Marantz - MODEL 30 Integrated Amplifier 200W x2 ch. Sound Master Tuning - Black
Color
Black
Specifications
- Continuous Watts x Channel @ Ohms100Number of Channels2Audio Only Inputs1 x Phono, Unbalanced RCANetwork Connector(s)No network connectorsPreamp OutputsYes
- Key Specs
- Continuous Watts x Channel @ Ohms: 100
- Number of Channels: 2 (The number of discrete channels of sound output. This can be a single number or multiple numbers separated by decimal(s). The first number is the primary, horizontally directed audio channels. The number after the first decimal, if applicable, is the number of subwoofer outputs or channels. The number after the second decimal, if applicable, is the number of height or atmospheric channels designed to immerse the listener by producing overhead sound effects.)
- Audio Only Inputs: 1 x Phono, Unbalanced RCA
- Network Connector(s): No network connectors
- Preamp Outputs: true
- General
- Brand: Marantz
- Model Number: MODEL30
- Product Name: MODEL 30 Integrated Amplifier 200W x2 ch. Sound Master Tuning
- Color: Black
- Audio
- Continuous Watts x Channel @ Ohms: 100
- Maximum Watts x Channel @ Ohms: 200 (This is the maximum load the speaker, subwoofer or amp can drive.)
- Number of Channels: 2 (The number of discrete channels of sound output. This can be a single number or multiple numbers separated by decimal(s). The first number is the primary, horizontally directed audio channels. The number after the first decimal, if applicable, is the number of subwoofer outputs or channels. The number after the second decimal, if applicable, is the number of height or atmospheric channels designed to immerse the listener by producing overhead sound effects.)
- Minimum Frequency Response: 5 hertz (Describes the maximum range of frequencies or musical tones a product can reproduce, from very low tones to very high treble tones. The minimum frequency or musical tone the speaker can reproduce. High treble tones have higher frequencies while low tones and deep bass have lower frequencies.)
- Total Harmonic Distortion: 0.005 percent (Measurement of the harmonic sound distortion. The lower the percentage, the cleaner the sound.)
- Maximum Frequency Response: 50 kilohertz (Describes the maximum range of frequencies or musical tones a product can reproduce, from very low tones to very high treble tones. The maximum frequency or musical tone the speaker can reproduce. High treble tones have higher frequencies while low tones and deep bass have lower frequencies.)
- Amplifier Class: D (An amplifier's mode of operation, specifically the conditions in which its electrical current flows for the duration of an audio signal, determines its class. Each class has its strengths and weaknesses when it comes to power efficiency, levels of crossover distortion, and overall sound quality.)
- Amplifier Type: Integrated amplifiers
- Signal-to-Noise Ratio (SNR): 107 decibels (The ratio of the desired signal's strength to the level of background noise. A ratio higher than 1:1, which equates to greater than 0 decibels, indicates more signal than noise.)
- Inputs
- Audio Only Inputs: 1 x Phono, Unbalanced RCA
- Video Only Inputs: No video only inputs (The number and type of video signal only inputs the product has.)
- Network Connector(s): No network connectors
- Line-Level Inputs: true (Also referred to as low-level inputs. Enables the amplifier to receive a sound signal from another device via RCA cables.)
- Outputs
- Preamp Outputs: true
- Speaker Connection Type: RCA
- Video Only Outputs: No video only outputs (The number and type of video signal only outputs the product has.)
- Dimensions
- Product Height: 5.1 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 17.4 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 17 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Product Weight: 32 pounds (The out of box weight of the item.)
- Other
- UPC: 699927170059
Get the most musical sound possible from this beautiful, Marantz integrated amplifier. Exquisitely tuned by the Marantz Sound Master, the MODEL 30 integrated amplifier features a master-curated Marantz HDAM and a fully discrete design for luxurious Hi-Fi purity. Designed to last the test of time and make all your music unforgettable, you'll see and feel it in the build quality and hear it every time. No matter your musical passions, your music always sounds better with MODEL 30.
- Exquisite sound tuning: MODEL 30 continues the renowned heritage of exquisite Marantz amplifiers. Tuned by the Marantz Sound Master who channeled his passion, experience, and extraordinary ear into the amplifier design.
- Musical, detailed sound: MODEL 30 is built on its own discrete circuit board, the Hyper-Dynamic Amplifier Module, or HDAM. By custom-curating hundreds of individual parts, HDAM significantly outperforms standard integrated circuits to create the unique musicality you always expect from Marantz.
- Marantz Musical Premium Phono EQ: Envisioned to deliver optimal sound quality by simplifying the signal path, the Phono EQ stage in the MODEL 30 amplifier can be used with both moving magnet and low-output moving coil cartridges, thanks to a built-in MC head amplifier.
- MC / MM phono input impedance selector: Optimize sound performance with moving coil (MC) or magnetic moving (MM) cartridges. MODEL 30 is equipped with an input impedance selector that can be adjusted to three different settings: MC LOW (33 ohm), MC MID (100 ohm) and MC HIGH (390 ohm).
- Analog-feel Volume Control: Newly developed electric volume control uses the latest volume control IC to realize better channel separation, dynamic range and distortion-reduction. You'll always get the volume precisely how you want it.
- Fully Discrete Pre-Amplifier: Current Feedback pre-amplification with HDAM-SA3 is thoughtfully designed to match the requirements of super audio High Resolution music for wide-bandwidth and high-speed reproduction. Each part is selected and optimized for sound quality and performance.
- Switching Power Amplification: MODEL 30 maintains the purest possible sound and supports the power needed to drive the most demanding speakers, delivering 2x100W into an 8ohms load, and easily copes with low impedance speakers thanks to a 2x200W output into 4ohms.
- Twin power supplies: A clean power supply is dedicated exclusively to preamp to ensure high purity. The amplification power supply delivers high current instantaneously. The MODEL 30 will follow even the hardest bass attacks and provides clean power for the reproduction of the finest details.
- Multiple Analog Inputs: In addition to phono and CD analog inputs, MODEL 30 features two line-level inputs and one pair of recorder input/output jacks that enable the connection of multiple sources and recorders.
- Main In and Pre Outs: Use MODEL 30 as a standalone stereo power amplifier for additional system configuration versatility with the included power amp direct input. For example, use the front pre-outs of your AV setup and run them through MODEL 30 power amps.
- Dedicated Headphone Output: The advanced headphone circuit delivers superb audio fidelity with the widest range of headphone types and impedances, including low impedance headphones.
- Exquisite sound tuning: MODEL 30 continues the renowned heritage of exquisite Marantz amplifiers. Tuned by the Marantz Sound Master who channeled his passion, experience, and extraordinary ear into the amplifier design.
- Musical, detailed sound: MODEL 30 is built on its own discrete circuit board, the Hyper-Dynamic Amplifier Module, or HDAM. By custom-curating hundreds of individual parts, HDAM significantly outperforms standard integrated circuits to create the unique musicality you always expect from Marantz.
- Marantz Musical Premium Phono EQ: Envisioned to deliver optimal sound quality by simplifying the signal path, the Phono EQ stage in the MODEL 30 amplifier can be used with both moving magnet and low-output moving coil cartridges, thanks to a built-in MC head amplifier.
- MC / MM phono input impedance selector: Optimize sound performance with moving coil (MC) or magnetic moving (MM) cartridges. MODEL 30 is equipped with an input impedance selector that can be adjusted to three different settings: MC LOW (33 ohm), MC MID (100 ohm) and MC HIGH (390 ohm).
- Analog-feel Volume Control: Newly developed electric volume control uses the latest volume control IC to realize better channel separation, dynamic range and distortion-reduction. You'll always get the volume precisely how you want it.
- Fully Discrete Pre-Amplifier: Current Feedback pre-amplification with HDAM-SA3 is thoughtfully designed to match the requirements of super audio High Resolution music for wide-bandwidth and high-speed reproduction. Each part is selected and optimized for sound quality and performance.
- Switching Power Amplification: MODEL 30 maintains the purest possible sound and supports the power needed to drive the most demanding speakers, delivering 2x100W into an 8ohms load, and easily copes with low impedance speakers thanks to a 2x200W output into 4ohms.
- Twin power supplies: A clean power supply is dedicated exclusively to preamp to ensure high purity. The amplification power supply delivers high current instantaneously. The MODEL 30 will follow even the hardest bass attacks and provides clean power for the reproduction of the finest details.
- Multiple Analog Inputs: In addition to phono and CD analog inputs, MODEL 30 features two line-level inputs and one pair of recorder input/output jacks that enable the connection of multiple sources and recorders.
- Main In and Pre Outs: Use MODEL 30 as a standalone stereo power amplifier for additional system configuration versatility with the included power amp direct input. For example, use the front pre-outs of your AV setup and run them through MODEL 30 power amps.
- Dedicated Headphone Output: The advanced headphone circuit delivers superb audio fidelity with the widest range of headphone types and impedances, including low impedance headphones.
Whats Included
- MODEL 30 Integrated Amplifier 200W x2 ch. Sound Master Tuning
- MODEL 30 Integrated Amplifier 200W x2 ch. Sound Master Tuning
Q: Wi-Fi output for speakers???
A: Hello, the Marantz MODEL 30 does not allow for Wi-Fi output for speakers. For network abilities, consider pairing the MODEL 30 with Marantz SACD 30.
Q: can i connect the model 30 to play audio through tv
A: Hello, Yes - the TV just needs to be connected either with an analog audio out (typically using the TV's headphone port with a 3.5mm headphone jack at one end and RCA plugs at the other end), or with an optical cable (make sure your TV's Digital Audio output is switched to PCM when doing this).
