SVS - PB17-Ultra R|Evolution 17" Powered Subwoofer - Piano Gloss Black
SVS - PB17-Ultra R|Evolution 17" Powered Subwoofer - Piano Gloss Black
Color
Piano Gloss BlackFREE delivery to
Specialty ItemDelivery of this item is restricted to drop-off onlySpecifications
- RMS Power0 wattsWoofer Size17 inches
- Key Specs
- RMS Power: 0 watts (The maximum amount of continuous power the device is able to handle.)
- Woofer Size: 17 inches
- General
- Brand: SVS
- Model Number: PB17-ULTRA-PIANO GLOSS
- Product Name: PB17-Ultra R|Evolution 17" Powered Subwoofer
- Color: Piano Gloss Black
- Audio
- Minimum Frequency Response: 12 hertz (Describes the maximum range of frequencies or musical tones a product can reproduce, from very low tones to very high treble tones. The minimum frequency or musical tone the speaker can reproduce. High treble tones have higher frequencies while low tones and deep bass have lower frequencies.)
- Maximum Frequency Response: 0.32 kilohertz (Describes the maximum range of frequencies or musical tones a product can reproduce, from very low tones to very high treble tones. The maximum frequency or musical tone the speaker can reproduce. High treble tones have higher frequencies while low tones and deep bass have lower frequencies.)
- Amplifier Class: D (An amplifier's mode of operation, specifically the conditions in which its electrical current flows for the duration of an audio signal, determines its class. Each class has its strengths and weaknesses when it comes to power efficiency, levels of crossover distortion, and overall sound quality.)
- Enclosure Type: Ported
- Firing Direction: Front
- Subwoofer Type: Powered (Passive subwoofers require an external amplifier, such as the one driving the main speakers in the system, for power. Active subwoofers, on the other hand, have a designated amplifier (one that isn't shared with other speakers) for power as well as line-level crossover.)
- Enclosed: true
- Features
- App Compatible: true (The product can be connected to a program or software application on a mobile device, which then receives collected data from the product.)
- Controls: Low pass filter, Phase, Volume
- Connectivity
- Network Connector(s): 1 x IR in
- Subwoofer Connection Type: RCA
- Dimensions
- Product Height: 25 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 21.7 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 29.3 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Product Weight: 165 pounds (The out of box weight of the item.)
- Material
- Woofer Composition: Glass fiber
- Included
- Cable(s) Included: Power
- Warranty
- Warranty - Parts: 5 years
- Warranty - Labor: 5 Years
- Other
- UPC: 850029050889
Born from three decades of SVS design expertise, the PB17-Ultra R|Evolution subwoofer represents the pinnacle of subwoofer performance. Featuring a massive 17" driver with dual 8" coils, powered by a powerful amplifier with DSP intelligence, the subwoofer incorporates advanced power management and auto EQ room correction. The benchmark for reference subwoofer experiences has arrived. Experience breathtaking low frequencies with unerring accuracy, room-shaking output, and stop-on-a-dime control. From the deep, chest-thumping slam of cinematic soundtracks to the delicate nuance of musical bass, every note is rendered truthfully. Whether heard or felt, low frequencies are delivered effortlessly without sacrificing sonic fidelity or refinement. With extension down to 12Hz, below the threshold of human hearing, the PB17-Ultra R|Evolution brings sound to life with visceral, jaw-dropping impact.
- High-excursion 17" driver: The glass fiber composite cone, combined with a 55 lb. toroidal ferrite magnet motor assembly, delivers massive low-frequency output down to 13Hz with pinpoint accuracy and control.
- Acoustically tuned triple-ported cabinet design: Three 4” ports optimize airflow, while rigid internal bracing ensures a resonance-free environment for uncompromised subwoofer performance.
- 8" dual voice coils: The dual voice coil design ensures stable and consistent transfer of motor electromagnetic energy to the 17" cone to maintain precise driver control with maximum efficiency.
- Dual mono amplifier: Each of the two Class-D mono-block amplifiers, featuring MOSFET output stages, powers one of the dual voice coils, doubling the current fed to the driver. This design achieves effortless output while reducing continuous current demand from the home’s AC circuit.
- Switch mode power supply: Time-aligns the AC voltage with the AC current, while filtering and stabilizing incoming voltage to optimize signal quality and audio performance.
- 295MHz DSP: The advanced processor optimizes every aspect of subwoofer output and usability to maintain flawless performance and intuitive control.
- Smartphone app: Provides a convenient way to control all DSP functions, including volume, six-band parametric equalizer, low-pass filter, phase, polarity, room gain, port tuning, system settings, custom presets, and auto room EQ.
Whats Included
- SVS PB17-Ultra R|Evolution 17" Powered Subwoofer
- Removable grile
- Detachable power cord
- Port plugs
Product Manuals
Q: Can the subwoofer be controlled using an app?
A: Yes, the subwoofer is compatible with an app.
Q: Does the subwoofer come with any cables?
A: The subwoofer includes a power cable.
Q: What are the dimensions of the subwoofer?
A: The subwoofer has a depth of 29.3 inches, a height of 25 inches, and a width of 21.7 inches.
Q: Is the subwoofer's amplifier class D?
A: The subwoofer's amplifier is class D.
Q: Can the subwoofer be controlled using an app?
A: This subwoofer is app compatible.
Q: What is the minimum frequency response of the subwoofer?
A: The minimum frequency response of the subwoofer is 12 hertz.
Q: What is the maximum frequency response of the subwoofer?
A: The maximum frequency response of the subwoofer is 0.32 kilohertz.
Q: Is the subwoofer enclosed or open-air?
A: This subwoofer is enclosed.
