Thermador - Liberty Series 36" Built-In Electric Induction Cooktop with 5 elements, 3 Flex Zones, Wifi and Frameless Design - Titanium Gray
- Key Specs
- Color Finish: Gray
- Product Height: 4 1/4 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 37 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 21 1/4 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Cooktop Surface Type: Smoothtop (On electric cooktops, coil elements are typically more durable and tend to provide more evenly conducted heat than smoothtops. However, smoothtops may be easier to clean and have a distinctive streamlined appearance.)
- Number of Elements: 5
- App Compatible: true (The product can be connected to a program or software application on a mobile device, which then receives collected data from the product.)
- Voice Assistant Built-in: No (A digital assistant built into the device that uses voice commands to answer questions and control smart devices.)
- General
- Brand: Thermador
- Model Number: CIT367YGS
- Product Name: Liberty Series 36" Built-In Electric Induction Cooktop with 5 elements, 3 Flex Zones, Wifi and Frameless Design
- Color: Titanium Gray
- Color Finish: Gray
- Vendor Collection: Thermador Masterpiece (Part of a line of different product types, like kitchen appliances.)
- Dimensions
- Product Height: 4 1/4 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 37 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 21 1/4 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Standardized Width: 36 inches (An approximated measurement (exact width may differ slightly) determined by the manufacturer in accordance with industry standards. Standardized sizes are intended to assist consumers when purchasing appliances and planning for installation.)
- Product Weight: 55 pounds (The out of box weight of the item.)
- Cut-Out Dimensions
- Cut-Out Height: 3 7/8 inches (Minimum required height of the installation location for a standard installation of the product. This measurement will help you determine if the appliance will fit into the desired space and have the clearance necessary for proper operational use. Please refer to the manufacturer’s installation documentation for detailed measurement requirements.)
- Cut-Out Width: 34 3/4 inches (Minimum required width of the installation location for a standard installation of the product. This measurement will help you determine if the appliance will fit into the desired space and have the clearance necessary for proper operational use. Please refer to the manufacturer’s installation documentation for detailed measurement requirements.)
- Cut-Out Depth: 19 7/8 inches (Minimum required depth of the installation location for a standard installation of the product. This measurement will help you determine if the appliance will fit into the desired space and have the clearance necessary for proper operational use. Please refer to the manufacturer’s installation documentation for detailed measurement requirements.)
- Features
- Downdraft Ventilation: false (This ventilation system, typically integrated right into the cooktop, pulls smoke and fumes downward in order to ventilate them away from the cooking area. If a range hood is not an option due to your cooktop location or you need more cabinet space above the cooking surface, downdraft ventilation will save space while ensuring smoke and odors are still being ventilated.)
- Installs Over Built-In Oven: true
- Control Type: LED display with touchscreen controls
- Control Location: Top
- Digital Display: true
- Power-On Indicator Light(s): true
- Fingerprint Resistant: false
- Hot Surface Indicator(s): true (Visual indicators turn on when the cooktop surface is hot and remain on until it is cooled, acting as a convenient safety reminder.)
- Child Lock: true (Setting that allows appliance to be temporarily locked to prevent use.)
- Form Factor: Cooktop (The size, arrangement, and physical configuration of the product.)
- Portable: false
- Wireless Connectivity: Wi-Fi (The manner in which a device sends data to another device over a short distance without the use of wires or cables.)
- Cooktop Features
- Induction: true (Induction cooktops use magnetic currents to heat compatible cookware directly instead of warming the cooktop itself, which can allow for faster and more efficient cooking. There is also an added safety benefit because the surface begins to cool when cookware is removed.)
- Cooktop Surface Type: Smoothtop (On electric cooktops, coil elements are typically more durable and tend to provide more evenly conducted heat than smoothtops. However, smoothtops may be easier to clean and have a distinctive streamlined appearance.)
- Cooktop Surface Material: Glass, Ceramic
- Number of Cooking Zones: 5
- Number of Elements: 5
- Pan Presence Sensor: true (Sensors detect when a pan comes into contact with the cooking surface and when it is removed. When a pan is removed, the cooktop will automatically shut off as a safety precaution.)
- Bridge Element: true (This feature is an additional heating element located between two individual burners. When this is enabled, the individual burners and the bridge element act as one connected cooktop. This equal heat distribution on the cooktop surface helps accommodate larger cookware, such as roaster pans or griddles.)
- Specialty Element(s): None
- Expandable Element: true (Accommodate large cookware and ensure even heat distribution with this feature, which allows more surface area for the individual heating element.)
- Included
- Power Cord Included: false (Connects your product to an electrical outlet, allowing for immediate use (provided that other installation requirements are met).)
- Griddle Included: false
- Power
- Auto Shut-Off: true (Feature automatically turns off the product.)
- Cooktop Power Source: Electric
- Element Wattage
- Element 1 Wattage: 3600 watts
- Element 2 Wattage: 3600 watts
- Element 3 Wattage: 3600 watts
- Element 4 Wattage: 3600 watts
- Element 5 Wattage: 3600 watts
- Electrical
- Wattage: 10800 watts (Measurement of electrical power.)
- Amperage: 50 amperes (Strength of electrical current.)
- Voltage: 240 volts (Amount of power needed to support an electrical current.)
- Certifications Listings & Approvals
- ADA Compliant: true (Meets standards set by the Disabilities Act (ADA) Standards for Accessible Design)
- Chemical Disclosures: Free of PFAS, PFOA, lead, and cadmium. Libre de PFAS, PFOA, plomo, y cadmio. (The disclosure of Per- and Polyfluorinated Substances (PFAS) and/or other chemicals.)
- ENERGY STAR Certified: false (Devices carrying the ENERGY STAR service mark, such as computer products and peripherals, kitchen appliances, and other products, generally use 20% to 30% less energy than required by federal standards.)
- Warranty
- Warranty - Parts: 2 years
- Warranty - Labor: 2-year
- Compatibility
- App Compatible: true (The product can be connected to a program or software application on a mobile device, which then receives collected data from the product.)
- Voice Assistant Built-in: No (A digital assistant built into the device that uses voice commands to answer questions and control smart devices.)
- Other
- UPC: 825225960270
The innovative Liberty induction cooktop is designed for greater flexibility when cooking and a sleek smooth surface makes cleaning fast and simple. Three extra-large cooking zones allow more space and flexibility in placing larger cookware and the induction system heats foods quickly and evenly. The PowerBoost feature increases element power by up to 50%, saving time to heat up pots or cook large quantities. Illuminated touch control panel offers intuitively simple selection of 17 power settings and allows for easy cleaning. Easily go from sauté to simmer for the ultimate control while cooking with HeatShift.
- Easily go from sauté to simmer with HeatShift: Perfect for recipes that require moving from a sauté to a simmer. HeatShift divides your cooktop into three preset heat zones that allow you to change the power level by simply moving the pot.
- Titanium Gray Glass with a frameless design: Titanium grey glass is a perfect match to Masterpiece series ovens.
- Transfer settings when moving a pot with MoveMode: MoveMode allows you to easily move your pot across the cooktop, and the power level will automatically transfer.
- PowerBoost heats up pots or boils water quicker: PowerBoost increases element power by up to 50%, saving time to heat up pots or boil water quicker.
- CookSmart ensures optimal cooking results: CookSmart ensures optimal results with 5 pre-set temperature levels programmed for cooking different types of food.
- Three cooking zones provides flexibility: Three extra-large Liberty cooking zones allows more space and flexibility in placing larger cookware.
- Easy cleanup: Provides a smooth surface that makes cleaning fast and simple.
- Automatic pan recognition: Cooktop automatically recognizes pan.
- Touch controls: Illuminated touch controls provide a sleek design.
- Child safety lock: Child safety lock provides peace of mind.
- Easily go from sauté to simmer with HeatShift: Perfect for recipes that require moving from a sauté to a simmer. HeatShift divides your cooktop into three preset heat zones that allow you to change the power level by simply moving the pot.
- Titanium Gray Glass with a frameless design: Titanium grey glass is a perfect match to Masterpiece series ovens.
- Transfer settings when moving a pot with MoveMode: MoveMode allows you to easily move your pot across the cooktop, and the power level will automatically transfer.
- PowerBoost heats up pots or boils water quicker: PowerBoost increases element power by up to 50%, saving time to heat up pots or boil water quicker.
- CookSmart ensures optimal cooking results: CookSmart ensures optimal results with 5 pre-set temperature levels programmed for cooking different types of food.
- Three cooking zones provides flexibility: Three extra-large Liberty cooking zones allows more space and flexibility in placing larger cookware.
- Easy cleanup: Provides a smooth surface that makes cleaning fast and simple.
- Automatic pan recognition: Cooktop automatically recognizes pan.
- Touch controls: Illuminated touch controls provide a sleek design.
- Child safety lock: Child safety lock provides peace of mind.
Whats Included
- Liberty Series 36" Built-In Electric Induction Cooktop
- Liberty Series 36" Built-In Electric Induction Cooktop
A: The HeatShift feature on the Thermador Liberty Series 36" Built-In Electric Induction Cooktop simplifies the cooking process by dividing the cooktop into three preset heat zones. This allows users to easily move pots from one zone to another, changing the power level without adjusting the temperature settings manually. This feature is particularly useful for recipes that require precise temperature control, such as sautéing and simmering.
A: The cut-out dimensions of the cooktop are 34 3/4 inches in width and 19 7/8 inches in depth. The overall dimensions of the cooktop are 37 inches in width, 4 1/4 inches in height, and 21 1/4 inches in depth.
A: Yes, the induction cooktop requires special cleaning and maintenance to ensure its longevity. It is recommended to use a soft, damp cloth to clean the cooktop surface after each use and avoid using harsh abrasives or cleaners. Additionally, it is important to avoid placing hot pots or pans directly on the cooktop surface, as this can damage the glass.
Q: What is the manufacturer's warranty coverage for parts and labor, and what does it entail?
A: The manufacturer's warranty for Thermador Liberty Series 36" Built-In Electric Induction Cooktop covers both parts and labor for a duration of 2 years from the date of purchase. During this period, Thermador will repair or replace any defective parts and provide labor to rectify any issues related to the cooktop's functionality.
A: Yes, this Thermador cooktop requires a specific voltage and amperage for installation. It operates at 240 volts and draws 50 amperes of current. Therefore, it is crucial to ensure that your electrical system can support these requirements before installation. A dedicated circuit and proper wiring are necessary to prevent any electrical hazards or damage to the cooktop.
Q: What is the control type, and how does it contribute to the user-friendly operation of the cooktop?
A: The Thermador Liberty Series 36" Built-In Electric Induction Cooktop features an LED display with touchscreen controls. This user-friendly control panel offers intuitive selection of 17 power settings and allows for easy cleaning, enhancing the overall cooking experience.
Q: How does the automatic pan recognition feature simplify the cooking process?
A: The automatic pan recognition feature on the Thermador Liberty Series 36" Built-In Electric Induction Cooktop simplifies the cooking process by automatically adjusting the power level to match the size and type of pan being used. This ensures optimal cooking results without the need for manual adjustment.
A: The Liberty Series 36" Built-In Electric Induction Cooktop features five cooking elements with varying wattages: 3600 watts for elements 1, 2, 4, and 5, and 3700 watts for element 3. These powerful elements contribute to the cooktop's overall cooking performance by providing rapid and even heating, allowing for precise temperature control and efficient cooking.
