Specifications
- Speaker TypeIn-Wall
- Key Specs
- Speaker Type: In-Wall
- General
- Brand: Sonance
- Model Number: R1/93344
- Product Name: R1 REFERENCE RECTANGLE SINGLE SPEAKER - Reference 5-1/4" 3-Way In-Wall Rectangle Speaker (Each)
- Color: Paintable White
- Audio
- Speaker Type: In-Wall
- Peak Power Handling: 150 watts (The maximum amount of power an electronic device, like a speaker, can handle without damage. This refers to short bursts of power, while root mean square (RMS) power handling indicates the amount of continuous power a device can sustain. Higher levels of distortion can also occur at peak power levels when the device is powered beyond its recommended usage.)
- Impedance: 8 ohms (Describes the resistance of an electric signal throughout the system. Devices with low impedance require less power to deliver optimal signals but are more at risk for damage from overloading. Higher impedance requires more power but is more protected from overload damage.)
- Minimum Frequency Response: 70 hertz (Describes the maximum range of frequencies or musical tones a product can reproduce, from very low tones to very high treble tones. The minimum frequency or musical tone the speaker can reproduce. High treble tones have higher frequencies while low tones and deep bass have lower frequencies.)
- Maximum Frequency Response: 30 kilohertz (Describes the maximum range of frequencies or musical tones a product can reproduce, from very low tones to very high treble tones. The maximum frequency or musical tone the speaker can reproduce. High treble tones have higher frequencies while low tones and deep bass have lower frequencies.)
- Sensitivity: 90 decibels
- Tweeter Type: Dome
- Midrange Type: Cone
- Woofer Type: Cone
- Number of Speakers: 1
- Number of Tweeters: 1
- Tweeter Size: 1 inches
- Number of Midranges: 1
- Midrange Size: 5.25 inches
- Number of Woofers: 2
- Woofer Size: 5.25 inches
- Connectivity
- Speaker Connectivity: Wired
- Wireless Multi-Room Audio: false (Technology that allows multiple speakers and/or soundbars to be connected wirelessly and play audio in separate rooms.)
- Audio Only Inputs: No audio only inputs, No audio only inputs, No audio only inputs
- Network Connector(s): No network connectors, No network connectors, No network connectors
- Speaker Wire Connection Type: Banana Jack/Screw Terminals
- Features
- Indoor Or Outdoor Use: Indoor (Indicates the appropriate environment product was designed to be used in.)
- Dimensions
- Product Height: 21.8 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 8.9 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 3.9 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Product Weight: 17.5 pounds (The out of box weight of the item.)
- Mounting Dimensions: 5.25 Cut out diameter
- Material
- Tweeter Material: Ceramic
- Midrange Material: Carbon fiber/Rohacell, rubber
- Woofer Material: Carbon fiber/Rohacell, rubber
- Included
- Cable(s) Included: None
- Speaker Wire Included: false
- Certifications Listings & Approvals
- ENERGY STAR Certified: false (Devices carrying the ENERGY STAR service mark, such as computer products and peripherals, kitchen appliances, and other products, generally use 20% to 30% less energy than required by federal standards.)
- Warranty
- Warranty - Parts: Limited Lifetime
- Warranty - Labor: Limited Lifetime
- Other
- UPC: 041093933448
Enjoy rich audio quality with this Sonance Reference in-wall speaker. Individual crossover networks deliver clear, precise sound, while the mix-and-match configuration works with other Sonance components to create a complete home audio system. This Sonance Reference in-wall speaker fits in most standard wall cavities, creating a seamless look for your entertainment center.
- 150W peak power handling: Helps ensure rich, dynamic sound.
- Two 5-1/4" carbon fiber woofers: Along with 1" ceramic tweeter for a complete range of sounds.
- 3-way speaker system: Sounds like 1 source rather than several separate sources.
- Removable grille: Remains acoustically transparent while protecting the speaker's components.
- Wall-mountable design: For flexible placement options.
- 20-1/2" H x 7-1/2" W mounting cut-out dimensions: Mounting depth: 3-7/8".
- 70Hz - 30kHz frequency response: Ensures a wide range of accurately reproduced sound.
- 90dB sensitivity: Ensures crisp, robust audio.
- 8 ohms nominal impedance: Ensures efficient conduction of power through the speaker.
Whats Included
- (1) Sonance Reference 5-1/4" 3-Way In-Wall Speaker
- (1) Speaker cut-out template
- (1) White paintable grille
- (1) Quick Start Guide
Product Manuals
Q: What is the minimum frequency response of the speaker?
A: The minimum frequency response of the speaker is 70 hertz.
Q: What is the maximum power handling of the speaker?
A: The peak power handling of this speaker is 150 watts.
A: This speaker is not wireless.
Q: How many woofers are included in the speaker?
A: This speaker includes two woofers.
Q: Do the speaker grilles come included?
A: The speakers come with speaker grilles.
