GE - 21" Electric Cooktop - White
- Key Specs
- Product Height: 3 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 20.13 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 16.13 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Cooktop Surface Type: Smoothtop (On electric cooktops, coil elements are typically more durable and tend to provide more evenly conducted heat than smoothtops. However, smoothtops may be easier to clean and have a distinctive streamlined appearance.)
- General
- Product Name: 21" Electric Cooktop
- Brand: GE
- Model Number: JP256WMWW
- Dimensions
- Product Height: 3 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 20.13 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 16.13 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Standardized Width: 22 inches (An approximated measurement (exact width may differ slightly) determined by the manufacturer in accordance with industry standards. Standardized sizes are intended to assist consumers when purchasing appliances and planning for installation.)
- Product Weight: 17 pounds (The out of box weight of the item.)
- Features
- Downdraft Ventilation: false (This ventilation system, typically integrated right into the cooktop, pulls smoke and fumes downward in order to ventilate them away from the cooking area. If a range hood is not an option due to your cooktop location or you need more cabinet space above the cooking surface, downdraft ventilation will save space while ensuring smoke and odors are still being ventilated.)
- Control Type: Electronic
- Control Location: Front panel
- Power-On Indicator Light(s): true
- Hot Surface Indicator(s): true (Visual indicators turn on when the cooktop surface is hot and remain on until it is cooled, acting as a convenient safety reminder.)
- Cooktop Features
- Induction: false (Induction cooktops use magnetic currents to heat compatible cookware directly instead of warming the cooktop itself, which can allow for faster and more efficient cooking. There is also an added safety benefit because the surface begins to cool when cookware is removed.)
- Cooktop Surface Type: Smoothtop (On electric cooktops, coil elements are typically more durable and tend to provide more evenly conducted heat than smoothtops. However, smoothtops may be easier to clean and have a distinctive streamlined appearance.)
- Cooktop Surface Material: Ceramic, Glass
- Bridge Element: false (This feature is an additional heating element located between two individual burners. When this is enabled, the individual burners and the bridge element act as one connected cooktop. This equal heat distribution on the cooktop surface helps accommodate larger cookware, such as roaster pans or griddles.)
- Specialty Element(s): false
- Expandable Element: true (Accommodate large cookware and ensure even heat distribution with this feature, which allows more surface area for the individual heating element.)
- Included
- Power Cord Included: false (Connects your product to an electrical outlet, allowing for immediate use (provided that other installation requirements are met).)
- Power
- Cooktop Power Source: Electric
- Other
- UPC: 084691164951
This electric cooktop features powerful ribbon heating elements that provide heat beneath the ceramic-glass surface to ensure even heat and fast warm-up times. A 6" or 9" dual heating element offers a convenient heating choice depending on the size of your cookware. Product specs and dimensions (PDF)
- Infinite-heat controls: Allow for precise temperature adjustments. Dishwasher-safe knobs allow for easy cleaning.
- Powerful ribbon heating elements: Provide even, fast heating beneath a smooth, glass surface to ensure even heat and fast warm-up times.
- 6" or 9" dual heating element: Offers a convenient choice of using either size element depending on the size of the pan.
- Simmer option: Delivers 140° temperature that is ideal for simmering soups and sauces.
- Hot-surface indicator light and element-on light: Lets you know when the surface is too hot to touch.
- Ceramic-glass cooktop: Provides a smooth surface that makes cleaning fast and simple.
Whats Included
- GE 21" Electric Cooktop
- Owner's Manual
Q: just curious, can this accommodate 220 volt? or strictly 110v
A: Hi poweroutput! Thanks for your question! We'd be happy to help! This model requires 208/240V to operate normally. If you have a 220V power supply, you will be able to operate this cooktop, so long as the rest of the installation instructions are followed. We hope that this helps! Stay safe. -Michael
Q: How does the “ribbon heating element” compare to the type of element in this cooktop JP5030SJSS?
A: Hello Curios. Both models have the same type of a ribbon element. Thanks for checking. Olga
Q: how do i measure to make sure this electric cooktop will fit where my old one is
A: Hi Peg- Thanks for choosing GE! We suggest to view a short video regarding measuring for a new cooktop: https://www.bestbuy.com/site/ge-21-built-in-electric-cooktop-black/8589967.p?skuId=8589967 - We also suggest to view page 15 of the Installation Instructions at the following link for complete details on cutout requirements for this model: http://products.geappliances.com/MarketingObjectRetrieval/Dispatcher?RequestType=PDF&Name=49-80508-5.pdf - We hope this is helpful. Keep in touch at 1-800-626-2005 or visit GEAppliances.com. Enjoy! SUE@GEA
