GIGABYTE - H810M S2H (Socket LGA 1851) Intel H810 mATX DDR5 Motherboard - Black
Model: H810M S2H
SKU: 6637841
This item is no longer available in new condition. See similar items below
- Key Specs
- Chipset: Intel H610
- Form Factor: microATX (The size, arrangement, and physical configuration of the product.)
- Processor Socket: Socket LGA 1851 (Type of pin configuration that connects a CPU to a computer’s motherboard.)
- Number of PCI-E Slots: 1 (How many peripheral component interconnect express slots are available.)
- Wireless Networking Standard: No Wi-Fi standard (The wireless networking standard used by the device. Each iteration of the standard developed by the Wi-Fi Alliance corresponds to an existing IEEE 802.11 protocol; for example, standard 802.11ac (or AC) is termed Wi-Fi 5. Refers specifically to the standard the device is designed to use, but ultimately determines product interoperability and backward compatibility including previous versions.)
- Number Of Memory Slots: 2
- Maximum Memory Supported: 128 gigabytes
- Memory Type Supported: DDR5
- General
- Brand: GIGABYTE
- Model Number: H810M S2H
- Product Name: H810M S2H (Socket LGA 1851) Intel H810 mATX DDR5 Motherboard
- Color: Black
- Year of Release: 2025
- Compatibility
- Chipset: Intel H610
- Chipset Compatibility: Intel
- Form Factor: microATX (The size, arrangement, and physical configuration of the product.)
- Processor Socket: Socket LGA 1851 (Type of pin configuration that connects a CPU to a computer’s motherboard.)
- Processor Compatibility: Intel Core Ultra 5 Series 2, Intel Core Ultra 7 Series 2, Intel Core Ultra 9 Series 2
- Operating System Compatibility: Windows 11 Home
- Slot
- Number of M.2 Slots: 1 (This interface is most commonly used for high-speed solid state drives (SSDs), and is often used in laptops due to its small size.)
- Number of PCI-E Slots: 1 (How many peripheral component interconnect express slots are available.)
- Number Of PCI-E x16 Slots: 1
- Number Of Memory Slots: 2
- Connectivity
- Wireless Connectivity: Wi-Fi (The manner in which a device sends data to another device over a short distance without the use of wires or cables.)
- Wireless Networking Standard: No Wi-Fi standard (The wireless networking standard used by the device. Each iteration of the standard developed by the Wi-Fi Alliance corresponds to an existing IEEE 802.11 protocol; for example, standard 802.11ac (or AC) is termed Wi-Fi 5. Refers specifically to the standard the device is designed to use, but ultimately determines product interoperability and backward compatibility including previous versions.)
- Ports
- USB Ports: 5 x USB-A 2.0, 1 x USB-A 3.2 (The number and type of USB ports the product has.)
- Number of Audio Channels: 2, 4, 5.1, 7.1 (The number of discrete channels of sound output. This can be a single number or multiple numbers separated by decimal(s). The first number is the primary, horizontally directed audio channels. The number after the first decimal, if applicable, is the number of subwoofer outputs or channels. The number after the second decimal, if applicable, is the number of height or atmospheric channels designed to immerse the listener by producing overhead sound effects.)
- Dimensions
- Product Length: 9.6 millimeters (The out of box length of the item. Length is measured as the longest dimension of the item.)
- Product Width: 8.5 millimeters (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Weight: 27.84 ounces (The out of box weight of the item.)
- Memory
- Maximum Memory Supported: 128 gigabytes
- Memory Type Supported: DDR5
- Memory Format Supported: UDIMM (Memory module size that will fit with the device.)
- Memory Speeds Supported: up to 6400 MT/s (The RAM's bandwidth rating supported by the device. The number refers to transfer speed. For example, 12800 would indicate that the memory has a theoretical bandwidth of 12,800 megabytes per second (MBs). The higher the number, the faster the speed.)
- Memory Slot Type: 288-pin DIMM
- Features
- RAID Support: RAID 0, RAID 1, RAID 5 (A Redundant Array of Independent Disks (RAID) includes a collection of separate disks that your computer recognizes as one disk unit. Each configuration offers a different level of mirroring, striping and read/write speeds.)
- Warranty
- Warranty - Parts: 3 years
- Warranty - Labor: 3 years
- Other
- UPC: 889523047996
The H810M S2H supports Intel Ultra Core Processors (Series 2) and features unmatched performance. GIGABYTE H810 motherboards come with upgraded power design, high grade storage standards, and outstanding connectivity that enables you to optimize your performance.
- Processor Compatibility: Supports Intel Core Ultra Processors (Series 2)
- DDR5 Compatible: 2*DIMMs
- Next Gen Connectivity: PCIe 4.0, 1x M.2 Slots, USB 3.2 Gen1, HDMI, DisplayPort
- DIY Friendly: PCIe EZ-Latch, EZ Debug Zone
- Networking: 1GbE LAN
- Processor Compatibility: Supports Intel Core Ultra Processors (Series 2)
- DDR5 Compatible: 2*DIMMs
- Next Gen Connectivity: PCIe 4.0, 1x M.2 Slots, USB 3.2 Gen1, HDMI, DisplayPort
- DIY Friendly: PCIe EZ-Latch, EZ Debug Zone
- Networking: 1GbE LAN
Whats Included
- H810M S2H (Socket LGA 1851) Intel H810 mATX DDR5 Motherboard
- H810M S2H (Socket LGA 1851) Intel H810 mATX DDR5 Motherboard
