JCPower Audio Systems - RMINI-Series 600 Watt Compact 4-Channel Amplifier - Black
JCPower Audio Systems - RMINI-Series 600 Watt Compact 4-Channel Amplifier - Black
FREE shipping to
Specifications
- Continuous Watts x Channel @ Ohms140 Watts x 4 @ 4 ohms, 210 Watts x 4 @ 2 ohms, 420 Watts x 2 @ 4 ohms bridgedAmplifier ClassDNumber Of Channels4Bass BoostNoneBridgeableYesLow-Pass CrossoverVariable
- Key Specs
- Continuous Watts x Channel @ Ohms: 140 Watts x 4 @ 4 ohms, 210 Watts x 4 @ 2 ohms, 420 Watts x 2 @ 4 ohms bridged
- Amplifier Class: D (An amplifier's mode of operation, specifically the conditions in which its electrical current flows for the duration of an audio signal, determines its class. Each class has its strengths and weaknesses when it comes to power efficiency, levels of crossover distortion, and overall sound quality.)
- Number Of Channels: 4
- Bass Boost: None (Circuitry that boosts the bass response of the amplifier, improving audio reproduction enhancing the sound of low frequencies. Fixed boost means the level of bass response is preset, whereas variable boost allows the user to make adjustments.)
- Bridgeable: true (Bridging an amplifier increases the power it supplies to the speaker(s).)
- Low-Pass Crossover: Variable (Devices with this function allow only audio frequencies below a chosen cut-off frequency to pass through to a speaker or sound system. A device may have a cut-off frequency predetermined by its manufacturer (fixed), multiple cut-off frequency options to choose from (selectable), or have the capability for the frequency to be configured by the user (variable).)
- High-Pass Crossover: Variable (Devices with this function allow only audio frequencies above a chosen cut-off frequency to pass through to a speaker or sound system. A device may have a cut-off frequency predetermined by its manufacturer (fixed), multiple cut-off frequency options to choose from (selectable), or have the capability for the frequency to be configured by the user (variable).)
- Speaker-Level Inputs: false (Also referred to as high-level inputs. Enables the amplifier to receive a sound signal from another device that does not have RCA, or low-level, inputs.)
- General
- Brand: JCPower Audio Systems
- Model Number: RMINI-600.4Dv2
- Product Name: RMINI-Series 600 Watt Compact 4-Channel Amplifier
- Color: Black
- Mounting Hardware Included: true
- Audio Power
- Continuous Watts x Channel @ Ohms: 140 Watts x 4 @ 4 ohms, 210 Watts x 4 @ 2 ohms, 420 Watts x 2 @ 4 ohms bridged
- Total Power Handling Maximum: 600 watts
- Amplifier Class: D (An amplifier's mode of operation, specifically the conditions in which its electrical current flows for the duration of an audio signal, determines its class. Each class has its strengths and weaknesses when it comes to power efficiency, levels of crossover distortion, and overall sound quality.)
- Audio
- Number Of Channels: 4
- Minimum Frequency Response: 20 hertz (Describes the maximum range of frequencies or musical tones a product can reproduce, from very low tones to very high treble tones. The minimum frequency or musical tone the speaker can reproduce. High treble tones have higher frequencies while low tones and deep bass have lower frequencies.)
- Maximum Frequency Response: 20 kilohertz (Describes the maximum range of frequencies or musical tones a product can reproduce, from very low tones to very high treble tones. The maximum frequency or musical tone the speaker can reproduce. High treble tones have higher frequencies while low tones and deep bass have lower frequencies.)
- Total Harmonic Distortion: 0.3 percent (Measurement of the harmonic sound distortion. The lower the percentage, the cleaner the sound.)
- Signal-to-Noise Ratio (SNR): 90 decibels (The ratio of the desired signal's strength to the level of background noise. A ratio higher than 1:1, which equates to greater than 0 decibels, indicates more signal than noise.)
- Bass Boost: None (Circuitry that boosts the bass response of the amplifier, improving audio reproduction enhancing the sound of low frequencies. Fixed boost means the level of bass response is preset, whereas variable boost allows the user to make adjustments.)
- Features
- Bridgeable: true (Bridging an amplifier increases the power it supplies to the speaker(s).)
- Low-Pass Crossover: Variable (Devices with this function allow only audio frequencies below a chosen cut-off frequency to pass through to a speaker or sound system. A device may have a cut-off frequency predetermined by its manufacturer (fixed), multiple cut-off frequency options to choose from (selectable), or have the capability for the frequency to be configured by the user (variable).)
- High-Pass Crossover: Variable (Devices with this function allow only audio frequencies above a chosen cut-off frequency to pass through to a speaker or sound system. A device may have a cut-off frequency predetermined by its manufacturer (fixed), multiple cut-off frequency options to choose from (selectable), or have the capability for the frequency to be configured by the user (variable).)
- MOSFET Power Supply: true (A specific type of power supply with the advantages of high switching speed and efficiency at low voltages.)
- Bluetooth Enabled: false (The device is capable of communicating with another device via Bluetooth, provided they are within the required range of each other. A Bluetooth-enabled device must also be the same Bluetooth version or higher than the accessory it is intended to pair with.)
- Remote Control Included: No
- Marine: false
- Fan Cooled: true
- Input
- Line-Level Inputs: true (Also referred to as low-level inputs. Enables the amplifier to receive a sound signal from another device via RCA cables.)
- Speaker-Level Inputs: false (Also referred to as high-level inputs. Enables the amplifier to receive a sound signal from another device that does not have RCA, or low-level, inputs.)
- Dimensions
- Product Height: 1.86 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 8.11 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 5 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Product Weight: 5 pounds (The out of box weight of the item.)
- Warranty
- Warranty - Parts: 2 years
- Other
- UPC: 618528024202
The JCPower RMINI600.4Dv2 4 channel amp redefines car audio convenience and performance. This compact Class D amplifier now delivers a significant increase in power and sound quality while maintaining a compact size, making it an ideal choice for a wide range of vehicles and audio setups.
- Powerful Performance in a Compact Package: This amplifier delivers impressive power with up to 210W RMS per channel at 2 ohms, 420W RMS x 2 when bridged, and increased headroom for demanding speakers. With up to 600W of peak power in certain configurations, it provides a dynamic and powerful listening experience.
- Space-Saving Solution: With its newly optimized dimensions of 8.11″ x 5.0″ x 1.86″, the RMINI600.4Dv2 remains a compact amplifier that’s easy to install in tight spaces. Whether you want to hide your amplifier away or simply minimize clutter, this amp is the perfect solution.
- Efficient Class D Technology: This compact Class D amplifier uses high-efficiency Class D technology to minimize wasted energy and deliver more power to your speakers for louder, cleaner bass.
- Versatile Applications: The RMINI600.4Dv2 is a versatile 4-channel Class D amplifier capable of powering factory speakers, SPL-oriented speakers, component systems, and coaxial speakers for louder, clearer, and more detailed sound.
Whats Included
- RMINI-600.4Dv2 4 Channel Amplifier, Mounting Screws
