LG - 20.2 Cu. Ft. Top-Freezer Refrigerator
- Key Specs
- Product Height: 66 1/8 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 29 3/4 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Height To Top Of Refrigerator (Without Hinges): 65 1/2 inches (Height from bottom of refrigerator to top of the door, without the top hinges.)
- Height To Top Of Door Hinge: 66 1/8 inches (Height from bottom of refrigerator to top of the door, including the top hinge.)
- Depth Without Handle: 33 3/8 inches (Measurement from the back of the product to its front (with door closed), not including handle.)
- Depth With Handle: 33 3/8 inches (Measurement from the back of the product to its front (with door closed), including the handle.)
- Total Capacity: 20.2 cubic feet
- Refrigerator Style: Top Freezer
- Lighting Type: LED
- Ice Maker: No
- App Compatible: false (The product can be connected to a program or software application on a mobile device, which then receives collected data from the product.)
- Color Finish: Stainless steel
- General
- Product Name: 20.2 Cu. Ft. Top-Freezer Refrigerator
- Brand: LG
- Model Number: LTCS20120S
- Color Finish: Stainless steel
- Dimensions
- Product Height: 66 1/8 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 29 3/4 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 33 3/8 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Height To Top Of Refrigerator (Without Hinges): 65 1/2 inches (Height from bottom of refrigerator to top of the door, without the top hinges.)
- Height To Top Of Door Hinge: 66 1/8 inches (Height from bottom of refrigerator to top of the door, including the top hinge.)
- Counter Depth: false (The product case installs flush with the depth of standard kitchen counters to provide a built-in appearance.)
- Depth Without Handle: 33 3/8 inches (Measurement from the back of the product to its front (with door closed), not including handle.)
- Depth With Handle: 33 3/8 inches (Measurement from the back of the product to its front (with door closed), including the handle.)
- Depth Without Door: 29 inches (Measurement from the back of the product to its front, not including the door.)
- Depth With Door 90 Degrees Open: 60 inches (Measurement from the back of the product to its front, with the door open at a 90-degree angle.)
- Product Weight: 201.9 pounds (The out of box weight of the item.)
- Cut-Out Dimensions
- Cut-Out Height: 67 1/8 inches (Minimum required height of the installation location for a standard installation of the product. This measurement will help you determine if the appliance will fit into the desired space and have the clearance necessary for proper operational use. Please refer to the manufacturer’s installation documentation for detailed measurement requirements.)
- Cut-Out Width: 30 1/4 inches (Minimum required width of the installation location for a standard installation of the product. This measurement will help you determine if the appliance will fit into the desired space and have the clearance necessary for proper operational use. Please refer to the manufacturer’s installation documentation for detailed measurement requirements.)
- Cut-Out Depth: 35 3/8 inches (Minimum required depth of the installation location for a standard installation of the product. This measurement will help you determine if the appliance will fit into the desired space and have the clearance necessary for proper operational use. Please refer to the manufacturer’s installation documentation for detailed measurement requirements.)
- Capacity
- Total Capacity: 20.2 cubic feet
- Refrigerator Capacity: 14.7 cubic feet (Total amount of space within the refrigerator compartment. Usable space may be reduced by shelves, cabinets, or other storage features.)
- Freezer Capacity: 5.5 cubic feet (Total amount of space within the freezer compartment. Usable space may be reduced by shelves, cabinets, or other storage features.)
- Features
- Configuration: Freestanding (The size, arrangement, and physical configuration of the product.)
- Refrigerator Style: Top Freezer
- Convertible Temperature Zone: false (Refrigerators with this feature include a separate compartment with independent temperature controls from the main product. These compartments offer a flexible space that allows you to change the temperature based on your additional storage needs. Whether it’s a place to chill beverages for an evening with friends, keep snacks cool, or even provide extra freezer space.)
- Temperature Control Type: Electronic
- Defrost Type: Automatic (Ice build-up can reduce the appliance’s cooling capacity, making it work harder and consume more energy. Defrosting is necessary to maintain its efficiency and each type has its own advantages depending on user needs and preferences. Manual defrost appliances require unplugging to melt ice naturally, but offer more space, lower energy consumption, and lower cost without the internal heating element. Frost-free appliances regulate temperature to prevent ice build-up automatically. Automatic defrost systems use a timer to circulate heat and prevent ice accumulation, while adaptive defrost systems use sensors to determine the optimal times for heat circulation.)
- Reversible Door Hinge: false
- Lighting Type: LED
- Ice & Water
- Ice Maker: No
- Ice and Water Dispenser: None
- Storage
- Quick Access Door: false (A door-within-door that provides convenient access to your favorite food and drink items without opening the main door.)
- Gallon Door Storage: true (Designated storage space for gallon-sized containers, such as milk, juice, and water.)
- Humidity-Controlled Crisper: true
- Refrigerator Shelf Material: Tempered Glass
- Freezer Info
- Freezer Compartment: true
- Freezer Location: Top
- Freezer Shelf Material: Glass
- Freezer Interior Light: true
- Filter Info
- Water Filtration: false
- Electrical Specification
- Amperage: 15 amperes (Strength of electrical current.)
- Voltage: 120 volts (Amount of power needed to support an electrical current.)
- Estimated Annual Electricity Use: 387 kilowatt hours (Predicted amount of electricity needed to operate the product under average conditions for one year.)
- Estimated Annual Operating Cost: 46 United States dollars (Predicted cost of operating the product under average conditions for one year.)
- Certifications Listings & Approvals
- ENERGY STAR Certified: true (Devices carrying the ENERGY STAR service mark, such as computer products and peripherals, kitchen appliances, and other products, generally use 20% to 30% less energy than required by federal standards.)
- Compatibility
- App Compatible: false (The product can be connected to a program or software application on a mobile device, which then receives collected data from the product.)
- Other
- UPC: 048231794978
Optimize food storage with this 30-inch LG refrigerator. Its 20.0 cu. ft. capacity provides sufficient room for plenty of perishable groceries, and the tempered glass shelves let you organize items to suit your needs. The humidity-controlled crispers of this LG refrigerator help you prolong the life of fruits and vegetables.
- Large Capacity, 20 cu ft.: Great size in a feature-packed refrigerator.
- Sophisticated Style & Design: Details matter more than ever when creating a distinctive kitchen.
- Humidity Control Crispers: Humidity-controlled crispers are a great place to keep fruits, vegetables, and more.
- Premium LED Lighting: LED panels located on the rear of the refrigerator provide an exceptionally bright interior and saves energy over traditional lighting.
- SmartDiagnosis™: Troubleshoot quickly and efficiently with SmartDiagnosis™.
- Digital Temperature Controls: Digital Temperature Controls designed to monitor and maintain conditions to help keep food fresh.
- 10-Year Manufacturer's Limited Warranty on Linear Compressor: LG confidently backs the Linear Compressor with a 10-year limited warranty.
- ENERGY STAR® Qualified: Save money and energy with this ENERGY STAR® qualified LG refrigerator that exceeds energy standards.
Product Manuals
Documents
- Energy_Guide_PDF
Q: does the freezer compartment have shelves? if so, how many?
A: It has 2 fixed shelves.
Q: will ltcs 2012w fit lg5989ja0002n
A: undefined
A: Beware! When I bought my LG 20 CF fridge at Best Buy, the manager told me it came with an ice maker. We looked on line and the picture shows an ice maker. However, fridge delivered, no ice maker. Found out this LG model doesn’t come with an ice maker. I talked to the manager who found an ice kit at AJ Madison that’s I had to order and have delivered. Then, I must call Best Buy and they’ll install. Best Buy will reimburse me the ice maker cost. What a goat rope. Delivery of appliances from BB has been the biggest inconvenience as I had delivery issues with the stove I ordered and had to schedule someone to come in and install a new handle. Delivery people suck big time in Springfield, VA. BB doesn’t make it easy once an item is delivered. Should I really be doing all this work?
Q: Your photo on Best Buy page shows an ice maker! Can unit LTCS20120W have an ice maker installed?
A: The Automatic Ice Maker is not included in all models of the ENERGY STAR® Qualified LG 20 cu. ft. Top Freezer Refrigerator, Model # LTCS20120S. For models that are listed as being "Ice Maker Ready", means that the refrigerator does not come with an Automatic Ice Maker Installed but the Automatic Ice Maker Kit, Model # LK65C, can be installed should you want an Automatic Ice Maker. ^CP
A: Hello, wondering the same thing.. did you end up adding a 3rd shelf? Seems silly there is so much extra space on the bottom where a shelf could be. Thanks
A: The Automatic Ice Maker is not included in all models of the ENERGY STAR® Qualified LG 20 cu. ft. Top Freezer Refrigerator, Model # LTCS20120S. For models that are listed as being "Ice Maker Ready", means that the refrigerator does not come with an Automatic Ice Maker Installed but the Automatic Ice Maker Kit, Model # LK65C, can be installed should you want an Automatic Ice Maker. Models that are listed as having a "Factory Installed Ice Maker" come with an Automatic Ice Maker installed...^IFV
A: The door is able to be removed for ease of installation. The Depth without Door is 29". If you are in need of any assistance, have additional questions, or would just like to see our helpful tips, check us out on Twitter @LGUSSupport Facebook https://www.facebook.com/LGUSA/ or you can give us a call at 800-243-0000. ^CP
