Specifications
- RMS Power184 wattsWoofer Size10 inches
- Key Specs
- RMS Power: 184 watts (The maximum amount of continuous power the device is able to handle.)
- Woofer Size: 10 inches
- General
- Brand: Sonance
- Model Number: VPSUB/93353
- Product Name: VPSUB - Visual Performance 10" Passive In Wall Subwoofer (Each)
- Color: Paintable White
- Audio
- Minimum Frequency Response: 34 hertz (Describes the maximum range of frequencies or musical tones a product can reproduce, from very low tones to very high treble tones. The minimum frequency or musical tone the speaker can reproduce. High treble tones have higher frequencies while low tones and deep bass have lower frequencies.)
- Maximum Frequency Response: 250 kilohertz (Describes the maximum range of frequencies or musical tones a product can reproduce, from very low tones to very high treble tones. The maximum frequency or musical tone the speaker can reproduce. High treble tones have higher frequencies while low tones and deep bass have lower frequencies.)
- Sensitivity: 90 decibels
- Impedance: 8 ohms (Describes the resistance of an electric signal throughout the system. Devices with low impedance require less power to deliver optimal signals but are more at risk for damage from overloading. Higher impedance requires more power but is more protected from overload damage.)
- Speaker Type: In-Wall
- Subwoofer Type: Passive (Passive subwoofers require an external amplifier, such as the one driving the main speakers in the system, for power. Active subwoofers, on the other hand, have a designated amplifier (one that isn't shared with other speakers) for power as well as line-level crossover.)
- Enclosed: true
- Features
- Indoor Or Outdoor Use: Indoor (Indicates the appropriate environment product was designed to be used in.)
- Connectivity
- Network Connector(s): No network connectors, No network connectors, No network connectors
- Subwoofer Connection Type: Banana Jack/Screw Terminals
- Wireless: false
- Dimensions
- Product Height: 15 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 15 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 3.9 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Product Weight: 11.5 pounds (The out of box weight of the item.)
- Material
- Woofer Composition: Laminated carbon fiber
- Included
- Remote Control Included: false
- Cable(s) Included: None
- Warranty
- Warranty - Parts: 5 Years
- Warranty - Labor: 5 Years
- Other
- UPC: 041093933530
Build a custom home theater sound system with the help of this Sonance Visual Performance subwoofer. A laminated carbon fiber cone with rubber surround delivers impressive audio quality, while the unique design works with other Sonance components to create an immersive listening experience. Designed for in-wall or in-ceiling installation, this Sonance Visual Performance subwoofer blends seamlessly with your room for a low-profile look.
- 10" passive subwoofer: Delivers authoritative bass for high-impact home theater audio. Works with Sonamp DSP 2-150 or Sonamp DSP 8-130 MKII amplifiers (sold separately).
- Removable paintable grille: Remains acoustically transparent while protecting the speaker's components. Also allows you to match your décor.
- In-wall mountable design: For flexible placement options.
- 34-250Hz frequency response: Delivers booming lows for an immersive soundscape.
- 90dB sensitivity: For powerful sound.
- 8 ohms nominal impedance: Provides efficient conduction of power.
- 12-3/4" H x 12-3/4" W mounting cutout dimensions: Mounting Depth: 3-7/8"
Whats Included
- (1) Sonance Visual Performance 10" Passive In-Wall Subwoofer
- (1) Cut-out template
- (1) Quickstart Guide
Product Manuals
Q: What is the impedance of this subwoofer?
A: This subwoofer has a nominal impedance of 8 ohms.
Q: What type of subwoofer is this?
A: This is a passive subwoofer.
Q: What is the frequency response range of this subwoofer?
A: This subwoofer has a frequency response of 34-250Hz.
Q: How sensitive is this subwoofer?
A: It has a sensitivity of 90dB.
Q: Can the grille on this subwoofer be painted?
A: Yes, the grille is removable and paintable.
Q: What is the diameter of the subwoofer?
A: This Sonance Visual Performance subwoofer features a 10-inch passive subwoofer.
Q: Does this subwoofer have a built-in amplifier?
A: No, this subwoofer does not have a built-in amplifier.
Q: Hi I have Marantz - Cinema 60 100W 7.2-Ch Bluetooth. Do I need an additional amp?
A: Hi, Thank you for your question. You will need to power the subwoofer with an additional amplifer. We reccomend using the Sonance DSP 2-150 MKIII using both channels bridged (BBYSKU # 6562194.) I hope you found this information helpful. If you have additional questions, please feel free to call our California-based support team at 949-492-7777 and ask for Tech Support. We are available Monday - Friday, 8 AM to 5 PM PST. We'd love to help you out. - Sonance Tech Support Team
