Swann - 16-Channel, 8-Camera Outdoor Wired 3TB DVR Surveillance System - Black/White
Model: CONV16-A4MP8C-US
SKU: 5591808
This item is no longer available in new condition. See similar items below
- Key Specs
- Camera Resolution: 1080 (Refers to the number of pixels, both horizontally and vertically, used to capture video/images. The higher the resolution the finer the detail that can be seen.)
- Field Of View: 75 degrees (The area of a target, measured as an angle from the location of viewing, that can be observed.)
- Night Vision: true
- Number Of Cameras Included: 8
- Camera Power Source: Plug-in
- Works With: Google Assistant (Compatible with or able to be connected to other smart devices or applications.)
- Number Of Channels: 16
- Recording Resolution: 2560 x 1440 (Refers to the number of pixels, both horizontally and vertically, used to capture video. The higher the resolution the finer the video detail that can be seen.)
- Storage Type: DVR
- Indoor Or Outdoor Use: Indoor, Outdoor (Indicates the appropriate environment product was designed to be used in.)
- Minimum Operating Temperature: -4 degrees fahrenheit (The lowest recommended ambient (surrounding) temperature in which the product can ideally operate stated by the manufacturer. Generally long-term exposure of the product to temperatures less than the minimum can result in ineffective operation.)
- Maximum Operating Temperature: 140 degrees fahrenheit (The highest recommended ambient (surrounding) temperature in which the product can ideally operate stated by the manufacturer. Generally long-term exposure of the product to temperatures more than the maximum can result in ineffective operation.)
- General
- Product Name: 16-Channel, 8-Camera Outdoor Wired 3TB DVR Surveillance System
- Brand: Swann
- Model Number: CONV16-A4MP8C-US
- Camera
- Camera Resolution: 1080 (Refers to the number of pixels, both horizontally and vertically, used to capture video/images. The higher the resolution the finer the detail that can be seen.)
- Field Of View: 75 degrees (The area of a target, measured as an angle from the location of viewing, that can be observed.)
- Night Vision: true
- Night Vision Distance: 82 feet
- Number Of Cameras Included: 8
- Number Of Cameras Supported: 8
- Day/Night Mode: true (Captures images/video with optimal clarity by automatically adjusting settings to various light levels.)
- IP Camera: Wired (An Internet Protocol (IP) camera is able to record and display image/video data via the internet, without need for a local recording device.)
- Minimum Required Illumination: 0 lux (Refers to the minimum amount of light needed to view objects. Generally, the lower the number, the better the camera can detect objects in little to no light.)
- Camera Infrared Distance: 82 feet (The distance over which the camera's infrared, or night vision, capabilities can detect objects.)
- Image Sensor Type: Specialty (CCD and CMOS are the two main technologies used in image sensors. CCD, the older of the two types, turns analog light signals into digital pixels. This conversion happens without distortion, resulting in high-quality images. Newer CMOS sensors use transistors at each pixel to move electrical charges. CMOS sensors are typically less expensive, but also require more light to create distortion-free images.)
- Infrared Cut Off Filter: true (Often referred to as an IR or heat-absorbing filter, this camera feature is designed to block infrared light during the day to produce optimally lit images, while still allowing for night vision capabilities in low light.)
- Camera Mount Type: Other
- Power
- Camera Power Source: Plug-in
- Compatibility
- Camera Compatibility: Not Available
- Operating System Compatibility: Android, Apple iOS, Mac, Windows
- Works With: Google Assistant (Compatible with or able to be connected to other smart devices or applications.)
- Connectivity
- Camera Connectivity: Wired (Security system cameras can be set up in several ways. Wired cameras require cables for power and footage transmission, while wire-free cameras don't need cables for either. Wireless cameras still require cables for receiving power but are able to transmit footage via a wireless network.)
- Recording & Playback
- Streaming Video: true (The ability to transmit a live video feed from the product.)
- Records Audio: true
- Number Of Channels: 16
- Video Compression Type: H.264
- Recording Resolution: 2560 x 1440 (Refers to the number of pixels, both horizontally and vertically, used to capture video. The higher the resolution the finer the video detail that can be seen.)
- Storage
- Storage Type: DVR
- DVR Storage Capacity: 3000 gigabytes
- Internal Storage Capacity Upgradeable Upto: 9000 gigabytes
- Performance
- Indoor Or Outdoor Use: Indoor, Outdoor (Indicates the appropriate environment product was designed to be used in.)
- Minimum Operating Temperature: -4 degrees fahrenheit (The lowest recommended ambient (surrounding) temperature in which the product can ideally operate stated by the manufacturer. Generally long-term exposure of the product to temperatures less than the minimum can result in ineffective operation.)
- Maximum Operating Temperature: 140 degrees fahrenheit (The highest recommended ambient (surrounding) temperature in which the product can ideally operate stated by the manufacturer. Generally long-term exposure of the product to temperatures more than the maximum can result in ineffective operation.)
- Features
- Auto-On Detection: Motion
- Sensor
- Sensors: Motion sensor (Detects stimuli such as heat, light, sound, motion, or pressure and responds accordingly by operating a control or initiating a function of the device.)
- Output
- DVR Output(s): HDMI, VGA, RCA audio, USB 2.0
- Display
- Camera Color Display: true
- Included
- Camera(s) Included: true
- DVR Included: true
- Monitor Included: false
- Remote Control Included: false
- Cable(s) Included: true
- Other
- UPC: 840236115273
Visually monitor your home or business with this Swann NVR security system. The VGA output lets you watch specific areas from your computer or smartphone when you're away, and the 3TB hard drive records your surveillance so you can view it at a later date. This Swann NVR security system also has a microphone to record sound.
- Motion-activated design: Automatically records once motion is detected.
- Monitor your property with 8 cameras: Also includes DVR, mouse, 4 security stickers, mounting hardware and screws.
- Set and forget with hard drive storage: Record continuously from 16 channels with a 3TB hard drive.
- High-resolution technology captures superior footage: 4 megapixel cameras use advanced image sensors to record clear full-screen video.
- Infrared night vision lets you see in the dark: Keep an eye on things up to 82' away when there's little to no light.
- Viewing angle up to 75°: Expertly captures a wide angle of your property for exceptional security at all times.
- HDMI and VGA outputs: Connect to a wide range of compatible displays for versatile viewing, including your HDTV, LCD or plasma TV. USB connectivity makes it easy to transfer stored footage.
Whats Included
- Swann 16-Channel
- 8-Camera Outdoor Wired 3TB DVR Surveillance System
Q: Are all 16 cameras and camera ports POE?
A: First, there are not 16 cameras in this system. There are 8 cameras included. There are, however, 16 channels, meaning that you can add additional cameras up to a total of 16. Yes, they are all Power Over Ethernet or PoE.
Q: can you make your own cat 5 cables as long as you would like.
A: Yes, we made our own cables up too 100 yards long without a problem.
A: I'm looking at buying this product when my house is finished being built in 2-3 months. I've done a lot of research on several camera systems for quite a while. According to SWANN's website, each camera DOES have its own microphone. http://www.swann.com/us/conv16-a4mp8c
A: I'm looking at buying this product when my house is finished being built in 2-3 months. I've done a lot of research on several camera systems for quite a while. According to SWANN's website, each camera DOES have its own microphone. http://www.swann.com/us/conv16-a4mp8c
