Rotel - A14MKII 80W 2-Ch Integrated Stereo Amplifier - Black
Color
BlackMore Buying Options
Related Item
Specifications
- Continuous Watts x Channel @ Ohms80 Watts x 2 @ 8 OhmsNumber of Channels2Number of Audio Zones1Audio Only Inputs1 x Phono, 2 x Optical digital audio, 2 x Coaxial digital audio, 1 x USB-B, Unbalanced RCANetwork Connector(s)1 x LAN, 1 x RS-232Preamp OutputsYes
- Key Specs
- Continuous Watts x Channel @ Ohms: 80 Watts x 2 @ 8 Ohms
- Number of Channels: 2 (The number of discrete channels of sound output. This can be a single number or multiple numbers separated by decimal(s). The first number is the primary, horizontally directed audio channels. The number after the first decimal, if applicable, is the number of subwoofer outputs or channels. The number after the second decimal, if applicable, is the number of height or atmospheric channels designed to immerse the listener by producing overhead sound effects.)
- Number of Audio Zones: 1 (Audio zones, typically designated by rooms in a home, are areas in which all speakers are dependent on the same sound source. Whether a zone encompasses one or multiple rooms, the receiver or preamp/processor is used to control all aspects of its audio and is able to select which zones receive sound.)
- Audio Only Inputs: 1 x Phono, 2 x Optical digital audio, 2 x Coaxial digital audio, 1 x USB-B, Unbalanced RCA
- Network Connector(s): 1 x LAN, 1 x RS-232
- Preamp Outputs: true
- General
- Brand: Rotel
- Model Number: A14MKII Black
- Product Name: A14MKII 80W 2-Ch Integrated Stereo Amplifier
- Color: Black
- Audio
- Continuous Watts x Channel @ Ohms: 80 Watts x 2 @ 8 Ohms
- Maximum Watts x Channel @ Ohms: 150 Watts x 2 @ 4 Ohms (This is the maximum load the speaker, subwoofer or amp can drive.)
- Total Power Handling: 150 watts (How much amplifier (amplified) power (wattage) that can be handled before damaging the product.)
- Number of Channels: 2 (The number of discrete channels of sound output. This can be a single number or multiple numbers separated by decimal(s). The first number is the primary, horizontally directed audio channels. The number after the first decimal, if applicable, is the number of subwoofer outputs or channels. The number after the second decimal, if applicable, is the number of height or atmospheric channels designed to immerse the listener by producing overhead sound effects.)
- Number of Audio Zones: 1 (Audio zones, typically designated by rooms in a home, are areas in which all speakers are dependent on the same sound source. Whether a zone encompasses one or multiple rooms, the receiver or preamp/processor is used to control all aspects of its audio and is able to select which zones receive sound.)
- Minimum Frequency Response: 10 hertz (Describes the maximum range of frequencies or musical tones a product can reproduce, from very low tones to very high treble tones. The minimum frequency or musical tone the speaker can reproduce. High treble tones have higher frequencies while low tones and deep bass have lower frequencies.)
- Total Harmonic Distortion: 0.018 percent (Measurement of the harmonic sound distortion. The lower the percentage, the cleaner the sound.)
- Maximum Frequency Response: 100 kilohertz (Describes the maximum range of frequencies or musical tones a product can reproduce, from very low tones to very high treble tones. The maximum frequency or musical tone the speaker can reproduce. High treble tones have higher frequencies while low tones and deep bass have lower frequencies.)
- Amplifier Class: AB (An amplifier's mode of operation, specifically the conditions in which its electrical current flows for the duration of an audio signal, determines its class. Each class has its strengths and weaknesses when it comes to power efficiency, levels of crossover distortion, and overall sound quality.)
- Amplifier Type: Integrated amplifiers
- Signal-to-Noise Ratio (SNR): 100 decibels (The ratio of the desired signal's strength to the level of background noise. A ratio higher than 1:1, which equates to greater than 0 decibels, indicates more signal than noise.)
- Sensitivity: 75 decibels
- Bass Boost: Variable (Circuitry that boosts the bass response of the amplifier, improving audio reproduction enhancing the sound of low frequencies. Fixed boost means the level of bass response is preset, whereas variable boost allows the user to make adjustments.)
- Inputs
- Audio Only Inputs: 1 x Phono, 2 x Optical digital audio, 2 x Coaxial digital audio, 1 x USB-B, Unbalanced RCA
- Video Only Inputs: No video only inputs (The number and type of video signal only inputs the product has.)
- Network Connector(s): 1 x LAN, 1 x RS-232
- Speaker-Level Inputs: false (Also referred to as high-level inputs. Enables the amplifier to receive a sound signal from another device that does not have RCA, or low-level, inputs.)
- Line-Level Inputs: true (Also referred to as low-level inputs. Enables the amplifier to receive a sound signal from another device via RCA cables.)
- Outputs
- Preamp Outputs: true
- Speaker Connection Type: RCA
- Video Only Outputs: No video only outputs (The number and type of video signal only outputs the product has.)
- Features
- App Compatible: false (The product can be connected to a program or software application on a mobile device, which then receives collected data from the product.)
- Fan Cooled: false
- Connectivity
- Wireless Multi-Room Audio: false (Technology that allows multiple speakers and/or soundbars to be connected wirelessly and play audio in separate rooms.)
- Dimensions
- Product Height: 4 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 17 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 14 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Product Weight: 20 pounds (The out of box weight of the item.)
- Warranty
- Warranty - Parts: 5 years
- Warranty - Labor: 5 Years
- Other
- UPC: 672563266119
Introducing the A14MKII Integrated Amplifier, your gateway to an audio experience like no other. With 80 Watts per channel of Class AB amplification, it breathes life into your favorite sources, be it analog, digital, PC-USB with MQA, wireless aptX HD, AAC Bluetooth, or Moving Magnet Phono stage. Its meticulously tuned power supply, DAC, and amplifier circuits promise endless hours of entertainment, ensuring your music journey remains unforgettable.
- Class AB Amplification: The A14MKII is the flagship model in the 14 Series family of Rotel products delivering 80 Watts of Class AB amplification into 8 Ohm speakers powered by Rotel's in-house manufactured, oversized toroidal transformer and an array of 4 high efficiency slit-foil bulk storage capacitors delivering an effortless acoustic performance.
- Digital to Analog Conversion: A fully redesigned Digital to Analog circuit topology utilizes a Texas Instruments 32-bit/384kHz DAC with exhaustive tuning and hand selection of all critical components delivering a fuller, richer and more balanced presentation of the music.
- Unlock the Magic of Vinyl: For vinyl enthusiasts, the included Moving Magnet Phono stage brings your records to life.
- Digital Audio Excellence: The A14MKII supports PC-USB with MQA, high quality wireless aptX HD and AAC Bluetooth streaming.
- Class AB Amplification: The A14MKII is the flagship model in the 14 Series family of Rotel products delivering 80 Watts of Class AB amplification into 8 Ohm speakers powered by Rotel's in-house manufactured, oversized toroidal transformer and an array of 4 high efficiency slit-foil bulk storage capacitors delivering an effortless acoustic performance.
- Digital to Analog Conversion: A fully redesigned Digital to Analog circuit topology utilizes a Texas Instruments 32-bit/384kHz DAC with exhaustive tuning and hand selection of all critical components delivering a fuller, richer and more balanced presentation of the music.
- Unlock the Magic of Vinyl: For vinyl enthusiasts, the included Moving Magnet Phono stage brings your records to life.
- Digital Audio Excellence: The A14MKII supports PC-USB with MQA, high quality wireless aptX HD and AAC Bluetooth streaming.
Whats Included
- Rotel A14MKII Amplifier
- Power Cord
- Manual
- Remote
- Rotel A14MKII Amplifier
- Power Cord
- Manual
- Remote
Q: Does the amplifier have a built-in phono stage?
A: This amplifier includes a Moving Magnet Phono stage.
Q: What is the amplifier's warranty period?
A: The amplifier's parts and labor are covered under the manufacturer's warranty for 5 years.
Q: What types of audio inputs does the amplifier support?
A: The A14 MKII Integrated Amplifier supports analog, digital, PC-USB with MQA, wireless aptXTM, AAC Bluetooth, and Moving Magnet Phono stage audio inputs.
Q: What is the amplifier's power output per channel?
A: The amplifier's power output is 80 watts per channel at 8 ohms.
Q: What are the amplifier's dimensions?
A: The amplifier's dimensions are 17 inches wide, 18.5 inches deep, and 7.75 inches high.
Q: What is the amplifier's signal-to-noise ratio?
A: The amplifier's signal-to-noise ratio is 103 decibels.
