Powerbass - PBX-600.6 - 6-Channel Compact Amplifier, Class-D, 100 watts x 6 at 4-Ohms, 150 watts x 6 at 2-Ohms - Black/Gray

The NXL-M6 is a 6-channel car amplifier from the DS18 NXL-M series, built as a Class D design. It delivers 6 x 230 watts RMS at 2 ohms and 6 x 150 watts RMS at 4 ohms. Total harmonic distortion is rated at less than 0.15% with a signal-to-noise ratio of greater than 90dB. A selectable HPF/LPF/FULL crossover covers 40Hz - 2KHz, so you can send each channel only the frequencies it should reproduce. Bass boost is adjustable from 0-12dB centered between 45Hz - 5Hz. A IP55 waterproof rating makes it suitable for boats, side-by-sides and powersports vehicles where the amplifier is exposed to water and spray. Match the amplifier to the RMS rating of your speakers or subwoofers and set the gain to that rating for clean, reliable output.

The Vega Series Amplifiers have solidified their place as the backbone of the Cerwin-Vega Mobile brand, delivering unrivaled performance in a sleek, compact package. Don’t be deceived by their streamlined design—these amplifiers pack a punch with monstrous power output to drive your system to its fullest potential. Innovation Meets Power Updated High-Efficiency Full Range Digital Topology: Experience exceptional sound clarity with maximum energy efficiency. Enhanced Power IR Digital Chipset: Engineered for stability and precision, ensuring consistent performance under any condition. Engineered for Durability Conformal-Coated 4-Layer PCB: Protected against moisture and environmental wear for long-lasting reliability. Water-Resistant Design: Built to withstand the rigors of the road, wherever your journey takes you. Specifications POWER RATING RMS Power (2Ω): 150W x 6 RMS Power (4Ω): 100W x 6 Bridged (Mono 4Ω): 300W X 3 POWER SUPPLY Power Supply: Full PWM Power Supply Threshold: 10.0V-17.0V (DC) Idle Current: (0.7A) DISTORTION THD 4 (1KHz @4Ω): 0.05% S/N Ratio (A weighted @1W): -85 dBA S/N Ratio (A weighted @FP): -101.1 dBA INPUT SENSITIVITY Low Input Level: 200mV-10.0V High Input Level: 200mV-10.0V INPUT IMPEDANCE Low Input Level: 20 KΩ High Input Level: 20 KΩ OUTPUT STAGE Output Impedance: 0.018Ω Damping Factor (50Hz @ 4Ω): >250 Bandwidth (-3dB): 10Hz-35KHz CROSSOVER (-12/-24 dB/Oct) Variable High-Pass: Flat or Fixed 70Hz Variable Low-Pass: 40Hz-400Hz FUSE RATINGS ATC: 60A DIMENSIONS L x W x H: 11.24”x 4.02”x 1.4” (285.6mm x 102mm x 36mm) FEATURES Full Range Class D IR Chipset DirectFET Power Mosfet Output Stage SMD Technology on 4-Layer PCB Board Water Resistant Conformal PCB Board Coating 1-year Manufacturer's Warranty

The PowerBass PBX Series Amplifiers are the cleanest most efficent amplifiers we have built to date, with attention to sonic accurracy, clarity, and a bold use of efficient power, this series is guaranteed to have smiling with pure musical enjoyment. PBX Ultra High Efficiency Amplifiers are the result of extensive engineering and testing to develop the best sounding and most efficient power delivery we have ever produced. With the success of our previous XMA series our engineers went to work on the PBX Series with the goal of creating true works of art featuring high quality parts and an ultra efficient circuit design proving to be some of the best Class D amplifiers on the market today. The PBX Series represents the very latest in Class D Technology. IR, a leader in PWM circuit design, has worked in conjuction with PowerBass engineers to produce more stable power output, minimal RF interference and improved sound quality. Specifications - • Peak Power: 1400 watts • Subwoofer Frequency Range: 10 Hz - 250 Hz • Inputs: 3 Pairs RCA (speaker level compatible) • Dimensions (in Inches): 13.25x7x2.25 • Depth: 13.25 • Channels (mono): 5 • 4-ohm Power: 100 watts x 4 + 500 watts x 1 • 4-ohm Mono Power: 400 watts x 2 + 500 watts x 1 (4-ohm) • 2-ohm Power: 150 watts x 4 + 800 watts x 1 • 1-ohm Mono Power: N/A • Variable Subsonic Freq: 10Hz - 50Hz • Height: 2.25 • Width: 7 • Subwoofer EQ Frequency: 45Hz • Variable Subwoofer EQ: 0-18db • Low-Pass Crossover Freq: 25 Hz - 250 Hz • High-Pass Crossover Freq: 50 Hz - 350 Hz • Crossover Slope: 12 dB • Input Sensitivity: 0.25 V - 10.0 V • S/N Ratio: >90 dB • Strapped Output Power @ 2ohms: N/A • Output Power (14.4 V) @ 4 ohm: 100 watts x 4 + 500 watts x 1 • Output Power (14.4 V) @ 2 ohm: 150 watts x 4 + 800 watts x 1 • Output Power (14.4 V) @ 1 ohm: N/A • Frequency Response: 10 Hz - 40 kHz
