Emporia - EV Charger with Load Management - White
- General
- Brand: Emporia
- Model Number: EMC1V2-A-N-J-2P-WH
- Product Name: EV Charger with Load Management
- Color: White
- Power
- Electric Vehicle Charging Level: Level 2 (Level 1 chargers connect to a standard 120V outlet but may take nearly a day to charge a vehicle. Level 2 chargers connect to a dedicated 240V outlet and charge most vehicles within a few hours. Level 3 chargers require a specialized charger and are typically found in public, fast charging stations. Charging requirements vary by vehicle.)
- Input Wiring Type: NEMA 14-50
- Charging Cable Length: 24 feet
- Surge Protection: True
- Connectivity
- Connector Type(s): SAE J1722 (Type 1) (Type of interface connection found on the device.)
- Wireless Connectivity: Bluetooth, Wi-Fi (The manner in which a device sends data to another device over a short distance without the use of wires or cables.)
- Compatibility
- App Compatible: true (The product can be connected to a program or software application on a mobile device, which then receives collected data from the product.)
- Features
- Overload Protection: true (Features intended to protect the product from damage and overheating caused by overload.)
- Number of Vehicles Charged Simultaneously: 1
- Display Type: LED
- Mount Type: Wall
- Certifications Listings & Approvals
- ENERGY STAR Certified: true (Devices carrying the ENERGY STAR service mark, such as computer products and peripherals, kitchen appliances, and other products, generally use 20% to 30% less energy than required by federal standards.)
- Certifications and Standards: UL-2594
- Product Safety Certifications and Standard(s): UL Listed (Lists the applicable certifications and/or standards, as stated by the manufacturer, in which the product has met the requirements for the assurance of quality and safety.)
- Environmental
- Indoor or Outdoor Use: Indoor, Outdoor
- NEMA Enclosure Rating: Type 4
- Dimensions
- Product Height: 10 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 15 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 24 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Product Weight: 24 pounds (The out of box weight of the item.)
- Warranty
- Warranty - Parts: 3 years
- Warranty - Labor: 3 Year
- Other
- UPC: 850019360295
The Emporia EV Charging Station is a Level 2 electric vehicle charger that charges any EV up to 40 amps with NEMA 14-50P (with 11" cable compliant with 2017 NEC Section 625.17(A)(3)) or up to 48 amps with hardwired installation. It comes with a 24’ cable (from charger to tip of gun) with an SAE J1772 connector so it works with all electric cars. Its IP66 enclosure is made to withstand the elements outdoors.
- Intelligent Load Management: Dynamically adjusts EV charge rate, allowing the sum of breakers to exceed the electrical panel's service rating, all while keeping your home's energy consumption within system limits. Allowing you to sidestep the need for expensive electrical service upgrades.
- Meets NEC Standards: Per NFPA 70, 625.42(B) and 750.30, an EMS can control and adjust load, even up to 100% of the panel rating. The EMS is safety approved to ensure the panel rating is not exceeded. UL CERTIFIED Level 2, 48A, 240V electric vehicle (EV) charging station has flexible amperage settings from 6 to 48 amps.
- Charger Installs Indoors Or Outdoors.: Your charger will be safe from the elements with a rugged watertight NEMA Type 4 enclosure. Check with your state and local company to see if there are incentives and rebates in your area. CHARGER IS PROTECTED BY A 3-YEAR WARRANTY.
- NEMA 14-50 Plug Ready: 9.6kW (240V/40A) / 10kW (208V/48A) / 8.3kW (208V/40A) up to 40A NEMA Type 14-50P with 22" cable compliant with 2017 NEC Section 625.17(A)(3). Requires a dual-pole, dedicated breaker at 50A+ for a 40A charge. A professional electrician is recommended for installing a NEMA plug.
- UL Certified Energy Monitor Installs In Circuit Panel: Installs in most homes with clamp-on sensors. Supports single-phase up to 240VAC line-neutral; single, split-phase 120/240VAC; and three-phase up to 415Y/240VAC (no Delta). Panels with access only to busbars will need flexible sensors available from Emporia Energy.
- Compatible With Any EV: Charges any EV up to 9X faster than Level 1 wall outlet charger with a SAE J1772 connector (adapter required for Tesla EVs) and a 24' cable with integrated cable management.
Q: Does the EV charger have surge protection?
A: The Emporia EV Charger does have surge protection.
Q: What type of connector does the EV charger use?
A: This EV charger uses an SAE J1772 connector.
Q: What are the dimensions of the EV charger?
A: The EV charger is 24 inches deep, 10 inches high, and 15 inches wide.
Q: Can the EV charger be installed indoors or outdoors?
A: The EV charger has an IP66 enclosure designed to withstand outdoor elements and is suitable for indoor or outdoor use.
Q: Is the EV charger ENERGY STAR certified?
A: This EV charger is ENERGY STAR certified.
Q: What is the maximum amperage the EV charger can provide with a hardwired installation?
A: The maximum amperage the EV charger can provide with a hardwired installation is up to 48 amps.
Q: How many vehicles can the EV charger charge simultaneously?
A: This EV charger can charge one vehicle at a time.
