Questions & Answers

Q: QuestionDoes this Audio Technica cartridge include a headshell?

• A:Answer Yes, the VM540ML/H combo kit includes the VM540ML MicroLine® dual moving magnet cartridge premounted on the AT-HS10BK universal 1/2"-mount headshell.

Q: QuestionWhat is the mount size of this Audio Technica cartridge?

• A:Answer This cartridge has a half-inch mount.

Q: QuestionWhat type of stylus does this Audio Technica cartridge use?

• A:Answer This Audio Technica cartridge uses a MicroLine stylus.

Q: QuestionWhat is the benefit of the paratoroidal coils in this Audio Technica cartridge?

• A:Answer The paratoroidal coils improve generating efficiency.

Q: QuestionIs this compatible with the AT-LP120X?

Asked 3 years ago by Jojo.

• A:Answer The compliance of the VM540ML Cartridge (17cu @ 10 Hz) is a bit high for a tonearm whose effective mass is 20.6 grams. The preferred tonearm/cartridge resonant frequency range is from 8 to 11 Hz. The AT-LP120XUSB / VM540ML combination would have a resonant frequency of 7 Hz. So the VM540ML/H on the AT-LP120XUSB Turntable is not a deal breaker, but the cartridge would perform its best on a lighter arm. With a compliance of 15cu @ 10 Hz, the VM530EN Cartridge (or the VM530EN/H Headshell + Cartridge Combo Kit) would be a better match. The resonant frequency of this combination would be 8 Hz.

  Answered 3 years ago by AudioTechnica


  Helpful (4)Unhelpful (0)ReportAnswer this questionShow more answers (3)

Q: QuestionI am looking to order the VM540ML cartrige with headshell as an upgrade to my AT LP 120 XBT-USB as I am not happy with the stylus it came with. This is a two part question. One does it come preassembled and two will I have to adjust the tonearm again? TY

Asked 4 years ago by Sand.

• A:Answer Yes, the cartridge provided with the VM540ML/H Headshell/Cartridge Combo Kit comes mounted, wired, and aligned. Due to a difference in the weight of both the cartridge and the headshell, you will need to rebalance the tonearm and set the tracking force.

  Answered 4 years ago by AudioTechnica


  Helpful (2)Unhelpful (0)ReportAnswer this questionShow more answers (1)

Q: QuestionWill this cartridge and headshell fit the Technics - SL-1500C? I'm thinking of purchasing that turntable because I already have the cartridge.

Asked 3 years ago by TheAmnesiacKid.

• A:Answer Assuming that the SL-1500C has a tonearm effective mass of 12 grams, like most of Technics s-shaped tonearms, the VM540ML Cartridge would be a good match. The resonant frequency of this tonearm/cartridge combination would be 9 Hz, which falls within the preferred range of 8 to 11 Hz. Note that this is obtained when using the provided Technics headshell, which weighs 7.6 grams. If you replace this headshell with the AT-HS10 Headshell which is the headshell the VM540ML/H Headshell/Cartridge Combo Kit consists of, the effective tonearm mass will be increased to 14.4 grams and the resonate frequency of this combination drops to 8 Hz.

  Answered 3 years ago by AudioTechnica


  Helpful (2)Unhelpful (0)ReportAnswer this question

Q: QuestionIs this a good fit for a Technics SL-1400 turntable?

Asked 5 days ago by Den.

• A:Answer Yes, it is.

  Answered 3 days ago by AudioTechnica


  Helpful (1)Unhelpful (0)ReportAnswer this question

Q: QuestionWould this stylus be a good option for my fluance rt-85? I'm looking to upgrade from my current stylus.

Asked 1 year ago by Tone.

• A:Answer You may use the VM540ML Cartridge, but you should stick with the Fluance headshell that was provided with the turntable. According to Fluance documentation, the maximum acceptable combined headshell/ cartridge weight is 16.5 grams (with the provided counterweight). The VM540ML/H Headshell/Cartridge Combo Kit weighs 16.8 grams. The Fluance headshell weighs 9 grams, the (AT-HS10) headshell included with the combo kit weighs 10.4 grams including the mounting hardware. If you really want the combo kit, see if Fluance offers a heavier counterweight for the RT-85.

  Answered 1 year ago by AudioTechnica


  Helpful (1)Unhelpful (0)ReportAnswer this question

Q: QuestionWill this be complaint with the Technics 1200gr? If so with at headshell or Technics headshell? Any other recommendations greatly appreciated.

Asked 2 years ago by Miguel.

• A:Answer It will be. It appears that the effective mass of the SL1200GR tonearm (with the provided headshell) is 9 grams. If this is correct, the resonance frequency of this tonearm/cartridge combination would be 10 Hz. With the (AT-HS6) headshell provided with the VM540ML/H Headshell/Cartridge Combo Kit, the resonance frequency would be 9 Hz. The preferred resonance frequency range is from 8 to 11 Hz, so you are good either way.

  Answered 2 years ago by AudioTechnica


  Helpful (1)Unhelpful (0)ReportAnswer this question

Q: QuestionWould this be a good fit for a vintage Yamaha YP-211?

Asked 2 years ago by SteveB.

• A:Answer Yes, it would.

  Answered 2 years ago by AudioTechnica


  Helpful (1)Unhelpful (0)ReportAnswer this question

Q: QuestionWould this cartridge work with Denon 300f turntable?

Asked 3 months ago by Yankeefan.

• A:Answer The VM540Ml cartridge itself will but not the combo kit. The combo kit consists of a headshell that is straight, your turntable requires a headshell that is angled. We recommend you use the headshell that was provided with your turntable to ensure the stylus overhang distance and the tonearm offset angle will be correct.

  Answered 3 months ago by AudioTechnica


  Helpful (0)Unhelpful (0)ReportAnswer this question

Q: QuestionIs the stylus for this cartridge sold separately?

Asked 9 months ago by stylus.

• A:Answer Yes, the VMN40ML is the replacement stylus for the VM540ML Cartridge.

  Answered 9 months ago by AudioTechnica


  Helpful (0)Unhelpful (0)ReportAnswer this question

Q: QuestionWill this work with a 1978 Mitsubishi DP EC-10 turntable?

Asked 1 year ago by Mike.

• A:Answer It will but you will need to adjust stylus overhang distance. The turntable calls for a stylus overhang distance of 14mm and our Headshell/Cartridge Combo Kits come with stylus overhang set at 15.5mm.

  Answered 1 year ago by AudioTechnica


  Helpful (0)Unhelpful (0)ReportAnswer this question

Q: QuestionWill the VM540ML cartridge be compliance with the Pro-Ject X1 turntable (effective tonearm mass: 10g) ?

Asked 1 year ago by Thoms76.

• A:Answer Yes, the VM540ML is suitable for use on the Pro-Ject X1 Turntable.

  Answered 1 year ago by AudioTechnica


  Helpful (0)Unhelpful (0)ReportAnswer this question

Q: QuestionHow is the complaince of the VM540ML/Headshell with the AT-LP140XP?

Asked 2 years ago by Miguel.

• A:Answer The preferred resonance frequency range is from 8 to 11Hz. The resonance frequency for this tonearm/cartridge combination would be 7Hz. If you change the provided headshell (9.3 grams) out for a lighter headshell (6.7 grams for example) the frequency moves up to 8Hz. Parts Express Part #230-010 Universal Headshell w/ Wires, 6.7g

  Answered 2 years ago by AudioTechnica


  Helpful (0)Unhelpful (0)ReportAnswer this question

Q: QuestionWould this cartridge (AT VM540ML/H) be a suitable upgrade for a Denon DP450USB turntable connected to Denon DRA 800 H receiver phono preamp?

Asked 2 years ago by Johnnie2.

• A:Answer This cartridge is compatible with this Denon turntable. I have it connected to a DP400 turntable.

  Answered 2 years ago by moviesrusVerified Purchase

  Helpful (0)Unhelpful (0)ReportAnswer this questionShow more answers (1)

Q: QuestionIs this a standard mount headshell? Will it fit a pioneer PL518? Also, does it come pre-aligned?

Asked 3 years ago by Nick.

• A:Answer It is a standard half-inch mount headshell and stylus overhang comes aligned to 15.5mm, the same as that required for PL518 your tonearm.

  Answered 3 years ago by AudioTechnica


  Helpful (0)Unhelpful (0)ReportAnswer this question

Q: QuestionWould this cartridge be a suitable upgrade for an AT - LPW30TK turntable?

Asked 3 years ago by JohnH.

• A:Answer This should fit most AT TTs.

  Answered 3 years ago by Rt68Verified Purchase

  Helpful (0)Unhelpful (0)ReportAnswer this questionShow more answers (1)
