Wavtech - LINK750.1PLUS 750 Watt Mono Amplifier - Black/Gray

Create a custom sound experience with this KICKER CX-Series mono amplifier. The variable 12dB crossovers provide the control you need to get the exact sound you want, and the 24dB subsonic filter protects against damaging frequencies. With its small footprint and Fail-safe Integration Technology-PLUS, this KICKER CX-Series mono amplifier is easy to install and works with almost any radio.

The link1000.1mini is the most powerful amplifier in the Wāvtech mini series. This amp makes 1000 watts RMS @ 2ohms. The speaker level inputs of the link1000.1mini can handle up to 40V and have our adaptive loading technology, making for easy connection to both factory and aftermarket head units. At 12.2”x4.5”x1.65”, it is easily one of the smallest 1000 watt RMS amplifiers available today. The link1000.1mini has Wāvtech’s bassFREQ preamp, with a 24dB per octave crossover, an adjustable parametric EQ and a subsonic filter. This provides the fine tuning required to get the most out of any subwoofer system. The optional linkRC remote allows for control of the subwoofer system from the vehicles front seat. The link1000.1mini is also compatible with OEM start/stop systems. link1000.1mini Features 1000 Watt Mono Amplifier 600 watts x 1 @ 4 ohms 1000 watts x 1 @ 2 ohms Only 12.2”x4.5”x1.65” Fully Adjustable Parametric EQ Variable Low-Pass Crossover (-24dB/oct) Variable Subsonic Filter (-24dB/oct) Remote Level Control (RLC) w/Optional linkRC Start/Stop System Compatible Differential Balanced Inputs Variable Gain Adjustment w/Clip LED Auto Turn-On via DC-Offset or Audio Signal Detect Adaptive OEM Load Detect Technology Locking Detachable Hi-Level Speaker Terminals Professional Grade Panel Mount RCA’s Compact Aluminum Chassis w/Detachable Mounting tabs link1000.1mini Specifications Input Sensitivity SPK: 1-20Vrms, 2-40Vrms RCA: 0.2V-5Vrms, 0.4V-10Vrms Max Input Voltage (SPK): 40Vrms Frequency Response: 500Hz (=0/-3dB) THD+N: 78dBA (1W, 4Ω)

800 Watt High Efficiency Class D Design Front Load Terminal Design 1-OHM Stable Mono Block Amplifier Ultra Low Current Draw Double Sided Copper Plated PCB PWM MOSFET Power Supply Digital Sound Optimization Circuitry High Damping Control Circuit Variable Subsonic Filter High Current Voltage Ripple Rejection Circuitry Balanced RCA Inputs Selectable Auto Turn On Circuit Remote Soft Delay Turn On/Off Circuit 40 Click Variable Low Pass Electronic Crossover Variable Gain Control Wired Secondary Remote Gain Control Included Calibrated Visual Clipping Indicator Protection Circuit: Impedance Over-load, Speaker Short, Circuit, Thermal Overheating, and DC Output Specifications Peak Power: 1600 watts Subwoofer Frequency Range: 10Hz - 300 Hz Dimensions (in Inches): 10.25x7x2.25 Depth: 10.25 Channels (mono): 1 4-ohm Power: 400 watts x 1 4-ohm Mono Power: 400 watts x 1 2-ohm Power: 600 watts x 1 1-ohm Mono Power: 800 watts x 1 Nominal Impedance: 1 Height: 2.25 Width: 7 Subwoofer EQ Frequency: 40 Hz- 100 Hz Low-Pass Crossover Freq: 35 Hz - 250 Hz High-Pass Crossover Freq: N/A Crossover Slope: 24 dB Input Sensitivity: 0.25 V - 7 V S/N Ratio: >95 dB Strapped Output Power @ 2ohms: 1600 watts x 1 Output Power (14.4 V) @ 4 ohm: 400 watts x 1 Output Power (14.4 V) @ 2 ohm: 600 watts x 1 Output Power (14.4 V) @ 1 ohm: 800 watts x 1 Frequency Response: 10 Hz - 300 Hz
