Eaton - 50 amps Plug In 2-Pole Circuit Breaker
Amperage
50 amperesAbout This Item
- General
- Brand: Eaton
- Model Number: 786676363051
- Product Name: Eaton 50 amps Plug In 2-Pole Circuit Breaker
- Power
- Amperage: 50 amperes (Strength of electrical current.)
- Maximum Voltage: 240 volts
- Ground Fault Interrupter: false
- Arc Fault Circuit Interrupter: false
- Certifications Listings & Approvals
- Product Safety Certifications and Standard(s): CSA Listed, UL Listed (Lists the applicable certifications and/or standards, as stated by the manufacturer, in which the product has met the requirements for the assurance of quality and safety.)
- Dimensions
- Product Height: 2.93 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 1.96 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 3 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Product Weight: 0.7 pounds (The out of box weight of the item.)
- Other
- UPC: 786676363051
Eaton’s 50‑amp plug‑in 2‑pole circuit breaker is the BR250 (Type BR), a standard thermal‑magnetic breaker used for 120/240‑volt branch circuits such as electric ranges, water heaters, RV hookups, and large air‑conditioning units in Eaton, Cutler‑Hammer, Bryant, Westinghouse, Challenger, and Novaline loadcenters. It installs in two adjacent spaces, provides 10 kAIC short‑circuit protection, uses #12–4 AWG Cu/Al wiring, and is UL‑listed and CSA‑approved for safe, code‑compliant residential and light‑commercial applications.
- Feature 1: Packaging Type: Bulk
- Feature 2: Product Series: Type BR
