Audio-Technica - Audio Technica AT-XP7/H Headshell Combo Kit - Black
About this product
The AT-XP7/H combo kit includes the AT-XP7 DJ cartridge premounted on the AT-HS6BK headshell. Features - 0.3 x 0.7 mil elliptical bonded stylus tip - Highly rigid, lightweight polyphenylene sulfide (PPS)/glass fiber body - 6.0 mV high-output level - Tracking force of 2.0 to 4.0 grams (3.0 grams standard) - Stainless wire suspension, double-layered rubber damper and tapered aluminum cantilever ensure precise tracking - Design offers maximum visibility of the stylus tip - Great tracking and channel separation for high-fidelity sound - Universal ½"-mount headshell for 4-pin turntable cartridges Specifications - Frequency Response: 20-20,000 Hz - Channel Separation: 22 (dB at 1 kHz) - Vertical Tracking Force: 2.0-4.0 g (3.0 g standard) - Stylus Construction: Bonded round shank - Recommended Load Impedance: 47,000 ohms - Output: 6.0 mV (1 kHz, 5 cm/sec.) - Channel Balance: 2.0 dB (1 kHz) - Stylus Shape: 0.3 x 0.7 mil elliptical - Cantilever: Aluminum tapered pipe - Mount: Half-inch - Replacement Stylus: ATN-XP7 - Coil Impedance: 6.7 k ohms (1 kHz) - DC Resistance: 990 ohms - Recommended Load Capacitance: 100 to 200 pF - Vertical Tracking angle: 20° - Dimensions: 17.2 mm (0.68") H × 17.8 mm (0.67") W × 28.3 mm (1.20") D - Weight (Cartridge): 6.2 g (0.22 oz) - Dimensions (Cartridge and Headshell): 21.2 mm (0.83") H × 21.4 mm (0.84") W × 62.4 mm (2.46") D - Weight (Cartridge and Headshell): 15.6 g (0.55 oz) - Accessories Included: Two 11 mm installation screws, two 8 mm installation screws, two washers, two nuts, non-magnetic screwdriver
Features
Frequency Response
20-20,000 Hz
Stylus Construction
Bonded round shank
Stylus Shape
0.3 x 0.7 mil elliptical
Cantilever
Aluminum tapered pipe
Recommended Load Impedance
47,000 ohms
Mount
Half-inch
Accessories Included
Two 11 mm installation screws, two 8 mm installation screws, two washers, two nuts, non-magnetic screwdriver
Specifications
- Accessory TypeTurntable AccessoryModel Compatibilityasset://embedded/asset/id/bed8375f-8e90-493f-89ef-0f40930c3f43/filename/at-xp7-h-04.png
Reviews
Rating 5 out of 5 stars with 5 reviews
Customer Images
The vast majority of our reviews come from verified purchases. Reviews from customers may include My Best Buy members, employees, and Tech Insider Network members (as tagged). Select reviewers may receive discounted products, promotional considerations or entries into drawings for honest, helpful reviews.
Compare similar products
The AT-XP7/H combo kit includes the AT-XP7 DJ cartridge premounted on the AT-HS6BK headshell. Features - 0.3 x 0.7 mil elliptical bonded stylus tip - Highly rigid, lightweight polyphenylene sulfide (PPS)/glass fiber body - 6.0 mV high-output level - Tracking force of 2.0 to 4.0 grams (3.0 grams standard) - Stainless wire suspension, double-layered rubber damper and tapered aluminum cantilever ensure precise tracking - Design offers maximum visibility of the stylus tip - Great tracking and channel separation for high-fidelity sound - Universal ½"-mount headshell for 4-pin turntable cartridges Specifications - Frequency Response: 20-20,000 Hz - Channel Separation: 22 (dB at 1 kHz) - Vertical Tracking Force: 2.0-4.0 g (3.0 g standard) - Stylus Construction: Bonded round shank - Recommended Load Impedance: 47,000 ohms - Output: 6.0 mV (1 kHz, 5 cm/sec.) - Channel Balance: 2.0 dB (1 kHz) - Stylus Shape: 0.3 x 0.7 mil elliptical - Cantilever: Aluminum tapered pipe - Mount: Half-inch - Replacement Stylus: ATN-XP7 - Coil Impedance: 6.7 k ohms (1 kHz) - DC Resistance: 990 ohms - Recommended Load Capacitance: 100 to 200 pF - Vertical Tracking angle: 20° - Dimensions: 17.2 mm (0.68") H × 17.8 mm (0.67") W × 28.3 mm (1.20") D - Weight (Cartridge): 6.2 g (0.22 oz) - Dimensions (Cartridge and Headshell): 21.2 mm (0.83") H × 21.4 mm (0.84") W × 62.4 mm (2.46") D - Weight (Cartridge and Headshell): 15.6 g (0.55 oz) - Accessories Included: Two 11 mm installation screws, two 8 mm installation screws, two washers, two nuts, non-magnetic screwdriver
The AT-VM95E/H combo kit includes the AT-VM95E dual moving magnet cartridge premounted on the AT-HS6BK headshell. VM dual magnet cartridge with 0.3 x 0.7 mil elliptical stylus. Aluminum cantilever. Specially wound coils increase output voltage. Durable low-resonance polymer housing. Threaded inserts in cartridge body enable cartridge to be mounted to headshell with just two screws – no nuts or washers required. Compatible with any AT-VMN95 replacement stylus. Universal ½"-mount headshell for 4-pin turntable cartridges. Frequency Response: 20-22,000 Hz. Channel Separation: 20 (dB at 1 kHz). Vertical Tracking Force: 1.8-2.2 g (2.0 g standard). Stylus Construction: Bonded round shank. Recommended Load Impedance: 47,000 ohms. Output: 4.0 mV (1 kHz, 5 cm/sec.). Channel Balance: 2.0 dB (1 kHz). Stylus Shape: 0.3 x 0.7 mil elliptical. Cantilever: Aluminum pipe. Mount: Half-inch. Replacement Stylus: AT-VMN95E. Coil Impedance: 3.3 k ohms (1 kHz). DC Resistance: 485 ohms. Load Capacitance: 100 to 200 pF. Coil Inductance: 550 mH (1 kHz). Vertical Tracking Angle: 23°. Dimensions (Cartridge): 17.2 mm (0.68") H × 18.9 mm (0.74") W × 28.3 mm (1.20") D. Weight (Cartridge): 6.1 g (0.22 oz). Dimensions (Cartridge & Headshell): 21.2 mm (0.83") H × 21.4 mm (0.84") W × 62.4 mm (2.46") D. Weight (Cartridge & Headshell): 15.5 g (0.55 oz). Accessories Included: Two 11 mm installation screws, two 8 mm installation screws, two washers.
The AT-VM95SH/H combo kit includes the AT-VM95SH dual moving magnet cartridge premounted on the AT-HS6BK headshell. VM dual magnet cartridge with 2.7 x 0.26 mil Shibata stylu. Aluminum cantilever. Specially wound coils increase output voltage.. Durable low-resonance polymer housing. Threaded inserts in cartridge body enable cartridge to be mounted to headshell with just two screws – no nuts or washers required. Compatible with any AT-VMN95 replacement stylus. Universal ½"-mount headshell for 4-pin turntable cartridges.
The AT-VM95SP/H combo kit includes the AT-VM95SP dual moving magnet cartridge premounted on the AT-HS6BK headshell. VM dual magnet cartridge with 3.0 mil conical stylus. Aluminum cantilever. Specially wound coils increase output voltage. Durable low-resonance polymer housing. Threaded inserts in cartridge body enable cartridge to be mounted to headshell with just two screws – no nuts or washers required. Compatible with any AT-VMN95 replacement stylus. Universal ½"-mount headshell for 4-pin turntable cartridges.
Specs
Questions & Answers
will this fit and work on a 'vintage' Technics SL-3200 semi auto turntable?
Answered by AudioTechnicaYes, it will.
Is this what your sound come from?
Answered by AudioTechnicaPlease call for further assistance.
I am replacing the cartridge on Dual 1214 and wondering if this will fit.
Answered by AudioTechnicaYou may use the cartridge itself, the AT-XP3, but not the headshell that is provided with the AT-XP3/H Headshell/Cartridge Combo Kit. You must use the proprietary angled Dual headshell and the Dual cartridge sled (aka carrier or clip).
will it fit a jvc ql-a2
Answered by AudioTechnicaYes, it will.
will it fit pioneer pl518
Answered by AudioTechnicaYes, it will, and it just happens to be set at the correct overhang, 15.5mm
