KitchenAid - 4.1 Cu. Ft. Self-Cleaning Slide-In Dual Fuel Convection Range
Model: KDRS407VSS
SKU: 1648107
This item is no longer available in new condition. See similar items below
- Key Specs
- Product Height: 35 3/4 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 29 3/4 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 29 9/16 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Depth Without Handle: 27 3/4 inches (Measurement from the back of the product to its front (with door closed), not including handle.)
- Depth With Handle: 29 9/16 inches (Measurement from the back of the product to its front (with door closed), including the handle.)
- Range Type: Slide-In (Freestanding ranges have finished sides and a backguard where the oven controls are located; this style allows for the most versatility in placement. Slide-in ranges may have unfinished sides and are wider at the top to overlap the countertop on each side, allowing for a built-in appearance. Drop-in ranges are also known for their built-in style and are designed to fit custom cabinetry or countertops.)
- Single/Double Oven: Single Oven
- Color Finish: Stainless steel
- General
- Product Name: 4.1 Cu. Ft. Self-Cleaning Slide-In Dual Fuel Convection Range
- Brand: KitchenAid
- Model Number: KDRS407VSS
- Color Finish: Stainless steel
- Dimensions
- Product Height: 35 3/4 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 29 3/4 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 29 9/16 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Standardized Width: 30 inches (An approximated measurement (exact width may differ slightly) determined by the manufacturer in accordance with industry standards. Standardized sizes are intended to assist consumers when purchasing appliances and planning for installation.)
- Depth Without Handle: 27 3/4 inches (Measurement from the back of the product to its front (with door closed), not including handle.)
- Depth With Handle: 29 9/16 inches (Measurement from the back of the product to its front (with door closed), including the handle.)
- Product Weight: 413 pounds (The out of box weight of the item.)
- Capacity
- Oven Capacity: 4.1 cubic feet (Standard ovens typically have capacities of about 5 cubic feet, while wall ovens typically have about 3 cubic feet of space.)
- Features
- Range Type: Slide-In (Freestanding ranges have finished sides and a backguard where the oven controls are located; this style allows for the most versatility in placement. Slide-in ranges may have unfinished sides and are wider at the top to overlap the countertop on each side, allowing for a built-in appearance. Drop-in ranges are also known for their built-in style and are designed to fit custom cabinetry or countertops.)
- Downdraft Ventilation: false (This ventilation system, typically integrated right into the cooktop, pulls smoke and fumes downward in order to ventilate them away from the cooking area. If a range hood is not an option due to your cooktop location or you need more cabinet space above the cooking surface, downdraft ventilation will save space while ensuring smoke and odors are still being ventilated.)
- Range Power Source: Dual fuel
- Ignition Type: Electric
- Oven Control Location: Front panel
- Clock Display: true
- Oven Light: true
- Hot Surface Indicator(s): false (Visual indicators turn on when the cooktop surface is hot and remain on until it is cooled, acting as a convenient safety reminder.)
- Functions
- Sabbath Mode: true (This mode complies with the rules of Halakha and allows Shabbat-observant people to use the appliance on the Shabbat and other Jewish holidays.)
- Hidden Bake Element: true (This feature provides more space within the cooking cavity and allows for cleaning without navigating around an exposed heating element.)
- Oven Features
- Induction: false (Induction cooktops use magnetic currents to heat compatible cookware directly instead of warming the cooktop itself, which can allow for faster and more efficient cooking. There is also an added safety benefit because the surface begins to cool when cookware is removed.)
- Single/Double Oven: Single Oven
- Number of Oven Racks: 3
- Oven Window: true
- Cooktop Features
- Cooktop Surface Material: Stainless steel
- Sealed Burners: false (A cap covers the internal components of the burner to prevent food spilling into the flame or under the cooktop, allowing for easier cleaning.)
- Specialty Burner(s): Simmer (Do more with your cooktop with burners designed for specific cooking needs and precise control. For example, simmer burners provide consistent, low-temperature heat for melting delicate foods or simmering sauces, while power burners provide high cooking power for quick boiling, searing, or stir-fry cooking.)
- Grate Material: Cast iron
- Included
- Power Cord Included: false (Connects your product to an electrical outlet, allowing for immediate use (provided that other installation requirements are met).)
- Other
- UPC: 883049155678
Cook your meals at the correct temperature with this dual fuel range that features an Even-Heat true convection system for excellent cooking results. The Ultra Power dual-flame burner provides temperatures for a variety of cooking options.
- Glass-touch oven controls: For easy operation.
- 4.1 cu. ft. oven: Accommodates multiple courses simultaneously.
- Cast-iron grates: Provide a durable cooktop surface.
- 5,000-20,000 BTUs of heat: Meet various cooking needs.
- Warm hold: Keeps food warm until you're ready to serve it.
- 5,000 BTU simmer/melt burner: Delivers a low heat setting to slowly heat specialty food and sauces without scorching.
- Ultra Power dual-flame burner: Delivers up to 20,000 BTUs of heat to accommodate a variety of recipes.
- Even-Heat true convection oven: Provides consistent heating throughout the oven for even cooking results.
- EasyConvect time and temperature conversion system: Easily converts recipes to match convection cooking requirements.
- Sabbath mode: Safely maintains a temperature for an extended period of time in order to comply with kosher cooking practices.
- Hidden bake element: Reduces cleanup time.
- Self-cleaning oven: Conveniently eliminates the need to scrub by doing the cleaning for you.
- Oven window and 2 oven lights: Let you keep an eye on food being cooked without opening the oven door and letting heat escape.
Q: does this range have a bottom drawer?
A: Hello Mike9, there is no drawer on the bottom of this Range. We hope this helps.
Q: Does the model KDRS407VSS come in a 120v hook up? My set up is for a 120v hook up.
A: Hello Mitch, yes. This appliance is setup for 120v hook up. We hope this helps!
Q: What is the wattage of this range
A: DaveF, the electrical requirements are on page 9 of the Installation Instructions. We've included the link for the instructions below. Hopefully this information is beneficial to you. Thank you for your inquiry regarding our KitchenAid appliances! https://bit.ly/3eU7sap
Q: Does the middle stove top griddle exchange out for a flat surface to make pancakes etc... ?
A: LM, we apologize but it can not. Hopefully, this information is beneficial to you. Thank you for your inquiry regarding our KitchenAid appliances!
Q: Will a microwave vent provide sufficient ventilation?
A: Hello Maureen! Yes, a microwave vent should provide sufficient ventilation. Thank you for your inquiry on our KitchenAid appliances.
Q: Does this slide in range need any counter top behind it or does the range go tight against the wall?
A: Yes it goes flush against the wall...
Q: Will the range work when the power is out?
A: The burners can work during power outage.
Q: Does this model have down draft ventilation?
A: No it doesn’t
