Specifications
- Color FinishStainless steelProduct Height36 inchesProduct Width29 7/8 inchesProduct Depth28 7/8 inchesDepth Without Handle26 3/8 inchesDepth With Handle28 7/8 inches
- Key Specs
- Color Finish: Stainless steel
- Product Height: 36 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 29 7/8 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 28 7/8 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Depth Without Handle: 26 3/8 inches (Measurement from the back of the product to its front (with door closed), not including handle.)
- Depth With Handle: 28 7/8 inches (Measurement from the back of the product to its front (with door closed), including the handle.)
- Range Type: Slide-In (Freestanding ranges have finished sides and a backguard where the oven controls are located; this style allows for the most versatility in placement. Slide-in ranges may have unfinished sides and are wider at the top to overlap the countertop on each side, allowing for a built-in appearance. Drop-in ranges are also known for their built-in style and are designed to fit custom cabinetry or countertops.)
- Oven Cleaning Method: Steam cleaning (There are several ways to clean the inside of your oven. Depending on the model, it might require manual cleaning or have a self-clean function. Self-clean functions use either high heat or steam to break down grease and food debris within the cooking cavity.)
- Single/Double Oven: Single Oven
- Cooktop Surface Type: Grate (On electric cooktops, coil elements are typically more durable and tend to provide more evenly conducted heat than smoothtops. However, smoothtops may be easier to clean and have a distinctive streamlined appearance.)
- Number of Burners: 4
- App Compatible: false (The product can be connected to a program or software application on a mobile device, which then receives collected data from the product.)
- General
- Brand: KitchenAid
- Model Number: KSDG950ESS
- Product Name: 6.4 Cu. Ft. Self-Cleaning Slide-In Dual Fuel Convection Range
- Color: Stainless steel
- Color Finish: Stainless steel
- Dimensions
- Product Height: 36 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 29 7/8 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 28 7/8 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Standardized Width: 30 inches (An approximated measurement (exact width may differ slightly) determined by the manufacturer in accordance with industry standards. Standardized sizes are intended to assist consumers when purchasing appliances and planning for installation.)
- Depth Without Handle: 26 3/8 inches (Measurement from the back of the product to its front (with door closed), not including handle.)
- Depth With Handle: 28 7/8 inches (Measurement from the back of the product to its front (with door closed), including the handle.)
- Product Weight: 183 pounds (The out of box weight of the item.)
- Capacity
- Oven Capacity: 6.4 cubic feet (Standard ovens typically have capacities of about 5 cubic feet, while wall ovens typically have about 3 cubic feet of space.)
- Features
- Range Type: Slide-In (Freestanding ranges have finished sides and a backguard where the oven controls are located; this style allows for the most versatility in placement. Slide-in ranges may have unfinished sides and are wider at the top to overlap the countertop on each side, allowing for a built-in appearance. Drop-in ranges are also known for their built-in style and are designed to fit custom cabinetry or countertops.)
- Downdraft Ventilation: true (This ventilation system, typically integrated right into the cooktop, pulls smoke and fumes downward in order to ventilate them away from the cooking area. If a range hood is not an option due to your cooktop location or you need more cabinet space above the cooking surface, downdraft ventilation will save space while ensuring smoke and odors are still being ventilated.)
- Gas Type: Natural gas
- Range Power Source: Dual fuel
- Fingerprint Resistant: false
- Ignition Type: Electric
- Control Type: Knob, Touchpad
- Oven Control Location: Front panel
- Clock Display: true
- Oven Light: true
- Hot Surface Indicator(s): false (Visual indicators turn on when the cooktop surface is hot and remain on until it is cooled, acting as a convenient safety reminder.)
- Propane (LP) Convertible: true
- Propane Kit Model Compatibility: *See features for compatible model
- Wireless Connectivity: None (The manner in which a device sends data to another device over a short distance without the use of wires or cables.)
- Design
- Display Type: None
- Functions
- Sabbath Mode: false (This mode complies with the rules of Halakha and allows Shabbat-observant people to use the appliance on the Shabbat and other Jewish holidays.)
- Hidden Bake Element: true (This feature provides more space within the cooking cavity and allows for cleaning without navigating around an exposed heating element.)
- Oven Cooking Modes: Convection, Bake, Broil, Roast
- Oven Settings: Keep Warm Setting, Timer
- Oven Features
- Convection Type: Single-fan (Convection adds a fan system to the two heating elements for continuous air motion and efficient cooking. True convection adds a third heating element to the fan system, for even more uniform heating.)
- Oven Cleaning Method: Steam cleaning (There are several ways to clean the inside of your oven. Depending on the model, it might require manual cleaning or have a self-clean function. Self-clean functions use either high heat or steam to break down grease and food debris within the cooking cavity.)
- Induction: false (Induction cooktops use magnetic currents to heat compatible cookware directly instead of warming the cooktop itself, which can allow for faster and more efficient cooking. There is also an added safety benefit because the surface begins to cool when cookware is removed.)
- Single/Double Oven: Single Oven
- Drawer Type: None (Many ranges have a drawer located beneath the oven. In some models, this drawer functions as a broiler for high-heat cooking and browning. Other models have warming drawers to keep prepared foods warm until serving. If the drawer has no cooking function, it serves as convenient storage for pans and baking sheets.)
- Broiler Location: Oven
- Number of Oven Racks: 3
- Number of Oven Rack Positions: 7
- Oven Window: true
- Cooktop Features
- Cooktop Surface Type: Grate (On electric cooktops, coil elements are typically more durable and tend to provide more evenly conducted heat than smoothtops. However, smoothtops may be easier to clean and have a distinctive streamlined appearance.)
- Cooktop Surface Material: Stainless steel
- Number of Burners: 4
- Sealed Burners: false (A cap covers the internal components of the burner to prevent food spilling into the flame or under the cooktop, allowing for easier cleaning.)
- Specialty Burner(s): None (Do more with your cooktop with burners designed for specific cooking needs and precise control. For example, simmer burners provide consistent, low-temperature heat for melting delicate foods or simmering sauces, while power burners provide high cooking power for quick boiling, searing, or stir-fry cooking.)
- Grate Material: Cast iron
- Griddle Included: false
- Burner Rating
- Burner 1 Rating: 17000 british thermal units (An average home cooktop burner gives off about 7,000 BTUs of heating power. Burners with higher BTU ratings are better suited for searing or stir-fry cooking, while lower burner ratings are ideal for simmering.)
- Burner 2 Rating: 5000 british thermal units
- Burner 3 Rating: 15000 british thermal units
- Burner 4 Rating: 9200 british thermal units
- Total Maximum BTU Rating: 15000 (The total amount of gas, measured in British Thermal Units (BTU), used by the appliance when operating at its maximum output.)
- Electrical Specification
- Amperage: 40 amperes (Strength of electrical current.)
- Voltage: 240 volts (Amount of power needed to support an electrical current.)
- Included
- Power Cord Included: true (Connects your product to an electrical outlet, allowing for immediate use (provided that other installation requirements are met).)
- Propane Conversion Kit Included: true
- Gas Regulator Inlet Thread Size: 1/2 inch (The internal (female) thread size of the gas inlet connection on the appliance’s gas regulator. Note: this is not referring to the gas line size requirement.)
- Certifications Listings & Approvals
- ADA Compliant: true (Meets standards set by the Disabilities Act (ADA) Standards for Accessible Design)
- Chemical Disclosures: This product may contain one or more regulated perfluoroalkyl and polyfluoroalkyl substances or PFAS. Mandatory reporting is not required until January 1, 2025. Whirlpool Corporation is in the process of gathering more information on PFAS use across our supplier base, and will update this disclosure as we learn more. For more information about chemicals in this product, visit www.kitchenaid.com/regulatory. [Este producto puede contener una o más sustancias perfluoroalquilo y polifluoroalquilo reguladas o PFAS. No se requieren informes obligatorios hasta el 1 de enero de 2025. Whirlpool Corporation está en el proceso de recopilar más información sobre el uso de PFAS en nuestra base de proveedores y actualizará esta divulgación a medida que sepamos más. Para obtener más información sobre los químicos en este producto, visite www.kitchenaid.com/regulatory.] (The disclosure of Per- and Polyfluorinated Substances (PFAS) and/or other chemicals.)
- Warranty
- Warranty - Parts: 1 year limited
- Warranty - Labor: 1 year limited
- Compatibility
- App Compatible: false (The product can be connected to a program or software application on a mobile device, which then receives collected data from the product.)
- Other
- UPC: 883049343648
KitchenAid dual fuel convection range: With Even-Heat True Convection technology, you can quickly and easily cook delicious homemade meals for your family. The downdraft system offers built-in ventilation to efficiently eliminate smoke and odors.
- 4 burners: Deliver between 5,000 and 17,000 BTUs of heat, so you can easily cook a wide variety of dishes. Continuous grates enable easy transfer from burner to burner.
- Circulate air throughout the oven: Even-Heat True Convection uses a bow-tie design and a convection fan to ensure even, thoroughly cooked results.
- Quickly eliminate baked-on spills and grease: AquaLift self-cleaning technology combines water and heat to clean your oven in less than an hour.
- Cook multiple dishes at once: The 6.4 cu. ft. capacity provides plenty of space to cook for a crowd. SatinGlide racks enable easy loading and unloading, even with heavy dishes.
- Reduce smoke and odors while you cook: Downdraft system offers integrated ventilation, without the need for a separate hood.
- Take the guesswork out of new recipes: EasyConvect Conversion adjusts conventional settings for recipes to convection settings.
- See cooking progress at a glance: Oven window and incandescent lighting offer clear visibility without opening the oven door.
- *Liquid Propane Kit Compatible Model:: W11126047 - (serial number engineering digit 00, 01, 06_aka W11126047 - a PACKAGED W10566083)
Whats Included
- 6.4 Cu. Ft. Slide-In Dual Fuel Convection Range
- Gas connector is not included
- pre-installed with a 4-prong power cord
- Owner's manual
Q: What type of oven lighting does this range have?
A: This range uses incandescent lighting in the oven.
Q: Is this KitchenAid range compatible with propane?
A: Yes, this range is propane compatible.
Q: Does this range offer a self-cleaning feature?
A: Yes, this KitchenAid range features AquaLift self-cleaning technology that uses water and heat to clean the oven in under an hour.
Q: What is the oven capacity of this KitchenAid range?
A: The oven has a capacity of 6.4 cubic feet.
Q: How many burners does this range have?
A: This KitchenAid range has four burners.
Q: Does this range have a convection cooking feature?
A: Yes, it features Even-Heat True Convection which uses a bow-tie design and a convection fan for even cooking.
Q: I have a vented hood and don’t need the downdraft. Does it have to be installed?
A: Be thankful you don't need to install the downdraft since you have a hood. We do not have a hood and spent $3,800 for our downdraft because we have an island and absolutely NO ONE WILL DO THE INSTALL FOR THE VENTING. Best Buy is doing nothing about this and had no problem selling us an expensive range with no one to help us. They ignore our phone calls don't return our calls and this is at the store level. I always loved Best Buy but they have proven themselves to not be an honest retailer. You can only prove how good you are when there is a problem and Best Buy has failed miserably.
Q: Does it come with the venting for downdraft in the sale price?
A: What you need to know about this range is that it is a special installation. It took FIVE tries (scheduling crews, who would show up and say they couldn't do the job) and many, many calls and visits to stores to get this product installed. I purchased installation online when I placed the order. But when the delivery people brought the range, they said they could not install. So if you order this range, you should do it IN STORE, and make sure you are dealing with a knowledgeable person who knows this requires special installation. The standard BestBuy / Geek Squad is not staffed to do these installs. This range replaced an older Jena-Air downdraft at a home that is now a rental property, and my poor tenants were without a range for over a MONTH. In the end, Best Buy gave additional discounts and eventually got it solved, but it was a headache. Again -- go into the store and be sure you're dealing with a product specialist who KNOWS this product and its requirements.
