SVS - SB17-Ultra R|Evolution 17" Powered Subwoofer - Black Oak Veneer
SVS - SB17-Ultra R|Evolution 17" Powered Subwoofer - Black Oak Veneer
Color
Black Oak VeneerFREE delivery to
Specialty ItemDelivery of this item is restricted to drop-off onlySpecifications
- RMS Power0 wattsWoofer Size17 inches
- Key Specs
- RMS Power: 0 watts (The maximum amount of continuous power the device is able to handle.)
- Woofer Size: 17 inches
- General
- Brand: SVS
- Model Number: SB17-ULTRA-BLACK OAK
- Product Name: SB17-Ultra R|Evolution 17" Powered Subwoofer
- Color: Black Oak Veneer
- Audio
- Minimum Frequency Response: 15 hertz (Describes the maximum range of frequencies or musical tones a product can reproduce, from very low tones to very high treble tones. The minimum frequency or musical tone the speaker can reproduce. High treble tones have higher frequencies while low tones and deep bass have lower frequencies.)
- Maximum Frequency Response: 0.32 kilohertz (Describes the maximum range of frequencies or musical tones a product can reproduce, from very low tones to very high treble tones. The maximum frequency or musical tone the speaker can reproduce. High treble tones have higher frequencies while low tones and deep bass have lower frequencies.)
- Amplifier Class: D (An amplifier's mode of operation, specifically the conditions in which its electrical current flows for the duration of an audio signal, determines its class. Each class has its strengths and weaknesses when it comes to power efficiency, levels of crossover distortion, and overall sound quality.)
- Enclosure Type: Sealed
- Firing Direction: Front
- Subwoofer Type: Powered (Passive subwoofers require an external amplifier, such as the one driving the main speakers in the system, for power. Active subwoofers, on the other hand, have a designated amplifier (one that isn't shared with other speakers) for power as well as line-level crossover.)
- Enclosed: true
- Features
- App Compatible: true (The product can be connected to a program or software application on a mobile device, which then receives collected data from the product.)
- Controls: Low pass filter, Phase, Volume
- Connectivity
- Network Connector(s): 1 x IR in
- Subwoofer Connection Type: RCA
- Dimensions
- Product Height: 20 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 19.5 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 21.2 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Product Weight: 124 pounds (The out of box weight of the item.)
- Material
- Woofer Composition: Glass fiber
- Included
- Cable(s) Included: Power
- Warranty
- Warranty - Parts: 5 years
- Warranty - Labor: 5 Years
- Other
- UPC: 850029050872
Born from three decades of SVS design expertise, the SB17-Ultra R|Evolution subwoofer represents the pinnacle of subwoofer performance. Featuring a massive 17" driver with dual 8" coils, powered by a powerful amplifier with DSP intelligence, the subwoofer incorporates advanced power management and auto EQ room correction. The benchmark for reference subwoofer experiences has arrived. Experience breathtaking low frequencies with unerring accuracy, musicality, and precise control. From the deep, chest-thumping slam of cinematic soundtracks to the delicate nuance of musical bass, every note is rendered truthfully. Whether heard or felt, low frequencies are delivered effortlessly without sacrificing sonic fidelity or refinement. With extension down to 15Hz, below the threshold of human hearing, the SB17-Ultra R|Evolution brings sound to life with visceral, jaw-dropping impact.
- High-excursion 17" driver: The glass fiber composite cone, combined with a 55 lb. toroidal ferrite magnet motor assembly, delivers massive low-frequency output down to 15Hz with pinpoint accuracy and control.
- Acoustically tuned sealed cabinet design: Constructed with double-thick MDF and rigid internal bracing, the cabinet creates a resonance-free environment for pitch-perfect accuracy, free from unwanted resonances and coloration.
- 8" dual voice coils: The dual voice coil design ensures stable and consistent transfer of motor electromagnetic energy to the 17" cone to maintain precise driver control with maximum efficiency.
- Dual mono amplifier: Each of the two Class-D mono-block amplifiers, featuring MOSFET output stages, powers one of the dual voice coils, doubling the current fed to the driver. This design achieves effortless output while reducing continuous current demand from the home’s AC circuit.
- Switch mode power supply: Time-aligns the AC voltage with the AC current, while filtering and stabilizing incoming voltage to optimize signal quality and audio performance.
- 295MHz DSP: The advanced processor optimizes every aspect of subwoofer output and usability to maintain flawless performance and intuitive control.
- Smartphone app: Provides a convenient way to control all DSP functions, including volume, six-band parametric equalizer, low-pass filter, phase, polarity, room gain, port tuning, system settings, custom presets, and auto room EQ.
Whats Included
- SVS SB17-Ultra R|Evolution 17" Powered Subwoofer
- Removable grille
- Detachable power cord
Product Manuals
Q: What is the minimum frequency response of the subwoofer?
A: The minimum frequency response of the subwoofer is 15 hertz.
Q: What are the dimensions of the subwoofer?
A: The subwoofer is 20 inches high, 19.5 inches wide, and 21.2 inches deep.
Q: Is the subwoofer's amplifier class D?
A: The subwoofer's amplifier class is Class D.
Q: What is the size of the subwoofer's woofer?
A: The subwoofer's woofer size is 17 inches.
Q: Does the subwoofer come with any cables?
A: The subwoofer includes a power cable.
Q: What is the minimum frequency response?
A: The minimum frequency response is 15 hertz.
Q: Can the subwoofer be controlled using an app?
A: This subwoofer is app compatible.
Q: What is the purpose of the dual 8" coils in the subwoofer's driver?
A: The dual 8" coils in the subwoofer's driver contribute to the subwoofer's ability to produce breathtaking low frequencies with accuracy, musicality, and precise control.
