- Key Specs
- Product Weight: 20.5 pounds (The out of box weight of the item.)
- Light Source: Laser
- Resolution: 4K (2160p) (Refers to the number of pixels, both horizontally and vertically, used to capture video/images. The higher the resolution the finer the detail that can be seen.)
- Contrast Ratio: 2000000:1 (Measured difference between a displayed image's brightest whites and darkest blacks. The larger the first number, the more detail and color that can be displayed.)
- Projector Use: Home Theater
- Projector Throw Type: Ultra Short Throw (The distance from the screen that the projector can be placed to project images. Standard throw projectors typically need to be at least 6 feet away while short throw and ultra short throw projectors can be placed closer to the screen for use in smaller rooms.)
- Portability: Fixed (Fixed projectors are ideal when creating an authentic theater atmosphere in your home. Often designed to stay in one place they may require significant recalibration if moved. Portable projectors, weighing around 5 pounds, are easy to move, but will still require set-up calibration and often have technology to reduce the complexity. Ultra-portable projectors are very light, often battery-powered, and ideal for on-the-go use.)
- Smart Capable: true (Smart, or smart-capable devices are able to connect directly to your home network in order to stream content from the Internet, run Internet-based apps, or connect to other smart devices.)
- Works With: Google Assistant (Compatible with or able to be connected to other smart devices or applications.)
- General
- Brand: Epson
- Model Number: V11H956520
- Product Name: EpiqVision™ Ultra LS500 4K via Upscaling PRO-UHD, Short Throw Laser Projector, 4000 lumens, HDR, Android TV, Sports
- Color: White
- Dimensions
- Product Height: 9 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 18 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 14.7 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Product Weight: 20.5 pounds (The out of box weight of the item.)
- Display
- Light Source: Laser
- Resolution: 4K (2160p) (Refers to the number of pixels, both horizontally and vertically, used to capture video/images. The higher the resolution the finer the detail that can be seen.)
- Resolution (Native): 1920 x 1080 (Native resolution of a screen refers to its single, fixed resolution. Sometimes screens must scale an image up or down in order to fit the native resolution. This can cause a loss of resolution or detail.)
- 3-Chip Technology: true (Projectors with this technology are able to display images with optimal brightness, color, and detail. Because of their high-performance design, these projectors are primarily used in large venues and digital cinemas.)
- High Dynamic Range (HDR): true (An HDR-compatible 4K TV or other HDR-compatible product displays HDR video content when it's available from sources like 4K Ultra HD Blu-ray Discs and 4K streaming services.)
- High Dynamic Range Format: Hybrid Log-Gamma (HLG), HDR 10 (There are a few HDR formats that tell the TV or other HDR-compatible product how to best utilize its capabilities to display HDR content. HDR technology can support one or multiple formats, each with various benefits to picture quality.)
- Contrast Ratio: 2000000:1 (Measured difference between a displayed image's brightest whites and darkest blacks. The larger the first number, the more detail and color that can be displayed.)
- Aspect Ratio: 16:9 (The measurement of the width of a screen compared to the height of a screen, expressed as a ratio.)
- Throw Ratio Range: 0.28, 0.38 (This measurement indicates what size of projected image can be produced from a certain distance. The smaller the ratio, the closer the projector can be to the screen while still producing a large image.)
- Digital Keystone Correction: true ("Keystone effect" refers to the distortion of an image when it is projected on an angled surface or when the projector is positioned too high or too low from the center of the display. Projectors with a digital keystone correction feature are able to scale the image as needed before it is projected, resulting in the correct image orientation no matter where it is displayed.)
- 3D Technology: true
- Viewing
- Minimum Projector Distance: 1.28 feet (Minimum distance that the projector can be placed from the screen to produce a display with acceptable visual performance.)
- Maximum Projector Distance: 1.28 feet (Maximum distance that the projector can be placed from the screen to produce a display with acceptable visual performance.)
- Minimum Viewable Screen Size: 100 inches
- Maximum Viewable Screen Size: 130 inches
- Features
- Projector Use: Home Theater
- Projector Throw Type: Ultra Short Throw (The distance from the screen that the projector can be placed to project images. Standard throw projectors typically need to be at least 6 feet away while short throw and ultra short throw projectors can be placed closer to the screen for use in smaller rooms.)
- Portability: Fixed (Fixed projectors are ideal when creating an authentic theater atmosphere in your home. Often designed to stay in one place they may require significant recalibration if moved. Portable projectors, weighing around 5 pounds, are easy to move, but will still require set-up calibration and often have technology to reduce the complexity. Ultra-portable projectors are very light, often battery-powered, and ideal for on-the-go use.)
- Smart Capable: true (Smart, or smart-capable devices are able to connect directly to your home network in order to stream content from the Internet, run Internet-based apps, or connect to other smart devices.)
- Remote Control Included: true
- Featured Streaming Services: Google Play Movies & TV, HBO Max, Netflix, YouTube, Hulu (Streaming services and other programs are available on this device. Keep in mind, there may be more services supported than just those shown here.)
- Screen Mirroring: Mobile to screen (Casts the screen of one device onto another wirelessly, using a common protocol (typically Bluetooth).)
- Exposure Control
- Focus Adjustment: Manual (The method used to focus the device in order to view or display a sharper image.)
- Optical Zoom: 1.3x (The optical zoom uses a combination of lenses that magnify the image prior to it being registered at high resolution by the imaging sensor.)
- Connectivity
- Number of HDMI Inputs (Total): 3
- HDMI Audio Return Channel (ARC): true
- Number of USB Port(s): 2
- Audio
- Integrated Speaker(s): true
- Speaker(s) Included: true
- Watts Per Channel: 10 watts
- Compatibility
- Works With: Google Assistant (Compatible with or able to be connected to other smart devices or applications.)
- Certifications Listings & Approvals
- ENERGY STAR Certified: false (Devices carrying the ENERGY STAR service mark, such as computer products and peripherals, kitchen appliances, and other products, generally use 20% to 30% less energy than required by federal standards.)
- Other
- UPC: 010343951907
With an immersive 4K HDR3 viewing experience, Epson Ultra Short Throw Laser Projector represents a new generation of digital projection that redefines the everyday television experience by offering a stunning 130" picture. Equipped with proprietary 4K PRO-UHD®2 3LCD technology, Epson Ultra Short Throw Laser Projector produces vivid colors and deep blacks for an exceptionally bright, colorful and sharp picture in virtually any viewing environment. Whether you’re watching a live sporting event, streaming your favorite series, gaming on the latest generation of consoles, or watching a blockbuster movie, Epson Ultra Short Throw Laser Projectior will simply amaze you.
- Stunning Picture Quality up to 130": Delivers an immersive, bright viewing experience for TV shows, sporting events, gaming and movies by accepting content up to 4K – for an amazing Full-HD HDR picture1.
- Ultra-short-throw Technology: for a breakthrough viewing experience with no shadows, plus easy installation; simply place the projector close to the wall and beam an image up to 130".
- Immersive Display: a new generation of digital projection that redefines the everyday television experience by offering a stunning picture; easy to set up
- 4K PRO-UHD2 Projection Technology: advanced processing for resolution enhancement, color and image processing, resulting in an exceptionally sharp picture
- Incredibly Bright Picture: displays 4K HDR3 content at an exceptional level of brightness of 4000 lumens in color; for all-day viewing in virtually any lighting environment
- Stunning Picture Quality up to 130": Delivers an immersive, bright viewing experience for TV shows, sporting events, gaming and movies by accepting content up to 4K – for an amazing Full-HD HDR picture1.
- Ultra-short-throw Technology: for a breakthrough viewing experience with no shadows, plus easy installation; simply place the projector close to the wall and beam an image up to 130".
- Immersive Display: a new generation of digital projection that redefines the everyday television experience by offering a stunning picture; easy to set up
- 4K PRO-UHD2 Projection Technology: advanced processing for resolution enhancement, color and image processing, resulting in an exceptionally sharp picture
- Incredibly Bright Picture: displays 4K HDR3 content at an exceptional level of brightness of 4000 lumens in color; for all-day viewing in virtually any lighting environment
Whats Included
- Projector
- Remote
- Power Cable
- Projector
- Remote
- Power Cable
Product Manuals
Q: How many watts of electricity does this use?
A: Hi Chaudhary, Electrical specification for the LS500 are as follows - Normal Power Consumption mode: 381 W; ECO Power Consumption mode: 236 W; Networked Standby: 2.0 W; Energy Saving: 0.5 W. Regards, Mark - The Epson Team.
Q: There is a range about throw ratio. How do I adjust my throw ratio of this machine?
A: Hello Olivia. The projector has an electronic Zoom (e-Zoom) function, but in normal mode, it can only make the image smaller (Tele),e-Zoom cannot overcome the physical placement of the projector being too close to the screen. Moving the projector closer or further from the screen should be used to control the image size. In general, e-Zoom should be avoided if possible, as it reduces the number of pixels used in the image. Regards, Kevin - The Epson Team.
Q: Can we connect the projector with 5g wifi network?
A: how is that help me improve my projector?
A: Hi David, The EpiqVision Ultra LS500 projector has built-in 10 Watt, front-facing speakers for excellent sound quality. If you need external speakers, the LS500 has a stereo mini port for audio output. It does not have Bluetooth speaker connection capabilities. Regards, Dylan - The Epson Team.
A: I have a white version of this for which I paid 2200. After 5-% credit for using Best buy CC it was under 2000 for me Great product at this price
A: You can connect the soundbar with Bluetooth, I don’t think it has the optical audio
