NETGEAR - 8-Port 10/100/1000 Mbps Gigabit Smart Managed Plus Switch - Black
- Key Specs
- Number of PoE (Power over Ethernet) Ports: 4 (Allow connection of a single cable that provides both data connection and electrical power (Power over Ethernet).)
- Form Factor: Desktop
- Maximum Data Speed: 2000 megabits per second
- Switch Management Type: Smart managed (Unmanaged switches don't require user configuration and are typically used for basic connectivity. Managed switches have more features and can be configured by the user for custom network use.)
- Number of LAN Ports: 8 (Number of devices able to be connected to the Local Area Network (LAN). LAN ports allow wired connections to other networking devices (wireless access points, range extenders, etc.) in order to share the internet connection received through a WAN port.)
- General
- Brand: NETGEAR
- Model Number: GS108PE-300NAS
- Product Name: 8-Port 10/100/1000 Mbps Gigabit Smart Managed Plus Switch
- Color: Black
- Network
- Quality Of Service (QoS) Traffic Prioritization: true (Allows a user to manage a device's network performance by configuring the types of traffic that receive top priority for transmission. High priority functions and applications receive maximum network performance, while low priority traffic receives minimum performance.)
- Uplinking Capability: true (Devices with an uplink port are capable of connecting to other networking devices, such as switches and hubs, to expand the network. For example, two switches may be connected together in a larger network using a daisy-chain setup.)
- Ethernet Standard: 10/100/1000 (Each standard is a variation of the IEEE 802.3 set of computer networking technologies known as Ethernet. New versions evolved to include higher bandwidth, different physical media, and other new and improved features. Standards are often denoted by speeds (in Megabits per second). For example, a 10/100/1000 Ethernet port transmits at 10 Mbps, 100 Mbps, and 1000 Mbps (1 Gbps).)
- Features
- Auto Speed Sensing: true
- Speed
- Gigabit Ethernet Speed: true (Supports the gigabit Ethernet networking standard, which has a data rate of at least one gigabit per second, or 1,000 Mbps.)
- Dimensions
- Product Height: 1.14 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Length: 3.98 inches (The out of box length of the item. Length is measured as the longest dimension of the item.)
- Product Width: 6.22 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Weight: 1.19 pounds (The out of box weight of the item.)
- Other
- UPC: 606449103458
Today's businesses demand and rely more on their network to carry out mission-critical business activities. NETGEAR® Smart Managed Plus Switches meet this growing need by providing fundamental network features such as VLANs, QoS, and IGMP Snooping that will help optimize the performance of business networks. Smart Managed Plus Switches are the perfect upgrade from the plug-and-play unmanaged switch, delivering essential networking features at a very affordable price.
- Smart Managed Plus Switch: Provides fundamental network features such as VLANs, QoS, and IGMP Snooping that will help optimize the performance of business networks.
- Power over Ethernet: 8 Gigabit PoE ports (802.3af) providing up to 13.3W per port with 53W total PoE power budget.
- Auto sensing: Supports Quality of Service (QoS) for traffic prioritization.
- Interactive LEDs: Show speed, activity, power and PoE power information.
- Auto DoS prevention: Secures your information.
- Plug-and-play connectivity: Provides simple, yet useful network setup.
- Smart Managed Plus Switch: Provides fundamental network features such as VLANs, QoS, and IGMP Snooping that will help optimize the performance of business networks.
- Power over Ethernet: 8 Gigabit PoE ports (802.3af) providing up to 13.3W per port with 53W total PoE power budget.
- Auto sensing: Supports Quality of Service (QoS) for traffic prioritization.
- Interactive LEDs: Show speed, activity, power and PoE power information.
- Auto DoS prevention: Secures your information.
- Plug-and-play connectivity: Provides simple, yet useful network setup.
Whats Included
- NETGEAR 8-Port 10/100/1000 Mbps Gigabit Switch
- DC power adapter
- Wall-mount installation kit
- Owner's manual
- NETGEAR 8-Port 10/100/1000 Mbps Gigabit Switch
- DC power adapter
- Wall-mount installation kit
- Owner's manual
Q: Can this power 4 Ring POE cameras and connect them to the network?
A: It works flawlessly with my Reolink cameras and DVR. 4 cameras off the POE ports and another port goes to my DVR across the house.
A: No. You need a Router that supports Dual Internet connections (Dual WAN) to do this, like the Linksys LRT224. Each internet connection connects directly to your router. Then your router connects to a switch or via WiFIto drive your home network.
Q: Can I use the PoE ports for non-PoE devices?
A: Absolutely! You will have no problems using non PoE devices if they are plugged into PoE ports. Jarreft
Q: Does this switch have a built in DHCP server?
A: No it does not, it can either have a static IP for access or get an IP via DHCP. But it does not have a built in dhcp server.
Q: Can I do packet capture between 2 ports using the monitor port of this switch ?
A: YES. Any smart switch allows port monitoring: all packets for one port copied to another.
A: undefined
A: Hi DillyMcphilly, This is just like a dumb switch with a little bit of L2 features(Smart Plus Switch). Most of our Managed switches are L2+/L3 switches with routing and DHCP functionalities. If you have any questions, you can also check out our NETGEAR community. Best regards, NETGEAR Amazon
A: Hi Oldskool, This is just a switch which is an additional port for a router. It does not support DHCP and Firewall services. You may need to look for a router like the NETGEAR BR200. If you have any questions, you can also check out our NETGEAR community. Best regards, NETGEAR Amazon
