A:Answer Hi Winchuck.
Thank you for reaching out regarding your Samsung - 30" Induction Cooktop with WiFi and Virtual Flame™ cutout dimensions. Regarding your concern, here are the details.
1. 281/2" - 2811/16" (724 mm - 728 mm)
2. 199/16" - 195/8" (497.4 mm - 499.4 mm)
3. Min 11/8" (28 mm). Between cutout and the wall behind the cooktop
4. Min 11/2" (38 mm). From the front edge of the cutout and front edge of the countertop
5. Min 1" (26 mm). Distance nearest left and right side combustible surface
above the cooktop.
6. Junction box or outlet 10" (254 mm) maximum from the right-hand side of
cabinet
7. Junction box or outlet 15" (381 mm) minimum from bottom of the countertop
I will be sharing your installation manual for further assistance. Please go to page 5.
https://downloadcenter.samsung.com/content/EM/201903/20190314211430975/Induction_Install_NZ30K7880U_NZ36K7880U_DG68-00827A-05_EN-MES-CFR.pdf
Should you need more assistance, please feel free to get back to us via the following options:
1. Facebook Messenger: http://m.me/samsungsupport
2. Twitter: https://twitter.com/messages/compose?recipient_id=18768513
3. Samsung Community: https://us.community.samsung.com/t5/Samsung-Community/ct-p/us
Thank you for being a valued customer of Samsung. Have a great day.
Reference Ticket Number: 1144246969
^Camille
