Lenovo - ThinkVision 19.5" IPS LED HD Monitor - Raven black
- Key Specs
- Refresh Rate: 60Hz (The number of frames per second the device can produce natively without enhancement. Higher rates help produce smooth, seamless pictures.)
- Maximum Resolution: 1440 x 900 (Maximum resolution refers to the highest number of pixels that a screen can process and display. Higher resolution signals produce more detailed images.)
- Response Time: 7 milliseconds (The speed at which pixels can change colors is called response time. It is measured in milliseconds (ms).)
- Panel Type: IPS (Technology that affects response time and image quality.)
- Screen Size: 19.5 inches (Size of the screen, measured diagonally from corner to corner.)
- General
- Product Name: ThinkVision 19.5" IPS LED HD Monitor
- Brand: Lenovo
- Operating System Compatibility: Windows
- Model Number: 60DFAAR1US
- Display
- Refresh Rate: 60Hz (The number of frames per second the device can produce natively without enhancement. Higher rates help produce smooth, seamless pictures.)
- Maximum Resolution: 1440 x 900 (Maximum resolution refers to the highest number of pixels that a screen can process and display. Higher resolution signals produce more detailed images.)
- Native Resolution: 1440 x 900 (Native resolution of a screen refers to its single, fixed resolution. Sometimes screens must scale an image up or down in order to fit the native resolution. This can cause a loss of resolution or detail.)
- Contrast Ratio: 1000:1 (Measured difference between a displayed image's brightest whites and darkest blacks. The larger the first number, the more detail and color that can be displayed.)
- Response Time: 7 milliseconds (The speed at which pixels can change colors is called response time. It is measured in milliseconds (ms).)
- Display Type: LCD
- Panel Type: IPS (Technology that affects response time and image quality.)
- Aspect Ratio: 16:10 (The measurement of the width of a screen compared to the height of a screen, expressed as a ratio.)
- Curved Screen: false
- Pixel Density: 87 pixels per inch (The number of pixels present per inch on the device's display. Higher pixel density improves the clarity and sharpness of the displayed image.)
- Brightness: 250 candela per square meter (A measure of the total light output.)
- Screen Size: 19.5 inches (Size of the screen, measured diagonally from corner to corner.)
- Horizontal Viewing Angle: 178 degrees (The maximum angle at which the display can be viewed with acceptable visual performance from either side.)
- Vertical Viewing Angle: 178 degrees (The maximum angle at which the display can be viewed with acceptable visual performance from above or below.)
- Touch Screen: false (Touch-screen devices make navigating more intuitive. Using a touch-screen display, you can do things such as tap to select, hold and drag to move items, swipe to scroll, and pinch to zoom.)
- Connectivity
- Number of VGA Ports: 1 (VGA (Video Graphics Adapter or Video Graphics Array) is a display standard that transmits via analog signals. This type of interface is typically used to connect a computer to a display device such as a monitor, projector, or TV.)
- Compatibility
- Wall Mountable: true (The product is able to be secured to a wall. Some products are designed ready to mount, while others may require additional hardware/accessories for installation.)
- VESA Wall Mount Standard: 100mm x 100mm (VESA wall mount standards refer to the spacing of screw holes built into a TV in order to fit with standard TV wall mounts. These standards are implemented into most TVs and monitors.)
- Features
- Tiltable: true
- Adjustable Stand Height: true
- Built-In Webcam: false
- Dimensions
- Product Height With Stand: 14.65 inches
- Product Width: 18 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth (With Stand): 7.4 inches
- Product Weight: 4.8 pounds (The out of box weight of the item.)
- Stand Included: true
- Cord Length: 72 inches
- Power
- Power Consumption: 16 watts
- Power Saving/Off Mode: 0.5 watts (This mode will turn the display and/or the device off, or into a standby mode, after a preset length of time with no activity to conserve power.)
- Certifications Listings & Approvals
- ENERGY STAR Certified: true (Devices carrying the ENERGY STAR service mark, such as computer products and peripherals, kitchen appliances, and other products, generally use 20% to 30% less energy than required by federal standards.)
- EPEAT Qualified: false (The Electronic Product Environmental Assessment Tool (EPEAT) was designed to provide an environmental assessment tool for purchasers. In order to qualify for EPEAT, a product must meet all 23 required criteria.)
- Warranty
- Manufacturer's Warranty - Parts: 3 Years
- Manufacturer's Warranty - Labor: 3 Years
- Other
- UPC: 889955037428
Customize your computing station with this Lenovo ThinkVision monitor. The LCD screen supports resolutions up to 1440 x 900, and it comes with 18 standard presets and 10 programmable user settings for convenient switching. The adjustable stand of this Lenovo ThinkVision monitor lets you create an ergonomic entertainment or work area.
- 1440 x 900 HD resolution with 16:10 aspect ratio: Offers arresting images with rich detail.
- 7 ms response time: Delivers solid performance for precise gaming and video work.
- Watch crisp images: The 60Hz refresh rate is a good choice for gaming and other fast-moving media.
- 19.5" LED monitor: Efficient screen type uses LEDs to provide precise backlighting to pixels.
- VGA input: Enables simple connectivity.
- 178° horizontal and vertical viewing angles: Allow you to view the screen from a wide range of angles.
- 1,000:1 contrast ratio: Ensures images are crisp and clear with deep blacks and bright highlights.
- 250 cd/m² brightness: Ensures images are clear and can be seen across the room.
- ENERGY STAR certified: Designed to use less energy and meets strict energy efficiency guidelines set by the Environmental Protection Agency and U.S. Department of Energy.
Whats Included
- Lenovo ThinkVision 19.5" IPS LED HD Monitor
- Stand
- VGA cable - 6 ft
Product Manuals
A: The Lenovo IdeaPad 320-15ABR has an HDMI-Out port for attaching an external monitor. You can use one external monitor and the laptop screen for two displays. The Lenovo ThinkVision monitor has only one VGA port so you would need a HDMI to VGA adapter to connect this monitor to your IdeaPad 320-15ABR. You could select another monitor with an HDMI connection available as well.
Q: is this Monitor compatible with the Lenovo Ideacentre Desktop 2HDDU2B?
A: This monitor has a VGA video connector only. Check the specific model computer you have for the video ports available.
A: No. The Lenovo ThinkVision 19.5-inch monitor, model number 60DFAAR1US, does not have built in speakers.
A: Yes, the Lenovo ThinkVision 19.5" IPS LED HD Monitor ships with a 6-foot VGA cable.
A: The Lenovo ThinkVision 15.5-inch monitor, model number 60DFAAR1US, ships with a VGA input to connect a computer.
Q: Will this connect and operate with Lenovo 920?
A: No. This monitor has a VGA connector. The Yoga 920 has a Thunderbolt port that carries a video signal. You can connect an HDMI monitor to the Yoga 920 by using a Thunderbolt to HDMI adapter.
