Audio Cartridges

0.3 x 0.7 mil elliptical replacement stylus for AT-VM95EN cartridge.

The AT-VM95E/H combo kit includes the AT-VM95E dual moving magnet cartridge premounted on the AT-HS6BK headshell. VM dual magnet cartridge with 0.3 x 0.7 mil elliptical stylus. Aluminum cantilever. Specially wound coils increase output voltage. Durable low-resonance polymer housing. Threaded inserts in cartridge body enable cartridge to be mounted to headshell with just two screws – no nuts or washers required. Compatible with any AT-VMN95 replacement stylus. Universal ½"-mount headshell for 4-pin turntable cartridges. Frequency Response: 20-22,000 Hz. Channel Separation: 20 (dB at 1 kHz). Vertical Tracking Force: 1.8-2.2 g (2.0 g standard). Stylus Construction: Bonded round shank. Recommended Load Impedance: 47,000 ohms. Output: 4.0 mV (1 kHz, 5 cm/sec.). Channel Balance: 2.0 dB (1 kHz). Stylus Shape: 0.3 x 0.7 mil elliptical. Cantilever: Aluminum pipe. Mount: Half-inch. Replacement Stylus: AT-VMN95E. Coil Impedance: 3.3 k ohms (1 kHz). DC Resistance: 485 ohms. Load Capacitance: 100 to 200 pF. Coil Inductance: 550 mH (1 kHz). Vertical Tracking Angle: 23°. Dimensions (Cartridge): 17.2 mm (0.68") H × 18.9 mm (0.74") W × 28.3 mm (1.20") D. Weight (Cartridge): 6.1 g (0.22 oz). Dimensions (Cartridge & Headshell): 21.2 mm (0.83") H × 21.4 mm (0.84") W × 62.4 mm (2.46") D. Weight (Cartridge & Headshell): 15.5 g (0.55 oz). Accessories Included: Two 11 mm installation screws, two 8 mm installation screws, two washers.

The AT-VM95ML/H combo kit includes the AT-VM95ML dual moving magnet cartridge premounted on the AT-HS6BK headshell. VM dual magnet cartridge with 2.2 x 0.12 mil Microlinear stylus. Aluminum cantilever. Specially wound coils increase output voltage. Durable low-resonance polymer housing. Threaded inserts in cartridge body enable cartridge to be mounted to headshell with just two screws – no nuts or washers required. Compatible with any AT-VMN95 replacement stylus. Universal ½"-mount headshell for 4-pin turntable cartridges.

The VM540ML/H combo kit includes the VM540ML MicroLine dual moving magnet cartridge premounted on the AT-HS10BK universal 1/2"-mount headshell. The VM540ML MicroLine stylus cartridge is the premier 500 Series model in Audio-Technica’s new VM cartridge line – a line that harks back to A-T’s early days as a manufacturer primarily of high-end phono cartridges, while also incorporating today’s advanced technology. Like all VM cartridges, the VM540ML is equipped with dual magnets that are positioned to match the left and right channels in the stereo record groove for outstanding channel separation and extended frequency response. The cartridge’s MicroLine stylus allows it to trace the record groove with incredible accuracy, resulting in nuanced audio reproduction that elliptical and conical styli simply can’t match. The stylus’s multilevel shape also wears better than other styli, while reducing the wear on your records. Includes mounting hardware. VM dual magnet cartridge with MicroLine stylus. Aluminum cantilever. Paratoroidal coils improve generating efficiency. Center shield plate between the left and right channels reduces crosstalk. Durable low-resonance polymer cartridge housing. Universal ½"-mount headshell for 4-pin turntable cartridges.

2.2 x 0.12 mil microlinear replacement stylus for AT-VM95ML cartridge.- Stylus Shape: Microlinear- Stylus Construction: Nude Square Shank

The AT-XP3 cartridge is specially designed for DJs. It features a highly-rigid polyphenylene sulfide (PPS)/glass fiber body, has a tracking force of 2 to 4 grams, and offers a powerful output level of 5.5 mV. Its 0.6 mil conical bonded stylus tracks the center of the record groove for reliable performance and excellent fidelity. And the cartridge design provides maximum visibility of the stylus tip. The AT-XP3 cartridge is compatible with any XP or VM95 Series replacement stylus, offering a wide choice of options for every budget and application. 0.6 mil conical bonded stylus tip. Highly-rigid polyphenylene sulfide (PPS)/glass fiber body. 5.5 mV high-level output. Tracking force of 2.0 to 4.0 grams (3.0 grams standard). Durable carbon fiber-reinforced ABS cantilever and nylon wire suspension ensure precise tracking. Design offers maximum visibility of the stylus tip. Great tracking and channel separation for high-fidelity sound. AT-XP3 cartridge is compatible with any XP or VM95 Series replacement stylus, offering a wide choice of options for every budget and application.
