15 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 23.55 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 23 23/39 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Depth With Door Open: 42 4/5 inches (Measurement from the back of the product to its front, with door fully open.)
- Product Weight: 99 pounds (The out of box weight of the item.)
- Capacity
- Capacity: 4 cubic feet
- Features
- Steam Function: false (In washers, this feature may be employed before, during, or after the main wash cycle. Steam aids in stain removal, activating detergent, sanitizing, and softening wrinkles. In dryers, this feature can be used to remove wrinkles or quickly freshen clothing items.)
- Dryer Heating Source: Electric
- Automatic Temperature Control: true (This feature regulates hot and cold temperatures of the water or air within the appliance in order to keep them in the optimal range for each cycle.)
- Moisture Sensor: true (This feature automatically senses moisture levels of the items in the cycle to determine the proper drying time.)
- Child Lock: true (Setting that allows appliance to be temporarily locked to prevent use.)
- Delay Start: true (Allows you to program the appliance to automatically run at a later time. This feature helps you coordinate with your household’s water needs, noise preferences, and more. Additionally, operating your appliance during off-peak hours may reduce energy costs.)
- End-Of-Cycle Signal: true (An audible alert and/or visual indicator that notifies you when a pre-selected cycle is complete.)
- Time-Remaining Display: true
- Vibration Reduction: true (Additional features, such as sensors that adjust spin speeds or weights that counter unbalanced loads, help to minimize vibration for smoother, quieter operation.)
- Interior Light(s): false
- Drying Type: Condenser (Vented dryers take in room temperature air, heat it to dry clothing, then exhaust the resulting moisture-laden air outside through a duct, and typically have shorter trying times than ventless dryers. Ventless dryers (condenser and heat pump) do not require external ventilation. Instead, condensers cool the warm air and drain or store the resulting water. Heat pump systems reheat the cooled air for another cycle. Overall, ventless dryers are more energy efficient than vented.)
- Design
- Reversible Door Hinge: false
- Exhaust Vent Location: Ventless
- 4-Way Venting: false (The appliance has four possible vent locations (right, left, front, or rear), which allows for placement versatility.)
- Control Type: Dial, Button
- Control Location: Front panel
- Compact Design: true
- Drum Material: Metal
- Drying Rack: false
- Window: true
- Cycle Specifications
- Number Of Drying Cycles: 15
- Drying Cycles: Permanent Press, Permanent Press Extra Dry, Permanent Press Damp, Delicates, Quick 40, Time Dry, Hand Wash / Wool, Air fluff/No Heat, Cotton Dry, Cotton Extra Dry, Towels, Sanitize, Jeans, Heavy Duty, Quick Dry Auto (Dryers typically have multiple pre-programmed drying cycles to accommodate various fabrics and materials. These often include Normal/Regular, Permanent Press/Wrinkle Reduction, Heavy Duty, and Delicate/Gentle.)
- Options and Programs: Dry Level, Time Dry, Finish in, Wrinkle Block, Low Heat, Signal, Start/Pause, Child Lock
- Number of Temperature Settings: 4
- Temperature Settings: 4
- Compatibility
- Pedestal Available: true
- Pedestal Model Compatibility: WMZ20500
- Matching Washer Available: true
- Matching Washer Type: Front load
- Matching Washer Model Number: WAT28400UC
- Stackable: true (To stack with similar products, ensure that the necessary support and/or installation hardware is in place to reduce safety hazards.)
- Stacking Kit Included: false
- Stacking Kit Model Compatibility: WTZ20410UC
- Included
- Power Cord Included: true (Connects your product to an electrical outlet, allowing for immediate use (provided that other installation requirements are met).)
- Filter Info
- Self-Cleaning Filter: false (Filter that requires little to no cleaning maintenance.)
- Electrical Specification
- Amperage: 13 amperes (Strength of electrical current.)
- Voltage: 240 volts (Amount of power needed to support an electrical current.)
- Certifications Listings & Approvals
- ENERGY STAR Certified: false (Devices carrying the ENERGY STAR service mark, such as computer products and peripherals, kitchen appliances, and other products, generally use 20% to 30% less energy than required by federal standards.)
- ADA Compliant: true (Meets standards set by the Disabilities Act (ADA) Standards for Accessible Design)
- Connectivity
- App Compatible: false (The product can be connected to a program or software application on a mobile device, which then receives collected data from the product.)
- Other
- UPC: 825225916871
Bosch 300 Series electric dryer: Take care of your delicates, heavy-duty loads and more with customized care in this dryer, which features 15 cycles and a variety of options, including delay-start, to help you dry your clothing efficiently. The child lock helps prevent unsupervised or accidental use.
- Accommodates approximately 16 bath towels at once: 4.0 cu. ft. capacity lets you wash large loads, so you spend less time doing laundry.
- Find the right cycle for every load: 15 drying cycles, including jeans and heavy-duty, allow you to dry clothes efficiently.
- Ensure consistent heating: Automatic dry control helps ensure each load is dried evenly.
- Automatically adjusts temperature and time: Moisture sensor measures moisture in the drum and alters the cycle to deliver optimal fabric care.
- Low vibration and low noise: 67dBA operation minimizes disruptive sounds.
- Front-load design: Offers efficiency. Stackable with optional kit WTZ11400 or WTZ20410 (not included) to reduce the need to bend over.
- No ducting required: Condensation drying eliminates the need for additional ductwork, and you can plug your compatible WAT28402UC, WAT28401UC or WAT28400UC washer (not included) directly into the dryer for simple installation.
- Child lock: Prevents accidental or unsupervised use.
Whats Included
- 300 Series 4.0 Cu. Ft. 15-Cycle Compact Electric Dryer
- 4-prong plug, fill and drain hoses
- Owner's manual
A: I, too had the same problem. I was stunned and disappointed, until I started playing around with the settings. If you press DRY LEVEL, you will be offered 3 choices...+1, +2, & +3. I chose +3 and my load of 1 towel set (hand, wash & bath), 2 dish towels and 1 set of queen size sheets (including pillow cases) came out bone dry! I love my drier now! Nancy
Q: what does the key lock light mean?
A: HI dav333. Thank you for your question. The child lock may have been turned on. You can secure the dryer against inadvertent changing of the set functions. To do this, activate the childproof lock after cycle start. To Activate/Deactivate, touch Time dry and Finish in buttons at the same time for 3 seconds. In the display field, you will see the D symbol light indicating the childproof lock is active. NOTICE: The childproof lock will remain activated until the next cycle start even after switching the machine off. You must deactivate the childproof lock before the next cycle and, if necessary, activate it again after starting the cycle.
Q: Can you fit a queen size comforter inside of this washer?
A: Maybe, but it would very full and might not wash it right.
A: Hi Susan, thank you for your question. Yes, the dryer plugs in to a standard American outlet. This unit comes with a 4-prong pigtail but can easily be switched to a 3-prong depending on what style you have in your home. Also, the matching washer is 220v and plugs into the dryer so you will not need to worry so long as you are purchasing as a set.
Q: Exactly how is the dry level changed?
A: You press dryness level on the control panel, and it will display +1, +2, or +3, for progressively dryer levels of drying.
A: No, this does not come with a standard 3 prong power cable.
A: It is ventless and in my experience doesn't give off any steam whatsoever. Hopefully that's helpful!
A: Hi Judy. Thank you for your question. The 300 Series Compact Dryer is ventless and does not require a vent kit.
